- Page 1 User Manual...
-
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ......................3 What is Included ..........................3 Unpacking Instructions ........................3 Claims ............................... 3 Text Conventions ..........................3 Symbols ............................3 Disclaimer ............................3 Product at a Glance .......................... 4 Safety Notes ............................. 4 2. -
Page 3: Before You Begin
Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. For other issues, such as missing components or parts, damage not related to shipping, or concealed damage, file a claim with CHAUVET® within 7 days of delivery. Text Convention... -
Page 4: Product At A Glance
Product at a Use on Dimmer Auto Programs Outdoor Use Auto-ranging Power Supply Glance Sound-Active Replaceable Fuse User-Serviceable Master/Slave Safety Notes These notes include important information about the mounting, usage, and maintenance of this product; read before using the product. ·... -
Page 5: Introduction
2. I NTRODUCTION Overview Display Menu Buttons DMX In Power In Fuse Holder DMX Out Power Out Passageway for Safety Cable Back Panel View SlimPAR™ Pro VW User Manual Rev. 6 Page 5 of 18... -
Page 6: Dimensions
Dimensions 285 mm 11.2 in Page 6 of 18 SlimPAR™ Pro VW User Manual Rev. 6... -
Page 7: Setup
3. S ETUP AC Power The SlimPAR™ Pro VW has an auto-ranging power supply and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 8: Power Linking
The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET® distributor as power linking connectors and requirements may differ in your country or region. -
Page 9: Mounting
Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The SlimPAR™ Pro VW may be mounted in any position; however, make sure adequate ventilation is provided around the product · Rigging Before deciding on a location, always make sure there is easy access to the product for maintenance and programming. -
Page 10: Lens Assembly Replacement
Lens Assembly The SlimPAR™ Pro VW comes with a factory-installed wide-angle lens assembly. A narrow lens (17°) assembly is available as an optional accessory (SPPVWLENS17). Replacement This narrow lens assembly will alter the beam and field angles of the fixture. To replace the lens assembly, follow the instructions below. -
Page 11: Operation
4. O PERATION Control Panel To access the control panel functions, use the four buttons located underneath the display. Operation Button Function <MENU> Selects an operation mode or backs out of the current menu option <UP> Scrolls up the list of options or selects a higher value <DOWN>... -
Page 12: Configuration (Dmx)
Configuration Set the product in DMX mode to control with a DMX controller. Connect the product to power. (DMX) Connect a DMX cable from the DMX output of the DMX controller to the DMX input socket on the product. Starting Address When selecting a starting DMX address, always consider the number of DMX channels the selected DMX mode uses. -
Page 13: Dmx Channel Modes, Assignments, And Values
DMX Channel Modes, Assignments, and Values Channel Function Value Setting 7-Channel 000 ó 255 0–100% Dimmer 000 ó 255 0–100% Warm White 000 ó 255 0–100% Cool White 000 ó 009 No function Strobe 010 ó 255 0–20 Hz, slow to fast 000 ó... -
Page 14: Configuration (Standalone)
Configuration Set the product in one of the standalone modes to control without a DMX controller. · Connect the product to a suitable power outlet. (Standalone) Never connect a product that is operating in any standalone mode (Static or Automatic) to a DMX string connected to a DMX controller. Products in standalone mode may transmit DMX signals that could interfere with the DMX signals from the controller. -
Page 15: Master/Slave Mode
Master/Slave The Master/Slave mode allows a single SlimPAR™ Pro VW (the “master”) to control the actions of one or more SlimPAR™ Pro VW units (the “slaves”) without the need of a Mode DMX controller. The master will be set to operate in either an auto program or static color, while the slaves will be set to operate in Slave mode. -
Page 16: Technical Information
5. T ECHNICAL NFORMATION Product Dust build-up reduces light output performance and can cause overheating. This can lead to reduction of the light source’s life and mechanical wear. To maintain optimum Maintenance performance and minimize wear, clean the product at least twice a month. However, usage and environmental conditions contribute to increased cleaning frequency. -
Page 17: Technical Specifications
6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 3.4 in (87 mm) 10.1 in (256 mm) 11.2 in (285 mm) 6.3 lb (2.8 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Supply Type Range Voltage Selection Power... -
Page 18: Returns
You must send the merchandise prepaid, in its original box, and with its original packing and accessories. CHAUVET® will not issue call tags. Clearly label the package with the RMA number. CHAUVET® will refuse any product returned without an RMA number.
