Alpine CDA-9852RB Owner's Manual

Rds mp3/wma cd receiver
Hide thumbs Also See for CDA-9852RB:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/
PARA USO EN AUTOMÓVILES/SOLO PER L'UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK
RDS MP3/WMA CD Receiver
ALPINE ELECTRONICS MARKETING, INC.
1-1-8 Nishi Gotanda,
Shinagawa-ku,
Tokyo 141-0031, Japan
Phone 03-5496-8231
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
777 Supertest Road, Toronto,
Ontario M3J 2M9, Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
Dalian Dongtai Colour Printing Technology Co., Ltd.
No.24 Liaohexisan Road, Dalian Economic&Technical
Development Zone, China
CDA-9854R
CDA-9852RB
CDA-9852RR
• OWNER'S MANUAL
Please read before using this equipment.
• BEDIENUNGSANLEITUNG
Lesen Sie diese Bedienungsanleitung bitte vor
Gebrauch des Gerätes.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
• ISTRUZIONI PER L 'USO
Si prega di leggere prima di utilizzare il
attrezzatura.
• ANVÄNDARHANDLEDNING
Innan du använder utrustningen bör du läsa igenom
denna användarhandledning.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Phone 03-8787-1200
ALPINE ELECTRONICS GmbH
Frankfurter Ring 117, 80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway, Coventry CV4 9TW, U.K.
Phone 0870-33 33 763
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. Paris Nord Il,
B.P. 50016, 95945 Roissy Charles de Gaulle
Cedex, France
Phone 01-48638989
R
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
ALPINE ELECTRONICS (BENELUX) GmbH
Leuvensesteenweg 510-B6,
1930 Zaventem, Belgium
Phone 02-725-13 15
Designed by ALPINE Japan
Printed in China (Y)
68-04123Z53-C
EN
DE
FR
ES
IT
SE

Advertisement

Table of Contents
loading

Related Manuals for Alpine CDA-9852RB

Summary of Contents for Alpine CDA-9852RB

  • Page 1 • ANVÄNDARHANDLEDNING Innan du använder utrustningen bör du läsa igenom denna användarhandledning. ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ITALIA S.p.A. 1-1-8 Nishi Gotanda, 161-165 Princes Highway, Hallam Viale C. Colombo 8, 20090 Trezzano Shinagawa-ku,...

  • Page 2: Table Of Contents

    ENGLISH Contents File/Folder Name Search (concerning MP3/WMA) ......12 Quick Search ........... 12 Operating Instructions About MP3/WMA .......... 13 Sound Setting WARNING Adjusting Bass/Treble/Balance (Between Left and Right)/Fader (Between Front and Rear)/ WARNING ..........3 Defeat ............14 CAUTION ..........3 Setting the Bass Control .........
  • Page 3 iPod™ (Optional) Playback ............20 Searching for a desired Song ......20 Searching by Playlist ........20 Searching by artist name ......21 Searching by album name ......21 Random Play Shuffle (M.I.X.) ....... 21 Repeat Play ............. 22 Displaying the Text ......... 22 Changer (Optional) Controlling CD Changer (Optional) ....

  • Page 4: Operating Instructions

    HALT USE IMMEDIATELY IF A PROBLEM APPEARS. or death. Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Centre for repairing. DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.
  • Page 5 We recommend not using these accessories on discs played in Alpine Centre Hole Centre Hole CD players.
  • Page 6 On handling Compact Discs (CD/CD-R/CD-RW) • Do not touch the surface. • Do not expose the disc to direct sunlight. • Do not affix stickers or labels. • Clean the disc when it is dusty. • Make sure that there are no bumps around the disc. •...

  • Page 7: Getting Started

    To close the front panel, press the left side until it locks as Getting Started shown in the figure below. SOURCE/ (OPEN) POWER Rotary encoder Grasp the front panel firmly, slide to the left , then pull to remove. Turning Power On and Off Press SOURCE/POWER to turn on the unit.

