Tripp Lite SmartOnline Owner's Manual

Single-phase 8kva—10kva intelligent true on-line ups systems (rackmount/tower)

Hide thumbs Also See for SmartOnline:

Owner's manual (104 pages)

Owner's manual (16 pages)

Owner's manual (57 pages)

Table Of Contents

Table of Contents

Quick Links

Need help?

Do you have a question about the SmartOnline and is the answer not in the manual?

Questions and answers

Summary of Contents for Tripp Lite SmartOnline

Page 1 Optional Connection Manual Bypass Operation Specifications Operation Storage and Service Warranty and Warranty Registration Español/Français/Ðóññêèé 27/53/79 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support Copyright © 2009 Tripp Lite. All rights reserved. SmartOnline is a trademark of Tripp Lite.
Page 2: Important Safety Warnings
Refer to your local codes for disposal requirements or in the USA only call 1-800-SAV-LEAD or 1-800-8-BATTERY (1-800- 822-8837) or visit www.rbrc.com for recycling information. Tripp Lite offers a complete line of UPS System Replacement Battery Cartridges (R.B.C.).Visit Tripp Lite on the Web at www.tripplite.com/support/battery/index.cfm to locate the specific replacement battery for your UPS.
Page 3: Mounting (Rack)
4U. 2-Post Mounting (Optional) To mount your equipment in a 2-post rack, you must purchase a Tripp Lite 2-Post Rackmount Installation Kit (model: 2POSTRMKITWM, sold separately) for each module installed. See the Installation Kit’s owner’s manual for complete mounting instructions.
Page 4: Mounting (Tower)
Mounting (Tower) Mount all modules in an upright, tower position using included base stands. The user must determine the fitness of hardware and procedures before mounting. The UPS system is shipped with two sets of plastic feet and extensions that can be used to tower mount the UPS’s power module, a battery module and a second battery module (9U total).
Page 5: Features (Rear Panel)
Features (Rear Panel) See page 6 for feature descriptions 8kVA/10kVA Power Module Detachable Power Distribution Unit Battery Module...
Page 6: Connection
Parallel Connector: For UPS communication in parallel. USB Communication Port: The USB port may be used to connect your UPS to a workstation or server. It is used with Tripp Lite software and the included USB cable to monitor and manage the UPS remotely over a network and to automatically save open files and shut down equipment during a blackout.
Page 7 Connection (continued) Connecting Modules to Each Other and to Utility Power and Equipment Attach the PDU to the Power Module and Battery Module. Align and connect the PDU’s power module input terminals with the terminals on the back of the Power Module. Secure the PDU to the Power Module with four screws .
Page 8: Optional Connection
UPS. Install on your computer the Tripp Lite PowerAlert Software appropriate to your computer’s operating system. Consult your PowerAlert manual for more information. USB Communication Port Note: The USB port may be used to connect your UPS to a workstation or server.
Page 9: Manual Bypass Operation
Note: If desired, an optional hardwire detachable PDU is also available separately from Tripp Lite. Contact Tripp Lite for details. (Optional: During a hot-swap, the PDU can be housed in the back of the rack configuration using supplied PDU hanger brackets and hardware. See STEP 5 on page 3 for mounting instructions.)
Page 10 Manual Bypass Operation (for power module maintenance or replacement) (continued) UPS Power/Battery Module Removal STEP 1. Disable PowerAlert Software and disconnect communication cables from the communication ports on the UPS power/battery module. STEP 2. Press UPS's “OFF” Button , if the UPS is powered, until you hear a beep and see a “BYPASS MODE”...
Page 11: Specifications
Manual Bypass Operation (for power module maintenance or replacement) (continued) High Voltage Warnings Contacts on Power/Battery Module Contacts on Detachable PDU WARnIng! High Voltage! WARnIng! High voltage! Risk of electrical shock! Risk of electrical shock! Due to the presence of high voltage internal batteries, If AC is present and Bypass Switch is set to “Bypass”, even without AC present, these contacts are live!
Page 12: Operation
Operation LED Display Information AC Mode: AC input voltage in normal range: Bypass Mode: AC input voltage in a range Economy Mode: AC input voltage in a range 156-280V. of: -20 to +15% of the rating voltage; Bypass between -10 and +10% of rating voltage; Mode is enabled.
