  • Page 1 T5200 User’s Manual...
  • Page 2 South 801 Stevens Street, Spokane, Washington 99204. Itronix Corporation reserves the right to revise the manual and make periodic changes to the content without a direct or inferred obligation to Itronix to notify any person of such revision or changes. Itronix Corporation does not assume responsibility for the use of this manual, nor for any patent infringements or other rights or third parties who may use the manual.
  • Page 3 Before using this manual and the product it describes, read the Microsoft’s End User’s License Agreement and the safety information. The Itronix Corporation Model T5200 Wireless Mobile Workstation was found to be compliant with FCC RF exposure requirements for the uncontrolled/general population exposure environment with these operating conditions.
  • Page 4 • Compliance Statement for Canada...
  • Page 6 • • • •...
  • Page 7 Unpacking Your System 3 The First Time. . . 4 Installing the Battery 4 Connecting the AC Adapter 5 Turning the T5200 Computer On and Off 6 Things You Need to Do at Start-up 7 Start-up Problems? 9 Password Security 10...

  • Page 8: Table Of Contents

    Connecting to a Desktop Computer 38 Installing Windows ActiveSync® on Your Desktop 38 Establishing a Connection 39 Copying and Converting Files 40 Printing Files from the T5200 Computer 41 PC Cards 41 Introduction 44 Practical Battery Tips 44 Low Battery Indicators 45...
  • Page 9 Introduction 52 Care and Cleaning Storing Your T5200 Computer 53 Introduction 56 What to Try First 56 Operational Problems 57 Battery Problems 58 Display Problems 59 Keyboard Problems 60 Touch Screen Problems 60 Radio Problems 61 Desktop Communication Problems 62...
  • Page 10 Physical Features Display 74 Processor and Memory 74 Input/Output 75 Power 75 Communications 76 Modems 76 Telephone Line Connector 76 Introduction Power On/Off Function Keys Primary Keys Numeric Keys Customizing Keyboard Settings 82 Adjusting the Key Repeat Rate 82 Adjusting Audio Feedback 83 Compliance Statements Warnings and Cautions 93...
  • Page 11 Unpacking Your System 3 Installing the Battery 4 Connecting the AC Adapter 5 Turning the T5200 Computer On and Off 6 Things You Need to Do at Start-up 7 Start-up Problems? 9...
  • Page 12 You can also lose data if the battery is removed for more than 10 minutes. • Use the stylus that comes with your T5200 computer. Don’t use sharp implements such as keys, pens or mechanical pencils to touch the screen because they can damage the screen.
  • Page 13 The T5200 computer is a rugged handheld computer that uses the Windows CE operating system. The T5200 computer is smaller than a ruggedized laptop, but has many of the same features. It is weather-sealed, resists bumps and drops, can connect with a variety of peripherals and host computers, and is capable of communicating over landline and wireless networks.
  • Page 14 Connecting the AC Adapter to the computer to charge the battery Make sure the T5200 computer is sheltered (away from liquids, dirt, etc..) when you install the Lithium Ion battery; the computer is not weather sealed until the battery is properly installed. The battery should be fully charged before you operate the unit on battery power.
  • Page 15 2 Insert the appropriate end of the AC Adapter cable into the power port on the back of the computer. 3 The T5200 computer will power on and start charging the battery automatically. The battery charging icon appears on the taskbar until the battery is fully charged, then the fully charged icon appears.
  • Page 16 • Press the POWER button once, and then give the system time to respond If the computer does not power on, press and hold the POWER button for at least ten seconds and then release the button to restart the computer. •...
  • Page 17 When you turn on your T5200 computer for the first time, you need to perform these simple tasks: • Calibrate the touch screen • Adjust the screen to your own personal viewing preference • Set the date and time • Enter User Information Use the stylus that comes with your T5200 computer.
  • Page 18 You can toggle the backlight on if you need additional light to view the screen. To conserve battery power, the backlight is defaulted to switch off automatically after one minute of continuous idle time. You can also adjust the display contrast for better viewing. Use the following keys to make adjustments: Toggle the backlight on and off SHIFT...
