VADDIO CEILINGVIEW HD CCU Installation And User Manual

Camera and Electronic Products for Integrators
C V
C V
E I L I N G
E I L I N G
H i g h D e f i n i t i o n C
H i g h D e f i n i t i o n C
OVERVIEW:
The Vaddio™ CeilingVIEW HD CCU (Figure 1) is a high
definition ceiling Document Camera designed for use with high
definition videoconferencing
presentation applications where image quality and resolution
are critical. The CeilingVIEW HD CCU can be configured for
16:9 HD CCU resolutions of 1080i or 720p when using the
analog component video outputs (Y/Pb/Pr), or with 4:3 standard
definition video with Y/C and composite video outputs.
Equipped with a 10X optical motorized zoom lens and 12X
digital zoom range, the camera has a 120X total zoom
capability. The 1/3" CMOS image sensor has approximately 2-
million pixels and provides precise edge focus. The heart of the
CCU system is its ability to adjust red and blue gain, aperture,
as well as iris and gain of the Camera Module.
Vaddio's active cabling system uses high speed differential signaling (HSDS) for the video signals from the
camera module to the Quick-Connect™ CV HD/SD interface as opposed to baluns. HSDS gives this system
high definition or standard definition video capability, superior video quality over CAT-5 cabling and the ability
to adjust the video signal depending on the length of the cabling used. The EZCamera series cabling system
delivers either high definition or standard definition video up to 400 feet over standard CAT-5 cable. The
Quick-Connect CCU connects directly to the RS-232 port on the Camera Module. RS-232 from an external
device, such as Vaddio's ProductionVIEW HD, or an external control system can be used in-line with
CeilingVIEW HD CCU.
The CeilingVIEW HD CCU is unmatched for price and performance as compared to other ceiling mounted
document cameras available today.
INTENDED USE:
Before operating the CeilingVIEW HD CCU system, please read the entire manual thoroughly. The
CeilingVIEW HD CCU Document Camera was designed, built and tested for use indoors and with the
provided power supply. The use of a power supply other than the one provided or outdoor operation has not
been tested and could damage the electronics and/or create a potentially unsafe operating condition.
SAVE THESE INSTRUCTIONS:
The information contained in this manual will help you install and operate your Vaddio CeilingVIEW HD. If
these instructions are misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and
most pertinent product drawings for the Vaddio product line on the website. These documents can be
downloaded from www.vaddio.com
IMPORTANT SAFEGUARDS:
Read and understand all instructions before using. Do not operate the system if it has been dropped or
damaged. In this case, a Vaddio technician must examine the product before operating. To reduce the risk
of electric shock, do not immerse in water or other liquids and avoid extremely humid conditions.
Use only the power supply (or power supplies) provided with the CeilingVIEW. Use
of any unauthorized power supply will void any and all warranties.
ⓒ2008 Vaddio - CeilingVIEW HD CCU- All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and
pricing are subject to change without notice. Vaddio, CeilingVIEW, EZCamera, Quick-Connect, WallVIEW, EZCable and PowerRite are trademarks of
Vaddio, Inc. All other trademarks are property of their respective owners. Document 341-768 RevA.
I E W ™
I E W ™
e i l i n g M o u n t e d D
e i l i n g M o u n t e d D
codecs, HD monitors
free of charge.
H D C C U
H D C C U
o c u m e n t C a m e r a
o c u m e n t C a m e r a
and
Figure 1: CeilingVIEW CCU (above left);
CeilingVIEW HD Document Camera (above).
Installation and User Guide
S y s t e m w i t h C C
S y s t e m w i t h C C
U
U
