User's Manual
2 x 7 BAND
DIGAN2.7
DIGITAL EQUALIZER
R
LTO
www.altoproaudio.com
Version 1.0 August 2005
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIGAN2.7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alto DIGAN2.7

Summary of Contents for Alto DIGAN2.7

  • Page 1 User's Manual 2 x 7 BAND DIGAN2.7 DIGITAL EQUALIZER www.altoproaudio.com Version 1.0 August 2005 English...
  • Page 2 SAFETY RELATED SYMBOLS Fuse To prevent fire and damage to the product, use only the recommended fuse type as indicated in this CAUTION manual. Do not short-circuit the fuse holder. Before RISK OF ELECTRIC SHOCK DO NOT OPEN replacing the fuse, make sure that the product is OFF and disconnected from the AC outlet.
  • Page 3 LTO DIGAN2.7 is the result of many hours of listening and tests involving common people, area experts, musicians and technicians.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS INTRODUCTION ............................4 FEATURES .............................4 CONTROL ELEMENTS .........................4 3.1 The Front Panel 3.2 The Rear Panel 4. INSTALLATION AND CONNECTION.....................5 4.1 Mains Connection 4.2 Audio Connection OPERATION OVERVIEW ........................7 5.1 Modify the parameters 5.2 Store preset 5.3 Bypass mode 5.4 Link mode 5.5 Select preset fast...

  • Page 5: Introduction

    USB control interface for easy operating with PC editor. Balanced 1/4 TRS jacks. ” 3. CONTROL ELEMENTS 3. CONTROL ELEMENTS 3.1 The Front Panel (10)(9) (7)(8) DRCE TONE DIGAN2.30 DIGAN2.7 Digital Equalizer Digital Equalizer BYPASS POWER 12K5 12K5 LINK STORE (12) (11)

  • Page 6: The Rear Panel

    LTO DIGAN2.7. In this way you can interface your DIGAN2.7 in several different ways without experiencing any noise or signal loss. You can use your DIGAN2.7 with single instruments using the mixer's main insert or on "in-line" between a mixing console's output and a power amplifier.

  • Page 7: Operation Overview

    - USB Connection 5. OPERATION OVERVIEW 5. OPERATION OVERVIEW Switching on the DIGAN2.7, the last selected preset and settings will be loaded, the number of last preset will appear on the display. 5.1 Modify the parameters Select one of the presets using UP/DOWN keys.

  • Page 8: Store Preset

    all blinking, then you can adjust the gain value of all these selected bands simultaneously via UP/DOWN keys. when Release Edit Group (see 6.1) is set ON, if you want to modify the others frequency bands, select it, and adjust the gain value via UP/DOWN keys separately, it doesn't affect the frequency bands, which has been selected and modified before.

  • Page 9: Reset Mode

    DIGAN EDITOR icon in the Windows PROGRAMS menu. Select NEW from the FILE menu, then DIGAN2.7 and click OK, now select ON LINE from ACTION menu and the PC will scan its USB port to verify the DIGAN2.7 unit is correctly connected. The NETWORK SCAN window should show the system...
  • Page 10 a. Main menu - Load Preset: This function allows to load one of the 100 available presets, the first 30 (0-29) presets are factory configured presets, the presets (30-99) are user's programmable presets. - Save Preset: You can store the new preset into one of user presets (30-99). - Bypass: When you click BYPASS, only Load and Save preset functions are activated in the main menu, all the rest functions are disabled.

  • Page 11: Upload Or Download

    DIGAN2.7 unit, or your DIGAN2.7 can't be recognized by your computer. To update your system in DIGAN2.7, do the following: a. Turn on DIGAN2.7 while it is not connected with PC, then press 12.5k of channel B and BYPASS key at the same time to enter Update mode.

  • Page 12: Operation Flow Chart

    8. Operation Flow Chart Operation Flow Chart UP/DOWN Preset Start 0~99 STORE UP/DOWN STORE LED Display Preset user Save Preset (Blinking) location 30~99 LINK(EXIT) LINK(EXIT) LINK(EXIT) Copy Channel A to Channel B (Mirror A and Channel B key disable) LINK(EXIT) BAND SELECT Band select 0~6: Channel A Adjust Gain Value...

  • Page 13: Technical Specification

    9. TECHNICAL SPECIFICATION 9. TECHNICAL SPECIFICATION Band System parametric 2 7 bands,4/3octave Bandwidth 20Hz-20kHz THD+N% <0.015%, Analog In to Analog Out Signal to noise ratio >90dB A-Weighted, Analog In to Analog Out Input gain +/-12dB Output gain +/-6dB Preset Factory preset: 30 , User preset: 70 Inputs Input section Two 1/4"...

  • Page 14: Warranty

    10. WARRANTY 10. WARRANTY 1. WARRANTY REGISTRATION CARD To obtain Warranty Service, the buyer should first fill out and return the enclosed Warranty Registration Card within 10 days of the Purchase Date. All the information presented in this Warranty Registration Card gives the manufacturer a better understanding of the sales status, so as to purport a more effective and efficient after-sales warranty service.
  • Page 15 No. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151, Taiwan http://www.altoproaudio.com Tel: 886-4-22313737 email: alto@altoproaudio.com Fax: 886-4-22346757 All rights reserved to ALTO. All features and content might be changed without prior notice. Any photocopy, translation, or reproduction of part of this manual without written permission is forbidden. Copyright 2005 SEIKAKU GROUP NF02233-1.0...
