Clean/Overdrive
1. Clean/Overdrive Switch - LED on indicates Clean Channel -- Led off indicates OD Channel
2. Overdrive 1 / Overdrive 2 Switch
3. Solo Boost Switch
- LED on indicates Solo Volume control activated -- OD2 also is activated
Footswitch connections -- Two 1/4" TRS plugs marked A and B with a DIN connector at the box end on a 25' cable
New Quickrods in 2013 are shipped with a 4 button footswitch which includes the mode switch, which allows
you to switch between two gears, if the front panel switch is set to 1st gear you can switch between
1st and 2nd gears, if the front panel switch is set to 3rd gear you can switch between 2nd and 3rd,
you cannot switch between 1st and 3rd.
This 4 button switch will also work on all Streetrod amps and older Quickrods and Promods after serial number 460.
These are available for purchase from our online store.
are the number of amps produced at that time.
For instance if your serial number is QR109996 this would be a Quickrod 100 watt built in 2009 and was the 996 amp built.
Please Check the Voltage selector on the back for proper Voltage selection! Please check the volume
control levels on all channels before powering on. After you plug in the amplifier, Flip the power switch
down to turn on. Wait for a minute for the tubes to warm, then turn on the Standby switch. The Amp is ready
This Amplifier will get VERY loud. Remember you only have one set of ears!
against failure of materials and workmanship. No other warranty applies. Tubes, transformers and speakers are
warranted for a period of ninety days. This warranty applies only if the amplifier has not been damaged by
accident, misuse or as a result of repair or modification. Splawn reserves the right to make any design changes
without notice or obligation to incorporate these changes in products previously purchased.
All warranty repairs are to be done by Splawn Amplification.
Overdrive 1/ Overdrive 2
Quickrod & ProMod Footswitch Operation
- LED on indicates OD2 gain boost -- LED off indicates OD1
WARNING:
for explosive guitar sounds!
Dimensions
29" Wide, 11.5" Tall, 8.5" Deep, 50lbs
Limited Lifetime Warranty.
New Amplifiers are lifetime warranted to the original purchaser
Splawn Amplification
115 South Gaston St.
Dallas, NC 28034
Solo Boost
