JBL VP7210 Technical Manual

Technical Manual
JBL VP7210/95DP

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Frequency Response:
• Frequency Range:
• Maximum Peak Output:
• Coverage Pattern:
• Directivity Factor (Q):
• Directivity Index (DL):
TRANSDUCER SECTION:
• Cabinet:
• Grille:
• Low Frequency Driver:
• Bandpass Nominal Impedance: 2 x 2 ohms
• High Frequency Driver:
• Bandpass Nominal Impedance: 8 Ohms
SYSTEM:
• DPC1 Internal Amplification
Output (at nominal load):
• DPC1 Output:
• DPC1 Output Section:
HF: Bridged Class D
PACKAGE
SCHEMATIC
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
80 Hz - 20 kHz (±3 dB)
50 Hz – 20 kHz (–10 dB)
132 dB SPL 1m
90º x 50° rotatable waveguide
10
10 dB
Enclosure (Not for Sale)
362983-001
2261FF, 254mm (10 in) dia., 76mm (3
in) Dual Coil neodymium Differential
Drive, Direct Cooled
2452H-SL, 100mm (4 in) titanium
damped diaphragm, 1.5 in exit,
1750W Peak, 875W Continuous
750 LF / 125 HF Watts (Continuous
IEC shaped pink noise into rated load
impedance)
LF: Dual Bridge Technology, Class D
Owners Manual
363642-001
Package, Microfoam (4)
49790P
Carton
363643-001
Filler (2)
363641-001
PKG, Microfoam (4)
49790P
Tape (8)
65012-01
Power Cord Assy Pack
355040 -002
SYSTEM CONT'D:
• Audio Input Connector:
• User Controls:
• Signal Processing:
• System Management:
• AC Power Operating Range: 90-132 VAC / 216-264 VAC, 50/60 Hz
• AC Line Voltage:
• AC Input Connector:
• AC Look-thru:
• AC Current Requirement:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
(Height x Width x Depth)
• Net Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Driver, Low Frequency
2261FF
(354964-003X)
Cone Repl
C2X2R2261
Yel
Yel/Blk
Blu/Blk
Blu
Grn
Grn/Blu
XLR with loop-through
80 Hz Subwoofer High Pass Filter.
Enable / Disable 0-16 dB input
Attenuator w/ 32 precision 0.5 dB steps
DSP based, resident in Input Module
DSP based limiters for mechanical
and thermal protection
50/60 Hz, Auto-Detect; 120V/240V
(-15%, +10%)
Neutrik PowerCon (NAC 3MPA)
Neutrik PowerCon (NAC 3MPB)
6A/system @ 120V, 3A/system @ 240V
100mV Input,, 20 Hz to 20 kHz
4.0V Input, 20 Hz to 1.2 kHz
2.5V Input, 300 Hz to 20 kHz
521 x 293 x 303 mm
20.5 x 11.5 x 11.9 in
40.5 lb (18.4 kg)
Driver, High Frequency
2452H-SL
(352328-003X)
Diaph Repl
D8R2452-SL
Wire Harness
363640-001
11-11
