- Page 1 EARTUBE USER MANUAL...
- Page 2 The CORDA EARTUBE-1 not only offers normal stereo reproduction of your music, but it also has a facility to add some of the left channel information to that of the right channel and vice versa. Thus mental stress is reduced and music can be enjoyed with more ease.
-
Page 3: Safety Precautions
Safety precautions Children and minors are not to use the device and should be kept at a safe distance from the device while it is running. Do not run the device without the top cover in place. Voltages inside the amp can be lethal and temperatures are high. - Page 4 Connections At the rear side of the CORDA EARTUBE-1 two pairs of inputs allow you to connect two different audio sources that have typical output voltages above 0.1 Volts (CD-player, cassette-player, tuner, minidisc-player, ...). The source you want to listen to can be selected by the switch at the left front side of the amp.
-
Page 5: Volume Control
Volume control The volume of the CORDA EARTUBE-1 is controlled by the large dial on the left side of the front panel and is increased by clock-wise rotation. The driving capabilities of the CORDA EARTUBE-1 by far exceed that of a regular CD-player. This not only guarantees less distortion, but also has the danger of severe hearing damage. - Page 6 Directional listening In normal daily life people use various mechanisms to locate sources of sound. Firstly, the sound of a source to the right side of the listener (e.g. the right loudspeaker) not only reaches the right ear but, attenuated and delayed, is also heard by the left ear. The level of attenuation and the delay time of this crossfeed signal provide important directional information.
- Page 7 Fortunately, the main directional information is provided by the time delay and level of attenuation of the sounds that reaches the opposite ear. The CORDA EARTUBE-1 can electronically simulate this process and, with appropriate attenuation and delay, add some of the right audiosignal to the left channel and vice -versa.
-
Page 8: Replacing Tubes
Replacing tubes The EARTUBE-1 uses three tubes 6N3P and two tubes GU17 (or its equivalents QQE03/12, RS1023, 6360) If you want to exchange tubes, please disconnect the power cord before removal of the top cover. Also make sure that all pins are properly mounted into the sockets. It is not uncommon that a pin is bend and doesn't enter the socket. -
Page 9: Declaration Of Conformity
Product Type: Audio Amplifier Complies with Standards: LVD: 92/31/EEC, 93/68/EEC, & 73/23/EWG Safety: EN60065 EMC: EN55013, EN55020, EN55022, EN55103, EN61000-3-2, & EN61000-3-3 The official Declaration of Conformity for this product is kept on file at: AudioValve, 34123 Kassel,Umbachsweg 70, Tel. 05617013360... - Page 10 In the event of a failure of your amplifier , AUDIOVALVE will repair or readjust this unit or , should the occasion arise , will replace it provided that all conditions stipulated in this warranty are met.
-
Page 11: Warranty Registration
MODEL : _______________________________________________ SERIAL NUMBER : _______________________________________ PURCHASE DATE : ______________________________________ AUTHORIZED AUDIOVALVE DEALER: PURCHASER`S NAME : ___________________________________ STREET ADDRESS : ______________________________________ CITY : __________________________________________________ ZIP / POSTAL CODE : _____________________________________...