  • Page 19 “Display Owner Identification” in the At Power On area. You can also add more information in the Notes tab. If your T5200 computer does not operate, try these solutions. • Check to make sure the battery is installed and charged properly •...
  • Page 20 • Verify that the LED light on the AC Adapter is on Section 7, “Troubleshooting,” lists additional solutions you can try. If you are using the T5200 computer for the first time, enter the default password provided by your company.
  • Page 21 ID and the computer’s serial number. This information is printed on the bottom of the T5200 computer. If you are registering with the ARDIS wireless network or the BellSouth Wireless Data MOBITEX network, your Radio Modem ID (RID) will be printed on a label as shown below.
  • Page 22 If you are registering with a Cellular provider for data service, your modem’s Electronic Serial Number (ESN) will be printed on a label as shown below. If you are registering with a Cellular provider for CDPD service, your modem’s Equipment Identifier (EID) will be printed on a label as shown below.
  • Page 23 Standard Hardware 15 Standard Software (Speaker Phone) 16 Basic Keys 17...

  • Page 24: Keyboard

    The following diagrams and descriptions provide an overview of the T5200 computer. Optional PC Card Door and Socket Display Antenna Microphone Keyboard Speaker Battery 9-Pin Serial Port IR Port RJ-11 Port Headset Port Power Port...
  • Page 25 Keyboard The keyboard is environmentally sealed and each key can provide audio feedback when pressed. PC Card Door and Socket If your T5200 computer is equipped with an optional PC Card socket, the PC Card is inserted here. When this door is open, shield the area from all contaminants such as liquids, rain, snow, and dust.
  • Page 26 Section 3, “Customizing Settings.” The standard keyboard for the T5200 computer contains 75 keys that are sealed to protect them from harsh environments. It includes a telephone-type numeric keypad for entering or dialing numbers.
  • Page 27 You can restart the T5200 computer by pressing the POWER button for at least ten seconds and then releasing it; however, restarting your computer while you are running applications or working in Windows CE may cause data loss or corrupt files.
  • Page 28 Darken the display contrast SHIFT Decrease the speaker volume SHIFT Increase the speaker volume SHIFT Toggle the speaker on and off SHIFT Restart the computer POWER for at least 10 sec. key is used in combination with other keys on the SHIFT keyboard to perform special functions.
  • Page 29 Use the stylus that comes with your T5200 computer. Don’t use sharp implements such as keys, pens or mechanical pencils to touch the screen because they can damage the screen. • Slide the stylus out of the slot on the hard handle or from the...
  • Page 30 3 Position and briefly hold the stylus at the center of each crosshair or “target” as it appears on the screen. 4 After you have finished, press to accept the new settings ENTER in the Stylus Properties box to accept all changes.

  • Page 31: Regional Settings 31

    Communications 23 Dialing 24 Display 25, 26 Gray Scale 26 Keyboard 27 Network 27 Owner 28 Password 28 Power 29 Regional Settings 31 Remove Programs 32 Stylus 32 System 33 T5200 Information 34 Volume and Sounds 34...
  • Page 32 You can customize several settings on the T5200 computer to suit your own personal preference. These settings can be modified by using the utilities under Control Panel. This section tells you about these utilities and how to make changes. To access these utilities, tap the Start Menu, choose Settings, choose Control Panel, and then double-tap the appropriate icon.
  • Page 33 Tap the Start Menu, select Settings, Control Panel, and then double-tap the Communications icon. This utility allows you to establish a name for your T5200 com- puter, which is important when connecting to a desktop computer. You can also use this utility to set automatic dialing patterns and...

  • Page 34: Connecting To A Desktop Computer

    Open this dialog box to make any necessary changes when you are connecting to a desktop computer. • Tap the Start Menu, select Settings, Control Panel, and then double-tap the Dialing icon This utility allows you to add and customize the dialing properties when dialing from various locations.
  • Page 35 • Tap the Start Menu, select Settings, Control Panel, and then double-tap the Display icon This utility allows you to change the background that appears on your screen, or the backlight idle time/power saving settings. 1 Tap Browse to locate an image you want to use. If you want the image to cover the entire background, check “Tile image on background.”...
