- Page 1 A Graham-Field Brand LF1030 HYDRAULIC PATIENT LIFT LF1040 ELECTRIC PATIENT LIFT OWNER'S MANUAL CD001030-1040 ©Graham-Field 10/03 IMPORTANT: READ THIS MANUAL BEFORE OPERATING YOUR PATIENT LIFT...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION ... 4 SPECIAL NOTES ... 5 SAFETY PRECAUTIONS ... 6 FEATURES ... 8 HANDLING PROCEDURES ... 9 ASSEMBLY INSTRUCTIONS ... 10 OPERATING INSTRUCTIONS ... 15 CARE AND MAINTENANCE ... 18 MAINTENANCE SCHEDULE ... 20 TROUBLESHOOTING ... 21 SPECIFICATIONS ... 22 LIMITED WARRANTY ... -
Page 4: Introduction
Congratulations on your purchase of a Lumex patient lift. The following pages will provide you with important safety and operating instructions on the use of patient lifts, slings, and accessories, as well as maintenance and warranty information. Read this manual carefully before operating your patient lift and refer to it as often as needed. -
Page 5: Special Notes
Warning: Do not operate this equipment without first reading and understanding this manual. If you are unable to understand the warnings, cautions and instructions, contact your dealer or a healthcare professional before attempting to use this equipment. Failure to do so may result in serious injury or damage to your patient lift. Maintenance MUST be performed by qualified personnel ONLY. -
Page 6: Safety Precautions
IMPORTANT: Before using patient lift, please read and adhere to the following safety precautions and warnings. Failure to do so could result in serious injury or damage to your patient lift. Always consult your healthcare professional to determine safe methods most suitable for your individual abilities. - Page 7 Warning: Unauthorized modification of your patient lift or the use of non-Lumex replace- ment parts may change the structure of the lift and could create a hazardous condition, which may result in serious injury and will void the warranty. Warning: LF1030 Hydraulic Patient Lift only: The hydraulic pump is sealed at the factory. If service is required, the unit must be returned to the factory for repair.
-
Page 8: Features
Battery, battery charger, & control box (LF1040 electric patient lift only) Actuator (LF1040 electric patient lift only) LF1040 electric patient lift Mast Push handle Base adjustment handle Locking casters LF1030 HYDRAULIC PATIENT LIFT / LF1040 ELECTRIC PATIENT LIFT OWNER'S MANUAL, 10/03 FEATURES Boom Spreader... -
Page 9: Shipping And Transportation Instructions
HANDLING PROCEDURES SHIPPING AND TRANSPORTATION INSTRUCTIONS If the patient lift is to be reshipped by common carrier, it should be packed in the same carton/s in which it was received (the LF1030 is shipped in one carton; the LF1040 motor may be packaged sepa- rately from the frame). -
Page 10: Assembly Instructions
ASSEMBLY INSTRUCTIONS The LF1030 patient lift is packed in one carton. The LF1040 motor may be in a separate carton. Com- ponents are shown in illustration below and called out in list below illustration. LF1030 HYDRAULIC PATIENT LIFT / LF1040 ELECTRIC PATIENT LIFT OWNER'S MANUAL, 10/03 LF1030 hydraulic patient lift components Item Qty Description Mast/Boom/Pump assembly (LF1030) - Page 11 Assembly 1. Remove the locking pin from the mast sleeve located on the rear of the base. 2. Install the L-inserts in the base. 3. With the boom pointed in the same direction as the base legs, insert the mast into the sleeve. 4.
- Page 12 6. Screw the push handles into the mast and tighten the nuts. 7. Remove the bolt from the top of the spreader bar, taking care not to drop the pin assembly. Install the spreader bar in the U bracket at the end of the boom.
