  • Page 1 Allied Telesyn CentreCOM AT-810SL Multiport Transceiver Fanout User Manual...
  • Page 2 The information provided herein is subject to change without notice. In no event shall Allied Telesyn International Corp. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesyn International Corp.

  • Page 3: Electrical Safety And Installation Requirements

    CAUTION: Air vents must not be blocked and must have free access to the room ambient air for cooling. CAUTION: DO NOT detach rubber feet from the product unless an Allied Telesyn vertical mounting chassis is being used. OPERATING TEMPERATURE This product is designed for a maximum ambient temperature of 50 degrees Celsius.
  • Page 4 IKKE FORETAGES uden brug af et Allied Telesyn vertikalt monteringsstel konstrueret til dette formål. ADVARSEL: Ventilationsåbninger må ikke blokeres og skal have fri adgang til den omgivende luft i rummet for afkøling. ADVARSEL: UNDLAD at fjerne gummisoklerne fra apparatet, med mindre der anvendes et Allied Telesyn vertikalt monteringsstel. BETJENINGSTEMPERATUR Dette apparat er konstrueret til en omgivende temperatur på...
  • Page 5 Waarschuwing WAARSCHUWING: Deze modellen zijn ontworpen om te werken in HORIZONTALE stand. VERTICALE MONTAGE mag NIET UITGEVOERD WORDEN, tenzij een daartoe speciaal ontworpen Allied Telesyn chassis voor verticale montage wordt gebruikt. WAARSCHUWING: De ventilatiegaten mogen niet worden gesperd en moeten de omgevingslucht ongehinderd toelaten voor afkoeling.
  • Page 6 ATTENTION: NE PAS ôter les pattes d’attache en caoutchouc du produit, à moins d’utiliser un châssis de montage vertical Allied Telesyn. TEMPERATURE DE FONCTIONNEMENT Ce produit est capable de tolérer une température ambiante maximum de 50 degrés Celsius POUR TOUS PAYS: Installer le produit conformément aux normes électriques nationales et locales.
  • Page 7 ATTENZIONE: NON staccare il piedino in gomma dal prodotto tranne qualora si utilizzi il telaio Allied Telesyn per il montaggio verticale. TEMPERATURA DI FUNZIONAMENTO Questo prodotto è concepito per una temperatura ambientale massima di 50 gradi centigradi. TUTTI I PAESI: installare il prodotto in conformità alle vigenti normative elettriche nazionali.
  • Page 8 ATENCION: Las aberturas para ventilación no deberán bloquearse y deberán tener acceso libre al aire ambiental de la sala para su enfriamiento. ATENCION: NO separe las patas de goma del producto a menos que se esté usando un chasis de montaje vertical de Allied Telesyn. TEMPERATURA REQUERIDA PARA LA OPERACIÓN Este producto está...
  • Page 9 VERTIKALMONTERING får EJ UTFÖRAS utan att ett Allied Telesyn specialkonstruerat vertikalt monteringschassi används. VARNING: Luftventilerna får ej blockeras och måste ha fri tillgång till omgivande rumsluft för avsvalning. VARNING: Ta ej bort gummifötterna från produkten om inte ett Allied Telesyn vertikalt monteringschassi används. DRIFTSTEMPERATUR Denna produkt är konstruerad för rumstemperatur ej överstigande 50 grader Celsius.

  • Page 10: Table Of Contents

    Table of Contents Electrical Safety and Installation Requirements ..........iii Chapter 1 Overview ..........................1 CentreCOM AT-810SL Multiport Transceiver Fanout ................1 AT-810SL 8 Port Fanout, Slim-line Chassis..................1 Features ..............................2 Chapter 2 Installation ........................3 Requirements..............................3 Procedure ................................3 Power................................
  • Page 11 Appendix B Pin Assignments ......................15 Notes ................................15 Appendix C Glossary .......................... 17 Appendix D Technical Support Fax Order ...................23 Incident Summary ............................23 Appendix E CentreCOM AT-810SL Manual Feedback ...............25...

