B100
INTEGRATED AMPLIFIER
OWNER'S MANUAL
2008-09-26
For models
B100, B100-DA & B100-P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B100-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bryston B100-P

  • Page 1 B100 INTEGRATED AMPLIFIER OWNER’S MANUAL 2008-09-26 For models B100, B100-DA & B100-P...
  • Page 2: Table Of Contents

    B100 TWO CHANNEL POWER AMPLIFIER table of contents Page • INTRODUCTION • SETUP • CONNECTIONS • INPUTS & OUTPUTS • LED STATUS INDICATORS • REMOTE POWER CONTROL • PROGRAMMING THE 12V TRIGGER • HAND-HELD IR REMOTE CONTROL • PROGRAMMING THE REMOTE CONTROL • SENDING CODES TO THE B100 VIA THE IR REMOTE CONTROL • WIRED RS232 REMOTE CONTROL • PASS-THROUGH MODE • DIGITAL-TO-ANALOG CONVERTER OPTION • MOVING-MAGNET PHONO STAGE OPTION • SPECIFICATIONS • FRONT & REAR PANEL DETAILS • EXTERNAL DIMENSIONS & RECOMMENDED CLEARANCE ENVELOPE...
  • Page 3 Bryston authorized dealer to qualify for warranty service. The warranty is transferable from the original owner to a subsequent owner as long as a copy of the bill-of-sale from the original authorized Bryston dealer accompanies the re-sale. The copy of the bill of sale to any subsequent owner need ONLY include the Name of the Bryston Authorized Dealer and the Model and Serial number of the Bryston product The warranty will only be honored in the country of the original purchase unless otherwise pre-authorized by Bryston.
  • Page 4: Introduction

    We would welcome any suggestions or comments you may have regarding the operation of your Bryston amplifier. In the unlikely event that your amplifier may require service Bryston recommends that you retain the original shipping box and packaging material for future use if required.
  • Page 5: Led Status Indicators

    B100-P and cannot be used as such. LINE LEVEL ANALOG AUDIO OUTPUTS : The Bryston B100 integrated amplifier comes equipped with 2 pairs of gold plated analog RCA jacks for out- puts: PREAMP OUT and RECORD OUT. • PREAMP OUT is normally connected, internally, via the CONNECTED/SEPARATE switch, to POWER AMP IN •...
  • Page 6: Remote Power Control

    D4 LEDs, it indicates that the digital inputs d1 (SPDIF), d2 (SPDIF), d3 (TOSLINK) or d4 (TOSLINK) have been selected. In B100 & B100-P models: when illuminated green this LED indicates that the line level ana- log audio input AUX-2 has been selected.
  • Page 7: Programming The Remote Control

    B100 TWO CHANNEL POWER AMPLIFIER unit. Ensure that the batteries are correctly oriented and properly seated in the battery holder. The B100 remote is a full function remote allowing selection of all sources, volume up or down (the volume con- trol is a motor-driven design), mute ,left/right balance, power on/off and discrete code entry.
  • Page 8: Digital-To-Analog Converter Option

    All of the above functions are available from the hand held remote control as well . MOVING-MAGNET PHONO STAGE OPTION: The B100-P contains a moving magnet phono stage. The Phono Stage is modular and can be added to the stan- dard B100 model later if required by your Bryston dealer.
  • Page 9: Specifications

    B100 dUAL CHANNEL POWER AMPLIFIER B100 SPECIFICATIONS: POWER AMPLIFIER SECTION: Power Output: 100 watts per channel into 8Ω 180 watts per channel into 4Ω Input Impedance: 50K ohms single ended Sensitivity: 1v = 100 Watts into 8 ohms Distortion: tHd+noise: < 0.005% 20Hz to 20kHz at 100 watts into 8 ohms, IMD: < 0.010% 60Hz + 7KHz mixed 4:1 Noise: >108dB below rated output (with 20Hz to 22KHz bandpass filter) Slew Rate: >60 volts per microsecond Power Bandwidth: <1 Hz to over 100 kHz Damping Factor: Over 500 at 20 Hz, ref. 8 ohms Power consumption: idle 30va, maximum power 600va Heat load: idle 100 btu/hr., max power 288 btu/hr...
  • Page 10: Front & Rear Panel Details

    B100 TWO CHANNEL POWER AMPLIFIER...
  • Page 11 B100 TWO CHANNEL POWER AMPLIFIER...
  • Page 12 There are no user serviceable parts inside the B100. Please refer any servicing to qualified personnel. BRYSTON LTD., 677 NEAL DRIVE, P.O. BOX 2170, PETERBOROUGH, ONTARIO CANADA K9J 7Y4 B100_MANUAL_20080926...
