Samsung SRD-1630 Specifications

Matching your requirements.
10-2010
General purpose
digital recording solution
16CH H.264 Digital Video Recorder
SRD-1630/1630D/1630DC
Forming part of the SRD series of Digital Video Recorders (DVRs),
the SRD-1630 range provides users with an general purpose 16
channel recording solution that has been designed to perfectly
match the functionality and budget requirements for a host of
professional security applications. Providing real-time live view
and higher selectable recording rates across all channels, users
are able to record at higher frame rates than the entry-level
SRD-1610 range; up to 240/200 (NTSC/PAL) fps at CIF resolution,
120/100 fps at 2-CIF resolution and 60/50 fps at 4-CIF resolution.
Besides its flexible recording capacity, like all SRD series DVRs the
SRD-1630 range utilises Samsung's high level H.264 compression
to ensure superb quality, whilst minimising hard drive space and
bandwidth requirements. Options include a built-in DVD drive (SRD-
1630D) and coaxial control compatibility (SRD-1630DC).
•
•
•
•
•
•
Up to 240 (NTSC) / 200 (PAL)fps recording rate
Up to 4ch audio inputs and 1ch audio outputs
SRD-1630 : Max. 6 internal HDD (HDD x 6)
SRD-1630D(C) : Max. 5 internal HDD (HDD x 5)
SRD-1630D(C) : DVD-RW backup support
SRD-1630DC : PTZ control via coaxial cable
Video (H.264) / Audio (ADPCM)