  • Page 12: Chapter 1 Overview

    Chapter 1 Overview CentreCOM AT-810SL Multiport Transceiver Fanout AT-810SL 8 Port The CentreCOM Multiport Transceiver Fanouts are part of a family of multiport transceivers for use with Ethernet Local Area Networks (LANs). Fanout, Slim-line These units can provide network managers with either small standalone...

  • Page 13: Features

    “Station Power” LED indicates when power is applied to any of the Transceiver Ports. On the back of the AT-810SL are redundant LEDs indicating the application of “Station Power” for each Transceiver Port, and one redundant LED indicating “System Power.” Allied Telesyn STATION PORT TRANSCEIVER PORT CentreCOM...

  • Page 14: Chapter 2 Installation

    Chapter 2 Installation Requirements Attention Before installing AT-810SL Multiport Transceiver Fanouts, read the electrical safety and installation requirements starting on page i. Before installing the AT-810SL Multiport Transceiver Fanout, ensure that the following requirements are met: The network cabling is properly configured. Power connections are made at the back panel.

  • Page 15: Power

    Power The CentreCOM AT-810SL Multiport Transceiver Fanout is designed for desktop or rackmount installation with optional Rack Mount Kits AT-RKMT- 2 and AT-RKMT-3. AT-810SL requires a 100-240 VAC power source with a line frequency range from 50 Hz-60 Hz.

  • Page 16: Chapter 3 Operation

    Chapter 3 Operation Station Port Configuration The AT-810SL is designed to require a minimum of operator attention during routine operation. The station port configuration allows access, via an AUI cable and transceiver, to an Ethernet coaxial cable or fiber optic cable. This port is only used when the AT-810SL is set in Remote Mode.

  • Page 17: Led Status Indicators

    Operation LED Status Indicators The AT-810SL has many LEDs to aid in installation and troubleshooting should any problems occur. They also serve to verify correct transceiver operation at a glance. Below is a description of their location, grouping and functionality. Refer to Figure 3 for location of the System Power and Station Power.
  • Page 18 CentreCOM AT-810SL Multiport Transceiver Fanout STATION PORT RECEIVE ON LINE COLLISION TRANSMIT Figure 4: Station Ports Refer to Figure 5 for the location of the Transceiver Ports. On Line —When lit, these LEDs indicate that the corresponding Transceivers Port is connected through an AUI cable to a DTE device, and that the DTE is powered-up and On Line.

  • Page 19: Back Panel

    PORT 1 PORT 3 PORT 5 PORT 7 SYSTEM SQE TEST LOCAL/REMOTE POWER SWITCH SWITCH LOCAL REMOTE Allied Telesyn CentreCOM Figure 6: Back Panel Status 810SL IEEE 802.3/ETHERNET MULTIPORT TRANSCEIVER FANOUT Indicators PORT 2 PORT 4 PORT 6 PORT 8...
  • Page 20 CentreCOM AT-810SL Multiport Transceiver Fanout Attention! Toutes les vis et autre matériel de montage de ces unités emploient le filetage métrique international standard. Ne pas essayer de les remplacer par un autre type de filetage. Varovaisuutta noudatettava! Kaikissa näissä yksiköissä käytettävissä ruuveissa ja metalliosissa käytetään kansainvälisen standardin mukaisia metrisiä...

  • Page 21: Chapter 4 Configuration

    Chapter 4 Configuration The CentreCOM Multiport Transceiver Fanout can be used to expand the number of allowable stations per transceiver in an Ethernet LAN in the following ways: Additional stations can be attached to an Ethernet coaxial cable segment which may have limited taps (MAUs) available. Where numerous stations are in close proximity, the number of transceivers connected to an Ethernet coaxial cable segment can be reduced.
  • Page 22 Configuration The configuration below demonstrates cascading of nine CentreCOM Multiport Transceiver Fanouts to provide up to 64 DTE (workstation) connections from one MAU tap on a coaxial backbone. Enterprise LAN Backbone Optional Backbone Connection Allied Telesis STATION PORT TRANSCEIVER PORT SYSTEM POWER RECEIVE ON LINE...

  • Page 23: Ieee 802.3 Quick Primer

    Appendix A IEEE 802.3 Quick Primer AUI Drop Cables AUI or Drop cables can be no longer than 50 meters (164 ft.) each. Attachments may be made only to the cable ends at the 15-pin D-shell connector. AUI Drop cables may have a maximum 257 ns propagation delay, as used for computing the worst case propagation delay of a cable system.

