- Page 1 For More Info OPERATING MANUAL SHREDDER Click Here ---> Strip Cut 1/2” Strip Cut 1/4” Cross Cut 1/4” x 2” Keep in a safe place for future use! http://www.monomachines.com...
-
Page 2: Table Of Contents
http://www.monomachines.com Contents Proper use, warranty......................3 Safety instructions......................3 Overview .......................... 4 Dimensions ........................5 Transportation, installation ....................6 Operator controls ......................7 Start-up, inspecting the safety devices ................8 Malfunctions........................11 Maintenance and care ....................12 10. Scope of supply, accessories..................14 11. -
Page 3: Proper Use, Warranty
• Carry out inspection and maintenance regularly. • Switch off the shredder, disconnect the power plug and call customer service in the following circumstances: - power cables or plugs are damaged - liquid has entered the shredder - the shredder has been exposed to rain... -
Page 4: Overview
http://www.monomachines.com Overview Main switch (only solo-version) Keypad Emergency stop button Loading tray Left cover panel Right cover panel Intake conveyor, paper feed opening Front door Braking swivel castors Nameplate For More Info Click Here ---> http://www.monomachines.com... -
Page 5: Dimensions
http://www.monomachines.com For More Info Dimensions Click Here ---> „ 45.5 „ 31.6 „ 61.6 Solo version „ 45.5 „ 31.6 „ 64.7 Combi version „ „ 31.5 31.6 „ 49.7 „ Transportation dimensions (without tray) Space requirements for operation and maintenance http://www.monomachines.com... -
Page 6: Transportation, Installation
• When moving the shredder use caution; remember the high center of gravity. • The shredder may only be placed in dry rooms on a hard, level floor — not on carpets. The floor load on each roller is approximately 396.8 lbs. -
Page 7: Operator Controls
Operator controls Main switch (only Solo-version) In the "0" position, the shredder is switched off. The main switch can be secured with a padlock. In the "I" position, the machine is ready for operation. Emergency stop button In the event of danger, press the emergency stop button immediately! This switches off the shredder, and stops the cutting block and feed belt. -
Page 8: Start-Up, Inspecting The Safety Devices
The green "Ready for operation" LED lights up. Note: There is a safety switch on the front door of the shredder. The machine can only be switched on when the door is shut. • Press the green start button. - Page 9 Press the emergency stop button while the machine is running. The shredder must switch off immediately. The cutting block and the feed belt must stop. The machine will only start again once you have pulled out the emergency stop button again.
- Page 10 • Press the stop button. The drive stops. • Press the reverse button. The cutting block and feed belt will run in reverse. • You can now remove the material from the belt and start the shredder again by pressing the start button.
-
Page 11: Malfunctions
• Is the shredder switched on? • Is the front door closed? • Is the waste bag full? • Is there a paper jam in the shredder? • Has the motor been overloaded? Paper jam (excessive paper feed) The red LED on the keypad blinks ... -
Page 12: Maintenance And Care
Maintenance and care Cleaning the cutting block (once daily) • Switch off the shredder. • Squirt special cutting block oil through the paper feed opening onto the blade rollers. 12 oz. bottle 16 oz bottle • Let the cutting block run forwards and backwards several times without feeding in any paper. - Page 13 You must check that the feed belt runs straight: Switch on the shredder and let it run for 10 minutes. During this time, the feed belt must run in the middle of the snub roller. If it slips to the left or right edge, you must alter the setting of the snub roller.
-
Page 14: Scope Of Supply, Accessories
Cleaning the shredder: • Switch off the shredder and disconnect the power plug. • Only use a soft cloth and mild soapy water for cleaning. Never use scouring agent, cleaning fluid, petroleum or thinners. Scope of supply, accessories •... -
Page 15: Electric Wiring Diagrams For Solo- And Combination-Version
For More Info Click Here ---> Electric wiring diagrams Legend: =AV: Shredder in switch cabinet +MA: on machine +BF: Keypad http://www.monomachines.com... - Page 16 http://www.monomachines.com For More Info Click Here ---> http://www.monomachines.com...
- Page 17 http://www.monomachines.com For More Info Click Here ---> http://www.monomachines.com...
- Page 18 http://www.monomachines.com For More Info Click Here ---> http://www.monomachines.com...
- Page 19 http://www.monomachines.com For More Info Click Here ---> http://www.monomachines.com...
- Page 20 http://www.monomachines.com For More Info Click Here ---> http://www.monomachines.com...
- Page 21 http://www.monomachines.com For More Info Click Here ---> http://www.monomachines.com...
- Page 22 Parts and labor to repair any failure caused by defect is limited to one (1) year from date of invoice or warranty registration date. If machine is purchased with an Automatic Oiler, the Cutting Roller is warranted to be free of manufacturer‘s defects to the first buyer for the Lifetime of the shredder from the date of the original purchase invoice. NOTES: •...
