PRODUCT NO.
MRT18BSCW6
MARKET
North America
WIRING DIAGRAM - 218758400
OWNER'S GUIDE - 218613200
SERVICE DATA SHEET - 218758400
101 Masters Blvd.
Anderson, SC 29624
UNIVERSAL/MULTIFLEX
BASE MODEL NO.
SERIES
MRT18BSC
R134a System
Publication No.
5995320149
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
REFRIGERATOR
COLOR
white
990325
390
©1999 White Consolidated Industries, Inc.
All rights reserved
VOLTS
115V
REFRIGERATOR
Model No.
MRT18BSC
Advertisement
Related Manuals for Frigidaire MRT18BSC
Summary of Contents for Frigidaire MRT18BSC
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR UNIVERSAL/MULTIFLEX PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS MRT18BSCW6 MRT18BSC R134a System white 115V MARKET North America WIRING DIAGRAM - 218758400 OWNER’S GUIDE - 218613200 SERVICE DATA SHEET - 218758400 REFRIGERATOR 101 Masters Blvd. Model No.
- Page 2 Publication No. MRT18BSCW6 5995320149 DOOR 03/99...
- Page 3 MRT18BSCW6 Publication No. 5995320149 DOOR POS. NO PART NO DESCRIPTION 215608916 Gasket-frzr door,white ,magnetic 218730605 Gasket-refr door,white ,magnetic 218360003 Panel-inner door,refr 218027022 Rack-door,23.81" x 1.62" 215267701 Support-door rack,"2-liter" ,RH/LH 215473602 Support-door rack,RH/LH 218360101 Panel-inner door,frzr 5308000134 Plug-button,white ,hinge brg hole 218508701 Panel-frzr door,white ,with handles &...
- Page 4 Publication No. MRT18BSCW6 5995320149 CABINET 03/99...
- Page 5 MRT18BSCW6 Publication No. 5995320149 CABINET POS. NO PART NO DESCRIPTION 218672501 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 218448301 Cover,white ,lwr hinge hole 5300157666 Bushing-motor mtg,(2) 5303205118 Bracket-motor mtg,front 3206451 Cover-evap coil 5303208309 Plug-hole,factory test 215079000 Plug-harness hole,round 215079100...
- Page 6 Publication No. MRT18BSCW6 5995320149 SHELVES 03/99...
- Page 7 MRT18BSCW6 Publication No. 5995320149 SHELVES POS. NO PART NO DESCRIPTION 218874301 Mullion,white ,1 218781003 Heater-mullion 218845602 Tapping Plate,mullion mtg ,(2) 218814800 Panel-top,refr cavity 5303001380 Screw,truss head ,8-10 x 1.625 218814600 Divider,styrofoam 8* # 218878500 Harness-wiring,control/divider 218814700 Panel-bottom,frzr cavity 218730000 Deflector-air 5303001449 Seal-air deflector,foam plastic ,(2) 218631001...
- Page 8 Publication No. MRT18BSCW6 5995320149 SYSTEM 03/99...
- Page 9 MRT18BSCW6 Publication No. 5995320149 SYSTEMS POS. NO PART NO DESCRIPTION 218173900 Condenser 5303208866 Spacer-cond tube,black 5308000296 Bracket,condenser mtg ,(4) 5308009617 Washer,ext tooth lock ,#10 ,grounding 218541000 Drier-filter 218878500 Harness-wiring,control/divider 215257004 Harness-wiring,compressor 5316254901 Cord-electric power 5303001197 Cover-wiring 13 # 218429306 Heat Exchanger,suction line 14 # 3206453 Heater-defrost...