  • Page 24: Thin (10Base2) Ethernet

    IEEE 802.3 Quick Primer Thin (10BASE2) Ethernet When configuring thin coax segments, IEEE 802.3 specifications allow 30 or fewer MAU attachments per cable segment spaced at no less than 0.5 meters (1.64 ft.) between each attachment. The thin (10BASE2) cable length can not exceed 185 meters (606 ft.) per thin (10BASE2) cable segment.

  • Page 25: Appendix B Pin Assignments

    Appendix B Pin Assignments Notes Control In Shield (CI-S) is tied internally to the connector shell's Protective Ground (PG) and is capacitively coupled to ground through a .01 FD capacitor. Control In pair [(CI-A) and (CI-B)] are sometimes referred to as “Collision.” This signal pair carries messages from the MAU to the DTE in a Manchester encoded format to inform the DTE of the following: Message...

  • Page 26: Pin Assignments

    Pin Assignments Voltage Common (Vc) is the ground return path for the Voltage Plus (Vp) supply voltage (12v-15v 6%) sourced by the DTE to power the MAU. Voltage Plus is optional under the IEEE 802.3 specification but is typically provided by the majority of DTE devices, and as such is used to light the “On Line”...

  • Page 27: Appendix C Glossary

    Appendix C Glossary 10BASE2 —Also called thinnet or CheaperNet, 10BASE2 is a 10 MHz, baseband, 185 meters (606 ft.) maximum coaxial segment. Cable impedance is 50 . 10BASE5 —Also called thick Ethernet, 10BASE5 is a 10 MHz, baseband, 500 meters (1639 ft.) maximum coaxial segment. The cable is commonly referred to as yellow cable.
  • Page 28 Glossary BIT TIME —The duration of one bit symbol (1/BR). Ethernet specifies a bit time of 100 ns. COAX SEGMENT —A segment of Ethernet cable that contains MAU. CARRIER SENSE MULTIPLE ACCESS with COLLISION DETECT (CSMA/CD) —This is the access method employed by IEEE 802.3 LAN transceivers, by which multiple stations compete for use of the transmission medium (coax cable) for data packet transmission, and provides for a level of error detection should that transmission be corrupted or impeded by...
  • Page 29 CentreCOM AT-810SL Multiport Transceiver Fanout DEPARTMENT CONCENTRATOR —Hub which provides a large number of workstation connections. The term, department concentrator, refers to multiple repeaters housed in an AT-36C8 chassis. See Hub/Repeater, Repeater. DIX CONNECTOR —See D-Sub Connector HARMONICA ADAPTER —This adapter provides a simple way to convert the 50-pin Telco connection to RJ45 connections.
  • Page 30 Glossary MANAGEMENT AGENT —Software that is used to view hub activity and set hub variables. MAU —See Medium Attachment Unit MAU to MAU, HUB to HUB WIRING —10BASE-T MAU to MAU or hub to hub wiring generally requires a cross-over cable located somewhere along the UTP cable run.
  • Page 31 CentreCOM AT-810SL Multiport Transceiver Fanout PUNCH-DOWN BLOCK —The punch-down block is the wiring panel where the house wiring from the building’s offices terminates. This is where many 10BASE-T hubs would be located. Wiring installers use a special punch-down tool to insert the UTP wire for data and voice applications. REPEATER —A device used to extend the length, topology, or interconnectivity of the physical medium beyond that imposed by a single segment, up to the maximum allowable end-to-end trunk transmission line...

  • Page 32: Technical Support Fax Order

    City ____________________State/Province____________ Zip/Postal Code __________ Country _________________ Phone __________________Fax ____________________ Incident Summary Model number of Allied Telesyn product I am using _____________________________ Firmware release number of Allied Telesyn product _____________________________ Other network software products I am using (e.g., network managers)

  • Page 33: Centrecom At-810Sl Manual Feedback

    Allied Telesyn. The mailing address and fax number are at the bottom of the page. Your comments are valuable when we plan future revisions of the manual.
