Alto CONTROL30 User Manual

15+15 band digital equalizer
Hide thumbs Also See for CONTROL30:
Table of Contents

Advertisement

Quick Links

User's Manual
15+15 Band
CONTROL30
Digital Equalizer
R
LTO
www.altoproaudio.com
Version 2.3 September 2005
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CONTROL30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alto CONTROL30

Summary of Contents for Alto CONTROL30

  • Page 1 User's Manual 15+15 Band CONTROL30 Digital Equalizer www.altoproaudio.com Version 2.3 September 2005 English...
  • Page 2 SAFETY RELATED SYMBOLS Fuse To prevent fire and damage to the product, use only the recommended fuse type as indicated in this CAUTION manual. Do not short-circuit the fuse holder. Before RISK OF ELECTRIC SHOCK DO NOT OPEN replacing the fuse, make sure that the product is OFF and disconnected from the AC outlet.
  • Page 3 LTO CONTROL30 is the result of many hours of listening and tests involving common people, area experts, musicians and technicians. The results of this effort is a DSP hi-performance equalizer that can be used in applica- tions as musical performances, installation and sound reinforcement.

  • Page 4: Table Of Contents

    4.1. Power Up and Audio Connections a. Audio Connections b. Power Up Setting 4.2. Analog a. Levels Setting 4.3. Installation a. Mono Use of CONTROL30 b. Standard Use c. Application Examples -line Instrument -Mixer 4.4. Operational Overview 5. PRESET FUNCTIONS DESCRIPTION....................10 5.1.

  • Page 5: Introduction

    LTO CONTROL30 is equipped with two powerful and separate configurable DSP channels, allowing to use up to 30 parametric EQ filters in order to obtain the desired sound and timbre out of the musical signals. CONTROL30 is a versatile and very powerful machine...also don't forget to check our 60 factory presets, they will surprise you...

  • Page 6: Analog Levels

    All connections have been made correctly. The volume controls of the amplifier or mixer are turned down. Insert the Power plug into the POWER input on the rear panel of the CONTROL30 and plug the power cord into an AC outlet.

  • Page 7: Analog

    Standard Use The CONTROL30 may be placed almost anywhere: on a table, on top of an amp, next to a mixing console. If it will be on furniture, check the rubber feet provided to the bottom of the unit. Make sure to place the CONTROL30 away from other audio equipment that may induce fields and away from the signal wiring.

  • Page 8: Mixer

    POWER In the above figure it describes the situation in which you want to apply the CONTROL30 to a couple of chan- nels arriving to a mixing console, in order to apply the desired dynamic process to single instrument's signals;...
  • Page 9 To Load a Preset: Select "Load Preset" using UP/DOWN buttons. Press ENTER button to access the further sub-menu. Select the chosen preset using UP/DOWN buttons. Press ENTER to load the preset or press button if you decide not to load the preset. Once terminated the sequence above, on the display will appear the name of the selected preset and the sys- tem will go back to the main menu.
  • Page 10 This is a digital bypass and the input signal is anyway converted digitally before being sent to the outputs. When the CONTROL30 is in this mode (Bypass LED (5) = ON), all the buttons except the" bypass" button are disabled.

  • Page 11: Preset Functions Description

    5. PRESET FUNCTION DESCRIPTIONS 5.1. EQ Presets a. Flat This program allows the audio signal to cross the CONTROL30 unmodified. b. Bass Debug Bass debug is a program particularly suitable to clean recordings which have an exaggerate bass equalization in the 100 Hz area.

  • Page 12: Brilliant

    d. Brilliant This preset 'moves on' music and gives vitality to 'slow' recordings. The main EQs are centered in the 100 Hz, 1 kHz and 10 kHz area. The boost reaches almost 10 dB in the high end giving more definition to recordings which are poor in high band energy.