  • Page 8: Initial System Start-Up

    The CDA-9854R/CDA-9852RB/CDA-9852RR can be F1 (FM1) F2 (FM2) F3 (FM3) F1 (FM1) controlled with an optional Alpine remote control. For details, consult your Alpine dealer. Press TUNE/A.ME to select the tuning mode. Point the optional remote control transmitter at the remote control sensor.

  • Page 9: Automatic Memory Of Station Presets

    • If the “FUNC” indicator is illuminated, turn off the indicator by pressing FUNC., then you can perform the operation. Automatic Memory of Station Presets Rotary MENU FUNC. encoder Press BAND repeatedly until the desired radio band is displayed. Press and hold TUNE/A.ME for at least 2 seconds. The frequency on the display continues to change while the automatic memory is in progress.

  • Page 10: Receiving Rds Regional (Local) Stations

    Make sure that the “FUNC” indicator light goes out, Setting PTY31 (Emergency Broadcast) then press the preset button in which your desired RDS station is preset. reception If the preset station's signal is weak, the unit automatically searches and tunes to a stronger station in the AF Turn PTY31 (Emergency Broadcast) reception ON/OFF.

  • Page 11: Pty (Programme Type) Tuning

    • The receiver is equipped with the EON (Enhanced Other Networks) PTY (Programme Type) Tuning function in order to keep track of additional alternate frequencies to the AF list. The “EON” indicator lights up while an RDS EON station is being received. If the station being received does not Press FUNC.

  • Page 12: Cd/Mp3/Wma

    • If the CD does not eject, press and hold for at least 2 seconds. CD/MP3/WMA • The CD-player can play discs containing audio data, MP3 data and WMA data. • A WMA format file that is protected by DRM (Digital Rights Management) cannot be played back on this unit.

  • Page 13: Random Play)

    • If a 12-disc CD changer is connected: • Press and hold for at least 2 seconds in the search mode to In CD changer mode, press FUNC. twice to illuminate the “FUNC” cancel. Or, the search mode will be cancelled when an operation has indicator, and go to the step above within 10 seconds.

  • Page 14: About Mp3/Wma

    Producing MP3/WMA discs • Press and hold for at least 2 seconds in the search mode to cancel. Or, the search mode will be cancelled when an operation has MP3/WMA files are prepared, then written to a CD-R or CD-RW not been performed in 10 seconds.

  • Page 15: Sound Setting

    Terminology Sound Setting Bit rate This is the “sound” compression rate specified for encoding. The higher the bit rate, the higher the sound quality, but also the larger Rotary encoder SOURCE/POWER BAND MENU the files. Sampling rate This value shows how many times per second the data is sampled (recorded).

  • Page 16: Setting The Bass Control

    Bass level indicator’s display Setting the Bass Control Bass level is usually displayed. You can change the Bass Frequency emphasis to create your own tonal preference. Press MENU to select the BASS ENGINE mode, then press MODE. BASS ENGINE SETUP RETURN (OFF) BASS ENGINE Press...

  • Page 17: Turning Loudness On/Off

    Turning Loudness On/Off Other Functions Loudness introduces a special low- and high-frequency emphasis at low listening levels. This compensates for the ear's decreased sensitivity to bass and treble sound. Press and hold MODE for at least 2 seconds to activate or deactivate the loudness mode.

  • Page 18: Setup

    About the indication display SETUP When displaying Text, the following indicators are lit according to the mode. You can flexibly customize the unit to suit your own preferences and usage. Choose the SETUP menu from Sound Customizing, Visual Customizing, etc., to select your desired setting. BAND Rotary encoder SOURCE/POWOR...

  • Page 19: Subwoofer On And Off

    Subwoofer On and Off Demonstration SUBW ON (Initial setting) / SUBW OFF DEMO ON / DEMO OFF (Initial setting) When the subwoofer is on, perform the steps below to adjust the This unit has a demonstration feature for the display. subwoofer output level.

  • Page 20: External Device

    D-AUX ON / D-AUX OFF (Initial setting) POWER IC OFF : Use this mode when the front and rear pre- When an ALPINE Ai-NET compatible digital audio processor and a amplifier of the unit are used to drive an DVD player (DVE-5207) not compatible with Ai-NET are connected, external amplifier connected to the speakers.

