Summary of Contents for Future Design FDC-9200
- Page 1 User's Manual FDC-9200 Self-Tune Fuzzy / PID Process Temperature Controller...
- Page 2 (1) (2) (3) (4) (5) (6) (7) (8) easy to limit access to suit the specific application. (1) Power Input The FDC-9200 is powered by 20-32 or 90-264VAC supply, incorporating a 90-264VAC 3 amp. control relay output and dual 3 amp. alarm relays output as standard...
- Page 3 3. SPECIFICATIONS 4. INSTALLATION Dangerous voltages capable of causing death are sometimes I N P U T present in this instrument. Before installation or beginning any trouble shooting procedures the power to all equipment must be switched off and Sensor Input Type Range (°C) * Accuracy...
- Page 4 TABLE 4.1 THERMOCOUPLE CABLE COLOUR CODES 2.0mm 0.08" max. British American German French Thermocouple Cable ASTM Type Material + white + blue + red + yellow Copper - blue - red - brown - blue Constantan * blue * blue * brown * blue 7.0 mm...
- Page 5 (OUT 1). The connections are shown in Figure 4.12. Control Output 0 20mA, 4 20mA or 0 10V FDC-9200 Fig. 4.12 Linear Voltage / Current Connections 3 Silicon Rubber buttons For ease of control set-up and setpoint adjustment. 5.2 KEYPAD OPERATION * With power on, it has to wait for 12 seconds to memorize the new values of parameters once it been changed.
- Page 6 5.3 FLOW CHART OF PARAMETERS The following chart shows a typical (default) access sequence of parameters. Note 1 shows how to modify the display sequence and how to delete unused parameters. Low scale to high scale value ** 100.0 C Normal Display Process value / setpoint value Low scale...
- Page 7 5.4 FLOW CHART OF TOOL PROGRAMS Hand ( Manual ) Control Enter the manual control mode. Long View the percentage power Allow to adjust the percentage value of of output 1. (Heating) output 1 by using 100% View the percentage power (No function with BTC -9200.) of output 2.
- Page 8 5.5 SETTING-UP PROCEDURES the controller does not use the RS-485 interface, the ADDR can be neglected. As power applied, the model number of the controller and its software version number will be displayed for 3.2 seconds, then all the display segments and LED indicators will be lit for 3.2 seconds.
- Page 9 level value is unchanged the above operation for entering can be omitted. For example: If ASP1, RAMP are configured as level 0, PB, TI, TD are configured as leve 1, and the other parameters are configured as level 3, the scrolling sequence of parameters will be as follows: ASP1 RAMP Cycle time too long...
- Page 10 (2) The cycle time (T) of this oscillation in seconds (see following Figure). 5.8 ON-OFF CONTROL * The control setting should then be adjusted as follows: The alarm output if configured as alarm function performs an ON-OFF control basically. Adjust the P band to PB = 0, an additional channel of ON-OFF control with variable hysteresis is obtained.
- Page 11 5.10 ALARM 5.11 VIEWING THE OUTPUT PERCENTAGE POWER There is a independent alarm available by adjusting the alarm special Selecting the Tool Programs until the HAND CONTROL is obtained. function A1SF and A2SF. The following descriptions of this section are Press scroll key, the display will show the process value and the display based on Alarm 1.
- Page 12 PCB to prevent the cold-junction compensator from warming up Select an appropriate Input Type ( INPT). Define the range by adjusting LOSC and HISC. In the example below, INPT = 4-20 (mA), LOSC = 0, HISC = 100.0, RESO = FDC-9200 COM+ 100.0 (HISC) LLEr...
- Page 13 "code value is always in degree C independent of the selection of " UNIT ". FDC-9200 (5) Press the scroll key for at least 3.2 seconds, then release. display will blink a moment and show an accurate temperature. If the accuracy of the controller is still unacceptable, replace the controller.
- Page 14 TABLE 7.1 TROUBLESHOOTING Sympton Probable Causes (s) Solution (s) - Clean contact area on PCB 1) Keypad no function - Bad connection between PCB & keypads - Replace keypads - No power to instrument - Check power line connections 2) LED's will not light - Power supply defective - Replace power supply board - LED display or LED Lamp defective...
- Page 15 8.0 COMMON FAILURE CAUSES ommon Failure Causes and Corrective Actions Symptom Probable Causes Corrective Actions - Clean contact area on PCB -Bad connection between PCB & keypads 1) Keypad no function - Replace keypads - No power to instrument - Check power line connections 2) LED's will not light - Power supply defective - Replace power supply board...
- Page 16 7524 West 98th Place Bridgeview, IL 60455 Phone 888-751-5444 888-307-8014...