  • Page 36 The Advanced button in the bottom right corner of the Backlight window is grayed-out and does not function. • Tap the Start Menu, select Settings, Control Panel, and then double-tap the Gray Scale icon. This properties box allows you to choose between 4 Level Gray Scale and 16 Level Gray Scale settings.
  • Page 37 • Tap the Start Menu, select Settings, Control Panel, and then double-tap the Keyboard icon. Move the sliders to adjust the key repeat rate. Refer to Appendix C Keyboard Functions for additional information. The Network Configuration box lists the installed hardware devices that enable your computer to connect to the network and the identification process by which you may access data.
  • Page 38 • Tap the Start Menu, select Settings, Control Panel, and then double-tap the Owner icon. Record owner information here, including your name, address, and phone number(s). If you want this information to appear on the screen each time you start your computer, check “Display Owner Identification”...
  • Page 39 Tap the Start Menu, select Settings, Control Panel, and then double-tap the Power icon. The Battery window provides information about the status of your battery. The T5200 computer uses a Lithium Ion battery as the main battery. The T5200 computer uses a super capacitor as the backup battery.
  • Page 40 To conserve battery power, the computer automatically suspends operation after two minutes of continuous idle time. You can change this time by selecting the Power Off tab and then selecting a different time from the list. The system will not suspend while connected to external power, and if suspended will automatically turn on when connected to external power.
  • Page 41 • Tap the Start Menu, select Settings, Control Panel, and then double-tap the Regional Settings icon. If the programs you are using support international settings, this utility allows you to set the way these programs manage numbers, currencies, times, and dates.
  • Page 42 • Tap the Start Menu, select Settings, Control Panel, and then double-tap the Remove Programs icon. This utility enables you to remove programs you no longer need on your computer. Check with your company’s help desk before removing any programs from your system. •...
  • Page 43 This utility provides general information about your Windows CE system and also allows you to adjust unused internal memory on your T5200 computer. The system is preset with the recommended Program Memory and Storage Memory defaults. In general, an increase in Program Memory allows your T5200 computer to run more programs simultaneously, while an increase toward Storage Memory allows for additional data storage.
  • Page 44 • Tap the Start Menu, select Settings, Control Panel, and then double-tap the T5200 Information icon. From this utility, under the Version Tab, you can identify your computers software version, build name, build date and boot version. Under the Configuration Tab you can identify the Serial Number and Configuration String of your unit.
  • Page 45 On the Sound tab, select the events on the Event Name list for sounds that you want to hear. Choose None from the Event Sound list to turn sound off for that event. Select Browse to locate a different sound to use. Different schemes can be saved by selecting Save As...
  • Page 47 ® Installing Windows ActiveSync on Your Desktop 38 Establishing a Connection 39 Copying and Converting Files 40 Printing Files from the T5200 Computer 41...
  • Page 48 This section shows you how to connect your T5200 computer to a desktop computer and how to transfer and print files. ® Windows ActiveSync is a program that resides on your desktop computer with Windows 95/98 or NT installed. It allows you to browse folders, files and install programs on the T5200 computer.
  • Page 49 1 Start Windows ActiveSync on your desktop computer if it is not already running. 2 Turn on your T5200 computer by pressing the POWER button once (if it is on battery power). 3 Insert the 9-pin null modem serial connector into the communi- cations port on your desktop computer, which you selected previously in the setup procedure.
  • Page 50 This connection icon is displayed in the taskbar on both the PC and CE device when the connection is established and services are enabled. The following pop-up window is displayed when the initial connection is made and services are established. Tap Hide to clear ®...
  • Page 51 You can print files that reside on the T5200 computer using ® Windows ActiveSync on your desktop computer. 1 Connect the T5200 computer to your desktop computer and ® start Windows ActiveSync ® 2 In Windows ActiveSync , select the file you want to print.
