- Page 1 AT-270T and AT-440T CentreCOM™ Multiport 10BASE-T Transceivers User Manual PN 613-10436-00 Rev. A 960209...
- Page 2 Introduction The CentreCOM Multiport Transceivers are two and four port twisted pair transceivers for users of Ethernet Local Area Networks (LANs). These transceivers provide the electronic and physical interface between the Ethernet 10BASE-T cabling and the IEEE 802.3/Ethernet station Data Terminal Equipment (DTE).
- Page 3 Receive — Indicates packets are received from the UTP media. Polarity —This LED will extinguish if the auto polarity correction has taken place. This +- signal reversal takes place on the RD- and RD+ signal lines only. This LED is normally ON. SQE Test—Heartbeat status LED is ON if Heartbeat is enabled and OFF if Heartbeat is disabled.
- Page 4 The information provided herein is subject to change without notice. In no event shall Allied Telesyn International, Corp. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesyn International, Corp.
