- Page 1 Tactical Binocular USERS GUIDE...
- Page 2 Using Your Leupold Tactical Binocular ........
- Page 3 Using Your Leupold ® Tactical Binocular Using your Leupold Tactical binocular is very simple. However, you must set them to match your eyesight before use. This is done by adjusting the interpupillary distance and focusing the binoculars to your own visual acuity.
- Page 4 SETTING THE DIOPTER ADJUSTMENT Setting the diopter adjustment of your binocular properly is very important, as properly adjusted binoculars will prevent eye strain and provide you with a crisp, sharp image. TO SET THE DIOPTER ADJUSTMENT ON RIGHT EYEPIECE DIOPTER ADJUSTMENT MODELS: 1.
- Page 5 3. Cover the left objective lens with your hand. 4. Adjust the center focus wheel (located between the two barrels) until the image presented to your right eye is clear and sharp. 5. Cover the right objective lens with your hand. 6.
- Page 6 Clean the lenses as you would a camera lens. For optimal cleaning, use the Leupold Lens Cleaning System. Begin by using the brush to whisk away dust. Then use the microfiber cleaning tip, which is impregnated with a special non-liquid cleaning compound, to clean the glass.
-
Page 7: Warranty Service
Leupold Product Service department in Beaverton, Oregon. LEUPOLD PRODUCT SERVICE If your Leupold Tactical binocular fails to perform in any way, you may return them directly to the Leupold factory for service. It is not necessary for your dealer to ship the binocular to Leupold; however, they can be very helpful in determining if factory service is necessary. - Page 8 Leupold Product Service Leupold Product Service 14400 NW Greenbrier Parkway P.O. Box 688 Beaverton, OR 97006-5791 USA Beaverton, OR 97075-0688 USA Our Product Service telephone number is (503) 526-1400. We can also be contacted through our Web site at www.leupold.com.
- Page 9 If at any time a Leupold Tactical product is found to have a defect in materials or workmanship, Leupold will, at our discretion, repair or replace it free of charge, when requested by the original owner.
- Page 10 Stevens, Inc., Beaverton, Oregon. Note: We reserve the right to make design and/or material modifications without prior notice. This publication may not be reprinted or otherwise reproduced without the expressed written consent of Leupold & Stevens, Inc. Copyright © 2005 Leupold & Stevens, Inc. All rights reserved.
- Page 11 Part # 61240 Artwork # 61244...