  • Page 54 The T5200 computer uses a Lithium Ion (Li-ion) battery as the main battery. This section provides some important information about this battery and ways to extend its life. The T5200 computer can be operated on battery power or external power. If a battery is installed, the system automatically starts charging the battery when external power is connected.
  • Page 55 When the battery becomes low, the computer beeps and the low battery icon appears in the taskbar. Double-tapping this icon opens the Power Properties window so you can view the level of battery power. If the battery becomes very low, the computer beeps and a low battery message appears on the screen periodically.
  • Page 56 To conserve battery power, the computer automatically suspends operation after two minutes of continuous idle time. You can change this time by selecting the Power Off tab and then selecting a different time from the list. The system will not suspend while connected to external power even if the box is checked here.
  • Page 57 When operating on battery power, the T5200 computer is equipped with enough internal backup power to maintain memory contents for about ten minutes each time you exchange batteries. You can lose data if you remove the existing battery while the computer is operating on battery power.
  • Page 58 To maintain power and prevent data loss from a low battery, charge the battery daily. Use the AC Adapter that comes with your T5200 computer. You can operate the T5200 computer while the battery is charging. 1 Make sure the battery is installed properly in the T5200 computer.
  • Page 59 Follow these guidelines to maintain performance of the Lithium Ion battery. • Avoid exposing batteries to extremely hot or cold temperatures for long periods. • Charge the battery nightly where the temperature will remain around 70° F (21° C). • Store the batteries within this temperature range: 50 F to 86 C to 30...
  • Page 62 The T5200 computer was designed to withstand rugged and harsh environments. Following the guidelines in this section will help you maintain the condition and performance of your computer. Periodically inspect the computer and accesso- ries for wear, damage, or loose or missing parts. Identifying and correcting potential problems early can help reduce the need to return the unit for service.
  • Page 63 Check all keys to make sure they are working properly. To clean the keyboard, use a solution of mild detergent in water applied to a clean, soft cloth. Make sure the ports are working correctly. Periodically inspect the ports for damage and contamination. If your computer is equipped with a PC Card connector, make sure it is operating correctly by reading from or writing to a PC Card.
  • Page 64 5 Store the unit within the recommended temperature ranges of F to +167 F (-40 C to +75 If you use PC Cards, refer to the manufacturer’s instructions you received with the card for storage and care information. When you turn the computer on after it has been stored for a long time, you may need to restart the system by holding down the POWER button for about ten seconds and then releasing it.
  • Page 66 This section provides some basic solutions to problems you might have while using the T5200 computer or connecting to your desktop computer. If you can’t find a solution here, contact your company’s help desk. If the T5200 computer stops functioning, try this first: •...
  • Page 67 Extend the auto-suspend time from the Start Menu by tapping Settings, Control Panel, and then double-tap the Power icon. Select the Power Off tab and enter a different time from the list. Extending the auto-suspend duration will decrease the battery life on your T5200 computer.
  • Page 68 • The computer will not suspend when it is connected to external power. • If the computer stops responding even after you’ve tried restarting the system, you may need to do a full reset. Performing a full reset erases all data and files in DRAM since the last time you backed up files to a desktop computer, Compact Flash or PC Card.
  • Page 69 When connected and charging, the battery charging icon displays in the taskbar Taskbar Battery charging icon • Turn off the computer whenever you’re not using it • Shorten the time the backlight automatically shuts off • Turn off sound and volume to events you do not need •...
  • Page 70 • Press and hold ALT and then the appropriate key • Enable key clicks and/or adjust the volume To enable key clicks from the Start Menu, tap Settings, Control Panel, and then double-tap the Volume and Sounds icon. To hear audio feedback when you press a key, make sure the “Key Clicks”...
  • Page 71 • Enable a RIM Radio communications session To enable a RIM Radio communication session from the Start Menu, tap Programs, Communication, and Terminal. Double- tap the “Make a New Session” icon to bring up the Session Properties dialogue box. On the Communications Tab name your session, select modem “RIM Radio on COM4”...
  • Page 72 For best RF performance the display should be fully open or fully closed with the antenna in a vertical position. • Make sure the null modem serial cable from the T5200 com- puter is connected to an appropriate serial port on your desktop...