  • Page 13: Percussion

    The CONTROL30 makes use of modern digital DSP techniques to recreate this useful filter (the loudness curve improves the listening experience at low volumes and into noisy environments) without analog circuit complexity.

  • Page 14: Soft

    i. Soft What is worse than a beautiful and super dynamic recording mistreated by a too brilliant and harsh mastering and/or equalization? If you thought to certain black/disco music of the '70/'80, you are plain right. This EQ will complement some great recordings by, say, Earth Wind & Fire as if it was tailored on. As a matter of fact, it is.

  • Page 15: Functional Data

    Your ideal sound has lots of punch and impact? Your system is a bit shy on low ends, but otherwise linear? Would you like more 'guts' out of a good pop disc? Try this, it could be the answer. On big systems with high power handling and already well capable in the low end, this kind of reinforcement could be like an earthquake.
  • Page 16 Brilliant: Preset 04/Preset 14/Preset 24/Preset 34 Gain [dB] Frequency 630 1000 1600 2500 4000 6300 10000 16000 [Hz] Bandwidth 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 [Oct] Hi Definition: Preset 05/Preset 15/Preset 25/Preset 35 Gain [dB] Frequency 630 1000 1600 2500 4000 6300 10000 16000...
  • Page 17 Super Boost: Preset 10/Preset 20/Preset 30/Preset 40 Gain [dB] Frequency 630 1000 1600 2500 4000 6300 10000 16000 [Hz] Bandwidth 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 0.65 [Oct] Graphical / Parametric 1x30 Mono Flat: Preset 41/Preset 51 Gain [dB] Frequency...
  • Page 18 Gain [dB] Frequency 800 1000 1250 1600 2000 2500 3150 4000 5000 6300 8000 10000 12500 16000 [Hz] Bandwidth 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 [Oct] Brilliant: Preset 44/Preset 54 Gain [dB] Frequency 31.5 [Hz]...
  • Page 19 Gain [dB] Frequency 800 1000 1250 1600 2000 2500 3150 4000 5000 6300 8000 10000 12500 16000 [Hz] Bandwidth 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 [Oct] Percussion: Preset 47/Preset 57 Gain [dB] -1.5 -0.5 -0.5...
  • Page 20 Gain [dB] Frequency 800 1000 1250 1600 2000 2500 3150 4000 5000 6300 8000 10000 12500 16000 [Hz] Bandwidth 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 0.33 [Oct] Virtual _ Sub: Preset 50/ Preset 60 Gain [dB] Frequency 31.5...

