LA Audio MLX20 Product Overview And Specifications

PRODUCT OVERVIEW
The MLX20 is a professional two channel Mic
Preamplifier which also accepts Line levels and Direct
Instrument connection.
The unit is designed around an ultra low noise input
device with excellent common mode rejection
resulting in signal amplification of exceptional clarity.
The DI input circuit is FET based producing excellent
sonic characteristics especially on bass instruments.
Front panel controls include Input Gain, Variable High
Pass Filter and Output level control. Front panel
switches provide selection between the rear panel
Mic and Line inputs and the front panel DI socket.
Phase Reverse and +48V Phantom Power switches
are also included.
APPLICATIONS
The high degree of specification and performance the
MLX20 offers makes it the ideal preamplifier for direct
to analogue or digital recording of Mic, Line and
Instrument sources.
The MLX 20 may also be used as a high quality
active Dual DI unit.
In keeping with our policy of continuous improvement LA Audio reserves the right to alter specifications without prior notice.
British
Manufactured in the UK by LA Audio, 6-24 Southgate Road, London, N1 3JJ.
Originals Tel: +44 (0)207 923 7447, FAX: +44 (0)207 241 3644. Web: www.laaudio.co.uk. email: sales@laaudio.co.uk
An SCV International Group Company
SPECIFICATIONS
ELECTRICAL
Frequency response:
Mic input impedance:
Line Input impedance:
DI impedance:
Output impedance:
Output levels:
Max output level:
Peak indicator:
Signal to Noise ratio:
Gain:
Hi Pass Filter:
THD:
Power Consumption:
PHYSICAL
Input connectors:
Output connectors:
Power Connection:
Dimensions:
Weight:
Shipping weight:
1dB, 20Hz to 20kHz
1.2k balanced
20k balanced
0.5M
<100R ground sensing
+4dBu on XLR
-10dBV on TRS jack
+20dBu
3dB before clipping
Mic EIN <-128dBu
Line <-90dB (at 0dB gain)
DI <-80dB (at 20dB gain)
Mic = +10dB to +60dB
Line = -10dB to +30dB
DI = 0dB to +30dB
25Hz - 250Hz, -12dB/octave
< 0.05%
7VA, 115/230V, 50/60Hz
Mic: 3 pin XLR (Pin 2 hot)
Line: º" TRS jack (Tip hot)
DI: º" jack
3 pin XLR (Pin 2 hot)
º" TRS jack (Tip hot)
Detachable Lead, 3 pin IEC
socket
483mm (19") W
150mm (6") D
44mm (1.75")
2.2kg
2.85kg