  • Page 73 • Verify both are communicating at the same speed • Check the communications settings on the T5200 computer and your desktop: To check communications settings on the T5200 computer 1 From the Start Menu, select Settings, Control Panel, and then double-tap the Communications icon.
  • Page 74 4 Click OK for new settings to be accepted. 5 1&6 7 6&1 5...
  • Page 75 PC Card Socket 66 Expansion DRAM 66 Expansion Flash (Compact Flash) 66 Radio Modem 67 Vehicle Cradle 67 Vehicle Adapter 70 AC Adapter 71 Stand Alone Battery Charger 72...
  • Page 76 The T5200 computer comes with many built-in features. You can also add options and order many peripherals to expand the capa- bilities of your system. Several accessories are also available for your T5200 computer. This section shows you the options available for your T5200 computer and the peripherals and accessories you can order.
  • Page 77 The T5200 computer has several radio options for networks. These include Bell South Wireless Data (Mobitex), American Mobile/Ardis (DATATAC) and CDPD. Contact your company’s help desk for a current list of the various modem options. The Vehicle Cradle is a vehicle-based docking station designed to safely secure the computer in the vehicle.
  • Page 78 A temperature of 0º to +50º Celsius (32º to +122º Fahrenheit) is recommended when charging batteries with the Vehicle Cradle. Batteries may not charge successfully outside this temperature range. Always remove the unit from the Vehicle Charger at night and store indoors in colder climate areas. 1.
  • Page 79 The Vehicle Cradle is designed with a standard serial port so you can connect external devices such as a printer or modem. Specify COM1 when you select the communications port in your applica- tion. Connect the external device to the serial port on the back of the cradle, and then place the mobile computer onto the vehicle cradle.
  • Page 80 Pull the lever out to turn off Vehicle Cradle charging at the end of each work day to prevent draining the voltage in your vehicle’s battery below starting levels. 1. Insert the Vehicle Adapter’s power cord into the power port on the side of the T5200 computer.
  • Page 81 Adapter is internally protected. It resets automatically if there is a power fault. 1. Insert the appropriate end of the AC Adapter power cord into the power port on the T5200 computer, then insert the other end of the power cord into an electrical wall outlet.
  • Page 82 The Stand Alone Battery Charger is an optional charging device used to charge a Lithium Ion battery. This charger allows you to charge an additional T5200 battery for the mobile computer. The operating temperature for this device is 0º to +50º Celsius (+32º to +122º...
  • Page 83 Modems 76 Telephone Line Connector 76...
  • Page 84 • Length: 9.8 inches • Width: 5.0 inches • Height: 2.25 inches • 7.3-inch, 640x240 pixel resolution • Transflective monochrome; 16-shades of gray • Passive touch screen, pressure sensitive for finger or stylus • Backlight and contrast controls • Philips PR31700 CPU, 32-bit 73.7 MHz MIPS-based RISC processor •...
  • Page 85 • Fully-sealed, 75-key QWERTY keyboard • Passive pen or finger touch screen • Full duplex RS-232, 9-pin “D” serial port • IrDA Level 1 serial port • Sealed headset jack • Built-in RJ-11 phone jack • External power • 5VDC power supply from serial port to power peripherals •...
  • Page 86 • 33.6 Kbps V.34 fax/data wireless modem • ARDIS network (DATATAC) • Bell South Wireless Data network (Mobitex) • CDPD • Built-in RJ-11 jack...
  • Page 87 Adjusting the Key Repeat Rate 82 Adjusting Audio Feedback 83...
  • Page 88 Contact your company’s help desk for a description of key functions if you have a custom keyboard. The keyboard for the T5200 computer is a fully sealed, 75-key QWERTY keyboard. It includes a numeric keypad for entering or dialing numbers.
  • Page 89 key is used in combination with other keys on the SHIFT keyboard to perform special functions. The shift key has been designed as “sticky” key for convenient one-handed opera- tion. Pressing the key once is the same as holding it down until a second key is pressed.