  • Page 21: Block Diagrams

    b. Block Diagrams EQ Param. 2 15 Mono - EDIT MENU Init Up/Down Enter/Esc Channel L / R Enter/Esc Enter/Esc Enter/Esc Equalizer Par Filter 01 Gain -15 / +15dB; 0.5dB Frequency 20Hz/20KHz; 1/12 Oct Bandwidth 0.05/3 Oct; 0.05 Oct Par Filter 02 Gain -15 / +15dB;...
  • Page 22 EQ Param. 2 15 Stereo - EDIT MENU Init Enter/Esc L+R (Locked) Channel Up/Down Enter/Esc Enter/Esc Enter/Esc Equalizer Par Filter 01 Gain -15 / +15dB; 0.5dB Frequency 20Hz/20KHz; 1/12 Oct Bandwidth 0.05/3 Oct; 0.05 Oct Par Filter 02 Gain -15 / +15dB; 0.5dB Frequency 20Hz/20KHz;...
  • Page 23 EQ Param. 1 30 Mono - EDIT MENU Init Enter/Esc Channel Mono (Locked) Up/Down Enter/Esc Enter/Esc Enter/Esc Equalizer Par Filter 01 -15 / +15dB; 0.5dB Gain Frequency 20Hz/20KHz; 1/12 Oct Bandwidth 0.05/3 Oct; 0.05 Oct -15 / +15dB; 0.5dB Par Filter 02 Gain Frequency 20Hz/20KHz;...
  • Page 24 EQ Graph. 1 30 Mono - EDIT MENU Init Enter/Esc Channel Mono (Locked) Enter/Esc Up/Down Enter/Esc Enter/Esc Equalizer Par Filter 01 Gain -15 / +15dB; 0.5dB Par Filter 02 Gain -15 / +15dB; 0.5dB Up/Down Up/Down Par Filter 30 Gain -15 / +15dB;...
  • Page 25 EQ Graph. 2 15 Stereo - EDIT MENU Init Enter/Esc L+R (Locked) Channel Enter/Esc Up/Down Enter/Esc Enter/Esc Equalizer -15 / +15dB; 0.5dB Par Filter 01 Gain -15 / +15dB; 0.5dB Par Filter 02 Gain Up/Down Up/Down -15 / +15dB; 0.5dB Par Filter 15 Gain Frequency...
  • Page 26 EQ Graph. 2 15 Mono - EDIT MENU Init Up/Down Enter/Esc L / R Channel Enter/Esc Up/Down Enter/Esc Enter/Esc Equalizer Par Filter 01 Gain -15 / +15dB; 0.5dB Par Filter 02 Gain -15 / +15dB; 0.5dB Up/Down Up/Down Par Filter 15 Gain -15 / +15dB;...
  • Page 27 Utility Menu Up/Down Enter/Esc Preset 1,...,60 Factory Load Preset Preset 61,...,124 User Up/Down Up/Down Enter Enter/Esc Store Preset Preset 61,...,124 Edit Name (Char n 1) Enter Up/Down Edit Name (Char n 2) Enter Up/Down Edit Name (Char n 3) Up/Down Enter Up/Down Enter/Esc...

  • Page 28: Midi 2

    Dual Mono 2 15 Bands Graphic / Parametric EQ Block Diagram Volume High P Delay In L Filt 01 Filt 02 Filt 15 Low P Out L In R Out R High P Delay Filt 01 Filt 02 Filt 15 Low P Volume Mono 1 30 Bands Graphic / Parametric EQ Block Diagram...
  • Page 29 Control Change (Max. Frequency of Changes: 120 BPM) MIDI commands will be executed from control30 only, if the status of the device is on the "Top Ring" or utility menu and if the MIDI channel is set properly. 1. System executes MIDI commands also when in bypass.
  • Page 30 b. P2 15M Bank = 0 selects Gain, possible values are 0, 60; -15, +15dB step = 0.5dB Channel 2 Bank = 1 selects Gain, possible values are 0, 60; -15, +15dB step = 0.5dB Channel 1 Bank = 2 selects Gain, possible values are 0, 120; 20Hz,...,20KHz step = 1/12 Oct Channel 2 Bank = 3 selects Gain, possible values are 0, 120;...

  • Page 31: Technical Specifications

    6. TECHNICAL SPECIFICATIONS Analog Input Section Inputs Analog variable gain, 2 XLR-F electronically balanced Input Impedance 44 kOhms Max. input Level 15 dBu (4.4V RMS) Sensitivity -22 dBu (63mV RMS) Analog Output Section Outputs Analog variable gain, 2 XLR-M electronically balanced Output Impedance <150 Ohms Max.

  • Page 32: Warranty

    7. WARRANTY 1. WARRANTY REGISTRATION CARD To obtain Warranty Service, the buyer should first fill out and return the enclosed Warranty Registration Card within 10 days of the Purchase Date. All the information presented in this Warranty Registration Card gives the manufacturer a better understanding of the sales status, so as to purport a more effective and efficient after-sales warranty service.
  • Page 33 No. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151 Taiwan http://www.altoproaudio.com Tel: 886-4-22313737 email: alto@altoproaudio.com Fax: 886-4-22346757 All rights reserved to ALTO. All features and content might be changed without prior notice. Any photocopy, translation, or reproduction of part of this manual without written permission is forbidden. Copyright...