Page 13: Startup Self-Test
Failed Self-Test If a problem is detected during the self-test, the LCD will display a error message. If your UPS displays any of the following messages in its LCD, call Tripp Lite Technical Support at (773) 869-1234 for service. BAD BATTERy!
Page 14: Normal Operation
Operation (continued) normal Operation During normal operation, the first line of your LCD Display shows which operating mode your UPS is in: Online, Economy, On Battery, or Bypass. Online mode: The UPS provides AC power while utility power is available and switches to On Battery mode instantly (zero transfer time) if AC power is interrupted.
Page 15: Changing The Password
Operation (continued) Changing the Password To change the password, scroll DOWNi from the SETUP MENU screen to the BASIS SETTING screen. From here, press ON for the CHANGE PASSWORD screen. From this screen press ON and follow the previously described actions to set your password. When set, press ON to move to the SAVING screen.
Page 16: Start Settings
Operation (continued) Start Settings The UPS can start up through the battery without AC power. The DEFAULT is ENABLE. When the UPS switches to battery it can AUTO RESTART to work in an On-Line Mode when AC power is restored. DEFAULT is ENABLE. From the SETUP MENU screen, scroll DOWNi to the START SETTING screen.
Page 17: Battery Settings
Operation (continued) Battery Settings Deep Discharge Test: used to set the time period for deep discharge tests. From the SETUP MENU screen, scroll DOWNi until you reach the BATTERY SETTING screen. Press ON for the BATTERY LOW ALARM screen and scroll DOWNi until you reach the DEEP DISCH TEST screen.
Page 18: Output Settings
Operation (continued) Output Settings Note: Any Output Setting changes require a UPS power cycle. Output Voltage: used to set the UPS’ output voltage rating. From the SETUP MENU screen, scroll DOWNi until you reach the OUTPUT SETTING screen. Press ON to reach an OUTPUT VOLTAGE screen and ON again. You can now scroll DOWNi or UPh between 5 voltage values: 200/208/220/230/240V.
Page 19 Operation (continued) Output Settings ECO Mode: used to set the UPS’ ability to work in the energy saving Economy Mode. When input voltage is in a + or - range of 10% of the overall voltage rating, the UPS will transfer into an Economy Mode to improve the efficiency of the UPS. From the SETUP MENU screen, scroll DOWNi until you reach the OUTPUT SETTING screen.
Page 20 Operation (continued) UPS Alarm Log UPS ALARM LOg READ FROM MEMORy 1 65535 HH:MM:SS DOWn DOWn nO HISTORy      To EnTER  2 65535 HH:MM:SS nO HISTORy   3 65535 HH:MM:SS nO HISTORy   4 65535 HH:MM:SS nO HISTORy ...
Page 21: Self Diagnosis Information
Operation (continued) Self Diagnosis Information When starting with AC power, you will see the following sequence display: DIAgnOSTIC MODE FREQ OUT = 50Hz  DIAgnOSTIC MODE InPUT 000V / 00Hz  DIAgnOSTIC MODE RECTIFIER OK  DIAgnOSTIC MODE CHARgER OK ...
Page 22 Operation (continued) Display Information-Online Mode When operating in Online Mode with AC power present, you will see the following sequence display: LOAD LEVEL 00.00KW / 000%   LOAD LEVEL 00.00KVA / 000%   InPUT VOLTAgE 000V / 00.0Hz ...
Page 23 Operation (continued) Display Information-Bypass Mode When operating in Bypass Mode, you will see the following sequence display: LOAD LEVEL 00.00KW / 000%   LOAD LEVEL 00.00KVA / 000%   InPUT VOLTAgE 000V / 00.0Hz   ByPASS VOLTAgE 000V / 00.0Hz ...
Page 24 Operation (continued) On Battery Alarm When in the On Battery mode, the UPS power module will beep to inform you that it is using battery power to support connected equipment. If its connected batteries are at more than half capacity, it will beep every two seconds. If its connected batteries are below half capacity, it will beep twice a second.
Page 25: Shutdown Conditions
Operation (continued) Shutdown Messages Your UPS will shut down and the LCD will display a message if it detects one of the following conditions. Note: During all these conditions, the “Input,” “Output” and “Bypass” LEDs will be illuminated. SHUTDOWN LCD DISPLAY CONDITIONS MESSAGES Extended...
Page 26: Storage And Service
10 days of purchase. The warranties of all TRIPP LITE surge suppressors are null and void if they have been connected to the output of any UPS system. The warranties of all TRIPP LITE UPS Systems are null and void if a surge suppressor has been connected to its output receptacles.