  • Page 90 Toggles the backlight on and off SHIFT Lightens the display SHIFT Darkens the display SHIFT Decreases the speaker volume SHIFT Increases the speaker volume SHIFT Turns off the speaker SHIFT Pressing the key produces upper case alphabetic characters SHIFT and the symbols and functions (such as ) shown above the |¬...
  • Page 91 Cancels the current operation Displays the Windows CE Start menu and works with other keys to shortcut to functions Works with other keys to perform various functions Enters one space SPACE Tells the computer to process the information you ENTER have typed or selected Moves information on the screen up one page PGUP...
  • Page 92 You can adjust the rate at which keys repeat when you hold them down, and you can adjust the sound of key presses. 1 Tap the Start Menu, select Settings, Control Panel, and then double-tap the Keyboard icon (or +K). 2 Move the sliders to adjust the key repeat rate, and then tap OK to save the new settings.
  • Page 93 • Tap the Start Menu, select Settings, Control Panel, and then double-tap the Volume and Sounds icon. Under “Enable clicks & taps for:” you can turn off the audio feedback by clearing the Key Clicks box, or you can adjust the sound of clicks by selecting Loud or Soft.
  • Page 95 END-USER LICENSE AGREEMENT FOR MICROSOFT CE SOFTWARE ADDITIONAL AUTHORIZED UPGRADE SOFTWARE COPIES: 0 IMPORTANT—READ CAREFULLY: This End-User License Agreement (“EULA”) is a legal agreement between you (either an individual or a single entity) and the manufacturer (“Manufacturer”) of the special purpose computing device (“SYSTEM”) you acquired which includes certain Microsoft software product(s) installed on the SYSTEM (“SOFTWARE PRODUCT”...
  • Page 96 copy the SOFTWARE, and you should promptly contact Manufacturer for instructions on return of the unused product(s) for a refund. • Limitations on Reverse Engineering, Decompilation and Disassembly. You may not reverse engineer, decompile, or disassemble the SOFTWARE, except and only to the extent that such activity is expressly permitted by applicable law notwithstanding this limitation.
  • Page 97 • Software Transfer. You may permanently transfer all of your rights under this EULA only as part of a sale or transfer of the SYSTEM, provided you retain no copies, you transfer all of the SOFTWARE (including all component parts, the media, any upgrades or backup copies, this EULA, and if applicable, the Certificate(s) of Authenticity), and the recipient agrees to the terms of this EULA.
  • Page 99 6. LIMITED WARRANTY. Limited Warranty. Manufacturer warrants that the SOFTWARE will perform substantially in accordance with the accompanying written materials for a period of ninety (90) days from the date of receipt. Any implied warranties on the SOFTWARE are limited to ninety (90) days.
  • Page 100 The SOFTWARE and documentation are provided with RESTRICTED RIGHTS. Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 or subparagraphs (c)(1) and (2) of the Commercial Computer Software- Restricted Rights at 48 CFR 52.227-19, as applicable.
  • Page 103 replacing 47 storage and care 49 AC adapter 5, 48 temperatures 44 address, entering personal 28 tips 44 adjusting the double-tap rate 32 troubleshooting 58 adjusting the key repeat rate 26, 27, 82 adjusting the screen 8 ARDIS wireless network 11 audio feedback, adjusting 34, 83 calibrating the touch screen 7, 19 auto-suspend 29, 46...
  • Page 104 28 24, 38 equipment, standard 3 conserving battery power 44 expanding your T5200 computer 66 Control Panel 22 external power 5, 44, 48 converting files 40 vehicle cradle 67 copying files 40–41...
  • Page 105 RAM network 11 recalibrating the touch screen 7, 19 recycling batteries 49 options 66 regulatory information 85 overview of the T5200 computer 14 removing and replacing the battery 47 owner information 28 removing programs 32 restarting the computer 17, 58, 79...
  • Page 106 3 storing your computer 53–54 stylus 19, 32 system information 33 vehicle cradle 67 volume, adjusting 34 T5200 computer cleaning 52 Windows CE 33 connecting to a desktop computer 38 Windows ActiveSync 38–41 expanding with options 66...