  • Page 21: Ipod™ (Optional)

    Each press changes the search mode. CDA-9854R/CDA-9852RB/CDA-9852RR, when connected to an The search mode is automatically changed to the PLAYLIST optional ALPINE Interface Adapter for iPod™ (KCA-420i). While search mode 4 seconds after PLAYLIST has been selected. connected to the CDA-9854R/CDA-9852RB/...

  • Page 22: Searching By Artist Name

    , press to change The Shuffle function of the iPod is displayed as M.I.X. on the to the album search mode of the selected artist. CDA-9854R/CDA-9852RB/CDA-9852RR. Turn the Rotary encoder within 10 seconds to select an Shuffle Albums: album. Select an album randomly in the iPod, and plays back the songs 3 Press MODE to play back all songs of the selected of the album in sequential order.

  • Page 23: Repeat Play

    Therefore, a maximum of 250 characters is recommended. The maximum number of characters for the head unit is 64 (64 byte). • Some characters may not be correctly displayed. • “NO SUPPORT” is displayed when text information is not compatible with the CDA-9854R/CDA-9852RB/CDA-9852RR.

  • Page 24: Changer (Optional)

    An optional 6-disc or 12-disc CD Changer may be connected to this unit if it is Ai-NET compatible. With a CD Changer connected to the Ai- Alpine's Ai-NET system will support up to 6 CD Changers. When NET input of this unit, the CD Changer will be controllable from this operating two or more changers, the KCA-400C (Multi-Changer unit.

  • Page 25: Information

    - Allow enough time for the condensation to evaporate (about 1 does not start to play or eject the disc. hour). - Remove the disc by following these steps: Press the button again for at least 2 seconds. If the disc still does not eject, consult your Alpine dealer.

  • Page 26: Indication For Ipod Mode

    • No magazine is loaded into the CD Changer. switch (refer to page 7) and press again. - Insert a magazine. If the disc still cannot be ejected, consult your Alpine dealer. • No indicated disc. • A copy-protected WMA file was played back. - Choose another disc.

  • Page 27: Specifications

    CHASSIS SIZE Specifications Width 178 mm (7") Height 50 mm (2") FM TUNER SECTION Depth 162 mm (6-3/8") Tuning Range 87.5 – 108.0 MHz NOSEPIECE SIZE Mono Usable Sensitivity 0.7 µV Alternate Channel Selectivity 80 dB Width 170 mm (6-11/16") Signal-to-Noise Ratio 65 dB Height...

  • Page 28: Warning

    Failure to do so may result in damage to the unit and/or SHIFT LEVER. the vehicle. When in doubt, consult your Alpine dealer. • The CDA-9854R/CDA-9852RB/CDA-9852RR uses female RCA- Doing so may obstruct forward vision or hamper movement etc.

  • Page 29: Installation

    When you install this unit in your car, do not remove the hex bolt onto the rear panel of the CDA-9854R/ detachable front panel. CDA-9852RB/CDA-9852RR and put the Rubber Cap If the detachable front panel is removed during installation, you on the hex bolt. If your vehicle does not have the...
  • Page 30 <JAPANESE CAR> Face Plate Screws (M5 × 8) (Included) this unit Mounting Bracket...

  • Page 31: Connections

    CDA-9854R only) Ai-NET CD Changer (Sold Separately) ∗1 EQ/DIV NORM Speakers Rear Left Amplifier Rear Right Front Left Amplifier (CDA-9854R only) Front Right Subwoofers (CDA-9852RB/ Amplifier CDA-9852RR is Front or Subwoofers) The label is attached or the bottom of the unit.
  • Page 32 • Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.
  • Page 33 CD-TEXT. Der CHA-1214 ist ein Ai-NET-Modell für 12 CDs. Der M-Bus-kompatible CHM-S630 ist ein superkompakter Wechsler für 6 CDs mit CD-R/RW-Wiedergabefunktion. Changeurs de CD Alpine : vous avez le choix! Plus de sélections musicales, plus de souplesse, plus de confort.
