General Dimensions RHM 100
PF0 (parallel, sealless/welded construction with flange
connection)
(*) Flange reduces the maximum allowable pipe pressure by a factor of 0.75
A2 = 1320 mm (51.97 in)
B2 = 403 mm (15.87 in)
Weight with 150# flanges: approx. 520 kg (1146 lb)
Shipping in wooden crate as per ISPM 15, approx. 220 x 160 x 90 cm (87 x 63 x 36 in), gross weight with 150# flanges and RHE 08 transmitter approx. 750 kg (1654 lb)
Finish type of our ANSI flanges corresponds to SF (AARH 125 up to 250 μin, Ra 3.2 up to 6.3 μm)
For customization with regard to face to face length and special fittings, please consult your local agent
Pressure Rating RHM 100
The maximum pressure (pmax) of a sensor is determined by its weakest part. The weakest part can be the measuring
loops (pmax indicated below) or the selected flanges / fittings (for pmax please see respective standard). For optional
materials like Alloy C22, wall thickness of measuring loops may change by +/- 10%.
pmax of P0 measuring loops, standard
M1 standard material - 1.4571 (316Ti)
OD x WT 114.3 x 4.5 mm (4.5 x 0.177 in)
bar
°C
73
50
66
120
57
210
pmax of PA measuring loops
M1 standard material - 1.4571 (316Ti)
OD x WT 114.3 x 6 mm (4.5 x 0.236 in)
bar
°C
99
50
88
120
76
210
2
H1 = 1505 mm (59.25 in)
H2 = 1735 mm (68.31 in)
psi
°F
1059
122
957
248
827
410
psi
°F
1436
122
1276
248
1102
410
Process Connection
Standard
Flange DIN DN200/PN16
Flange DIN DN200/PN40
Flange ANSI 8" 150# RF/SF
Flange ANSI 8" 300# RF/SF
Flange ANSI 8'' 600# RF/SF (*)
Optional
Flange DIN DN200/PN100 (*)
Flange ANSI 8" 900# RF/SF (*)
Flange ANSI 8" 900# RTJ (*)
Flange ANSI 8" 1500# RF/SF (*)
Flange ANSI 8" 1500# RTJ (*)
Flange JIS RF 10k 200A (8")
Flange JIS RF 20k 200A (8")
Terminal box (without cable gland) 125 x 80 x 58 mm (4.92 x 3.15 x 2.28 in)
W = 150 mm (5.91 in)
pmax of P1 measuring loops
M3 optional material - 2.4602 (Alloy C22)
OD x WT 114.3 x 5 mm (4.5 x 0.197 in)
bar
°C
113
50
100
120
85
210
pmax of PA measuring loops
62 optional material - 1.4462 (Duplex)
OD x WT 114.3 x 6.02 mm (4.5 x 0.237 in)
bar
°C
189
50
166
120
145
210
Face to face length (L)
Order Code
mm
in
900
35.43
D1
900
35.43
D2
900
35.43
A1
900
35.43
A2
900
35.43
A3
900
35.43
D3
900
35.43
A4
900
35.43
R3
900
35.43
A5
900
35.43
R4
900
35.43
J1
900
35.43
J2
psi
°F
1639
122
1450
248
1233
410
psi
°F
2741
122
2408
248
2103
410
