QuickSpecs
Overview
1. Speakers
Integrated rear-firing speakers
(Located on back of the monitor).
2. Dual
Built-in microphones.
Microphone
Array
3. Webcam
Built-in 720p HD Webcam.
4. Webcam LED
LED lights up when webcam is in use.
5. Menu
Opens, selects or exits the OSD menu.
Model
LW490AA
HP Compaq LA2206xc 21.5-inch Webcam LCD Monitor
DA - 14084 North America — Version 6 — April 17, 2013
6.
Minus
If the OSD menu is on, press to navigate
backward through the OSD menu and
decrease adjustment levels.
7.
Plus/source
If the OSD menu is on, press to navigate
forward through the OSD menu and increase
adjustment levels. If the OSD menu is inactive,
press to activate the source button that
chooses the video signal input (VGA, DVI, or
DisplayPort).
8.
OK/auto
If the OSD menu is on, press to select the
highlighted menu item. If the OSD menu is
inactive, press to activate the auto adjustment
feature to optimize the screen image.
9.
Power
Turns the monitor on or off.
10. Power LED
Blue = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the LW490AA and is the answer not in the manual?

Questions and answers

Summary of Contents for HP LW490AA

  • Page 1 QuickSpecs HP Compaq LA2206xc 21.5-inch Webcam LCD Monitor Overview 1. Speakers Integrated rear-firing speakers Minus If the OSD menu is on, press to navigate (Located on back of the monitor). backward through the OSD menu and decrease adjustment levels. 2. Dual Built-in microphones.
  • Page 2: Technical Specifications

    Color Gamut (typical) Color Support** Can display up to 16.7 million colors *All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. ** With the use of FRC technology. On Screen Display Buttons or Switches "Menu", "-", "+", "OK", "Power"...
  • Page 3 QuickSpecs HP Compaq LA2206xc 21.5-inch Webcam LCD Monitor Technical Specifications User Programmable Yes (10) Modes Anti-Glare Default Color Warm (6500K) Temperature Video/Other Inputs Plug and Play Input Connectors (1) VGA (analog); (1) DVI-D w/ HDCP; (1) DisplayPort w/ HDCP Input Impedance...
  • Page 4: Additional Information

    This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive - 2002/95/EC. This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive - 2002/96/EC. This product is in compliance with California Proposition 65 (State of California;...
  • Page 5 RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
  • Page 6: Hewlett-Packard

    HP Integrated Work Allows mounting of a 17 - 24 inch diagonal HP LCD monitor and an HP Compaq 8000 series Ultra-slim Desktop PC as well as select HP Thin Clients on a single Center Stand- stand for the convenience of an "all-in-one"...
  • Page 7 © Copyright 2012, 2013 Hewlett-Packard Development Company, L.P. 1 The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the VESA-compliant screws).