-
Page 13: Electrical Connections (Lf1040 Only)
Note: Steps 10-13 apply to LF1040 Electric Patient Lift only. 10. Attach control box using 5mm cap screws as shown at right. 11. Attach battery charger using 5mm cap screws as shown at right. 12. Clip battery onto unit. 13. See following Electrical connections section. Electrical connections (LF1040 only) The control box is the heart of the electrical system;... -
Page 14: Emergency Procedures (Lf1040 Only)
Charging the battery with lift-mounted battery charger: With control box, battery charger, and battery assembled, insert the battery charger plug into a standard 110V receptacle. A green light signifying power and a yellow light signifying that the battery is charging will illuminate on the battery charger. When the battery is fully charged, the yellow light will shut off. -
Page 15: Lifting The Patient From A Bed
OPERATING INSTRUCTIONS Lifting the patient from a bed 1. Roll the patient onto their side. Place the folded sling behind the patient’s back. The center of the sling should be parallel with the patient’s spine. Roll the patient onto their back on top of the sling. 2. -
Page 16: Lifting The Patient From The Floor
Lowering the patient onto a bed 1. Raise the patient lift until the patient’s buttocks are above the surface of the bed. Ensure that there are no obstacles underneath or around the bed. Move the patient lift under the bed. Be careful the patient does not hit any portion of the bed and that the patient’s legs have cleared the bed. -
Page 17: Removing Sling
8. Slowly lower the patient into the wheelchair. 9. With one (1) attendant behind the wheelchair and the other operating the lift, the attendant behind the chair should pull back on the handle or sides of the sling to place the patient into the back of the chair. -
Page 18: Care And Maintenance
Proper care and maintenance is essential to keeping your Lumex patient lift in a safe operating condi- tion. In addition to inspecting the unit before each use, periodic maintenance checks should be done. We further recommend that this unit be serviced at least once annually by an authorized dealer. Warning: It is extremely important that the patient lift be inspected before each use. -
Page 19: Checking For Damage And Wear
Cleaning Regular cleaning is recommended. A soft cloth, dampened with water and a mild NON-ABRASIVE detergent (household cleaner, soapy water, or hospital grade disinfectant) is all that is needed to clean your patient lift. Automobile wax or furniture polish will help maintain the finish over a long period of time. -
Page 20: Maintenance Schedule
MAINTENANCE SCHEDULE Note: Only qualified persons should service and repair your Lumex patient lift. Regular maintenance of your patient lift is necessary to ensure continuing proper and safe operation. Read and observe the following recommended maintenance schedule: Item Base and Casters Ensure that base is level (all four wheels touch the floor) Ensure that caster mounting bolts and axle bolts are tight Ensure that casters swivel and roll freely... -
Page 21: Troubleshooting
Warning: If you experience a problem with your lift and are unable to service it yourself, contact your Lumex dealer. LF1030 HYDRAULIC PATIENT LIFT SYMPTOM POSSIBLE CAUSE Patient lift does not Air in the cylinder go up or down Loss of hydraulic fluid (leaking cylinder) Patient lift does not Air in the cylinder... -
Page 22: Specifications
SPECIFICATIONS Note: All dimensions given in inches unless otherwise specified. LF1030 HYDRAULIC PATIENT LIFT / LF1040 ELECTRIC PATIENT LIFT Base width Open: 39.4" Closed: 25.6" Base height (Clearance): 5-1/2" Base length 45.30" Lifting height range Note: As measured from point where spreader bar attaches to boom. Minimum: 27.4"... -
Page 23: Limited Warranty
NOTE: The warranty below has been drafted to comply with the Federal Law applicable to products manufactured after July 4, 1975. This warranty is extended only to the original purchaser/consumer or dealer/non-consumer who does not buy for resale and to no other purchaser or transferee. Graham-Field warrants the LF1030 hydraulic patient lift against defects in materials and workmanship as listed below: PRODUCT... - Page 24 THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESSED WARRANTIES AND IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND SHALL NOT EXTEND BEYOND THE DURATION OF THE EXPRESSED WARRANTY PROVIDED HEREIN, AND THE REMEDY FOR VIOLATIONS OF ANY IM- PLIED WARRANTY SHALL BE LIMITED TO THE REPAIR OR REPLACEMENT OF THE DEFECTIVE PRODUCT OR PART PURSUANT TO THE TERMS CONTAINED HEREIN.
-
Page 25: Index
Actuator, maintenance (LF1040 only) 20 Assembly instructions 10 Battery, charging (LF1040 only) 13 Care and maintenance 18 Care of sling 19 Caution, as used in this manual 5 Checking for damage and wear 19 Cleaning 19 Electrical connections (LF1040 only) 13 Electronic components, service 7 Emergency procedures (LF1040 only) 14 Handling procedures 9... - Page 26 NOTES LF1030 HYDRAULIC PATIENT LIFT / LF1040 ELECTRIC PATIENT LIFT OWNER'S MANUAL, 10/03...
- Page 28 U.S.A., Corporate Headquarters: Graham-Field Health Products 2935 Northeast Parkway Atlanta, Georgia 30360 telephone: 800-347-5678, 770-447-1609 fax: 800-726-0601, 678-291-3232 http://www.grahamfield.com...
