e
Bath Fan
Item Stock Number(s): BFL50UQ, BFL60UQ, BFL70, BFL85

IMPORTANT INSTRUCTIONS -

OPERATING MANUAL
READ AND SAVE THESE INSTRUCTIONS
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH
INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE!
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
When using electrical appliances, basic precautions should always be followed to reduce
the risk of fire, electric shock and injury to person, including the following:
1. Read all instructions before installing or using
exhaust fan.
2. Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
3. Before servicing or cleaning the unit, switch power
off at service panel and lock the service disconnecting
means to prevent power from being switched on
SAVE THESE INSTRUCTIONS
210572123 Rev. D 1-08
a
with

GENERAL SAFETY INFORMATION

Light User's Guide
accidentally. When the service disconnecting means
cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
4. Installation work and electrical wiring must be done
by qualified person(s) in accordance with all applicable
codes and standards, including fire-related construction.
5. Sufficient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of
www.geelectrical.com
BFL50UQ, BFL60UQ,
BFL70, BFL85
1 of 8

Advertisement

Table of Contents
loading

Summary of Contents for GE BFL50UQ

  • Page 1: Important Instructions

    BFL50UQ, BFL60UQ, BFL70, BFL85 Bath Fan Light User’s Guide with Item Stock Number(s): BFL50UQ, BFL60UQ, BFL70, BFL85 IMPORTANT INSTRUCTIONS - OPERATING MANUAL READ AND SAVE THESE INSTRUCTIONS READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED.
  • Page 2: Installation Instructions

    GENERAL SAFETY INFORMATION venturi. Keep the venturi assembly and the grill in the carton until needed so they do not get damaged (Continued) or lost. fuel burning equipment to prevent back drafting. Follow the heating equipment manufacturer’s guideline and safety standards such as those published by the National Screw Fire Protection Association (NFPA) and the American Society for Heating, Refrigeration, and Air Conditioning...
  • Page 3 2. Mounting Tab Installation: Using the gauge on the fan’s housing, line up housing so that it will be flush with the finished ceiling. Position the fan so that the tabs rest flat against the joist and secure with four nails (not provided) to ensure proper installation (Figure 4).
  • Page 4 1a. From where you have access to inside the fan’s SECTION 6 junction box, connect the one white wire from the Completing the Installation house to both the white wire from the fan’s light 1. Reinstall the fan’s venturi by holding it at approximately receptacle and the white wire from the fan’s exhaust a 45 degree angle, hook the two tabs on the venturi receptacle.
  • Page 5: Troubleshooting Guide

    a soft cloth. NEVER USE ANY ABRASIVE PADS OR SCOURING POWDERS. Completely dry grill before reinstalling. Refer to instructions in Section 6 Completing the Installation , to reinstall grill. 2. Cleaning the Fan Assembly: Unplug the motor cord and light cord from receptacles and loosen the venturi screw to remove the venturi from the unit.
  • Page 6: Warranty

    God. This warranty contains the sole and exclusive warranty of GE for claims based on defects in these products. Upon the expiration of the warranty period, all such liability shall terminate. There are no other warranties, whether written, oral, implied or statutory.
  • Page 7: Replacement Parts Diagram

    REPLACEMENT PARTS DIAGRAM Qty. Description Replacement Part # Qty. Description Replacement Part # Fan Housing 5S1201009 Hex Nut 5S1999006 Mounting Rails 5S1299002 Impeller 5S1299001 Collar 5S1201010 Motor Plate 5S1201014 Damper 5S1201011 Captive Screw 5S1999005 Polarized Receptacle 5S1999001 Scroll 5S1201006 Goose Neck Wire Cover 5S1201004 14 ga Ground Wire 5S1999003...
  • Page 8 210572123 Rev. D 1-08 www.geelectrical.com 8 of 8...
