Makita BTD061 Instruction Manual

Cordless impact driver equipped with electric brake
Hide thumbs Also See for BTD061:
Table of Contents

Advertisement

Quick Links

Cordless Impact
Driver
Equipped with Electric Brake
MODEL BTD061
001249
I N S T R U C T I O N
M A N U A L
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
w w w . m a k i t a t o o l s . c o m

Advertisement

Table of Contents
loading

Related Manuals for Makita BTD061

Summary of Contents for Makita BTD061

  • Page 1 Cordless Impact Driver Equipped with Electric Brake MODEL BTD061 001249 I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    SPECIFICATIONS Model BTD061 Machine screw 4 mm - 8 mm (5/32” - 5/16”) Capacities Standard bolt 5 mm - 12 mm (3/16” - 1/2”) High tensile bolt 5 mm - 10 mm (3/16” - 3/8”) No load speed (RPM) 0 - 2,500/min.
  • Page 3 3. Keep bystanders, children, and visitors Tool Use and Care away while operating a power tool. Distrac- 12. Use clamps or other practical way to tions can cause you to lose control. secure and support the workpiece to a Electrical Safety stable platform.

  • Page 4: Specific Safety Rules

    22. When servicing a tool, use only identical SERVICE replacement parts. Follow instructions in 21. Tool service must be performed only by the Maintenance section of this manual. qualified repair personnel. Service or main- Use of unauthorized parts or failure to follow tenance performed by unqualified personnel Maintenance instructions may create a risk of may result in a risk of injury.
  • Page 5 8. An extension cord should not be used 3. CAUTION - To reduce risk of injury, charge unless absolutely necessary. Use of only MAKITA rechargeable batteries improper extension cord could result in a marked on the charger label. Other types risk of fire and electric shock.
  • Page 6 11. Do not disassemble charger or battery 14. Young children should be supervised to cartridge; take it to a qualified serviceman ensure that they do not play with the bat- when service or repair is required. Incor- tery charger. rect reassembly may result in a risk of 15.
  • Page 7 SYMBOLS The following show the symbols used for the charger. Be sure that you understand their meaning before use... Ready to charge ...Delay charge (Cooling) ..... Charging ..Defective battery ..... Charging complete ..Conditioning ...Cooling abnormality...

  • Page 8: Functional Description

    FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge 001251 • Always switch off the tool before insertion or removal of the battery cartridge.
  • Page 9 NOTE: • The battery charger is for charging Makita battery cartridge. Never use it for other purposes or for other manufacturer’s batteries. • When you charge a new battery cartridge or a battery cartridge which has not been used for a long period of time, it may not accept a full charge.
  • Page 10 When the tool is switched off, the light goes out after approx. 5 seconds. If the battery has not been used for a long time, or is needed refresh charging, the (C) lamp begins to flicker. Use Makita refreshing adapter to refresh the battery.

  • Page 11: Electric Brake

    Electric brake This tool is equipped with an electric brake. If the tool consis- tently fails to quickly stop after switch trigger release, have tool serviced at a Makita service center. Reversing switch action 001257 This tool has a reversing switch to change the direction of rotation.

  • Page 12: Operation

    ASSEMBLY CAUTION: • Always be sure that the tool is switched off and the battery cartridge is removed before carrying out any work on the tool. Installing or removing driver bit or socket bit 001266 Use only the driver bit or socket bit shown in the figure. Do 12 mm 9 mm not use any other driver bit or socket bit.
  • Page 13 Hold the tool firmly and place the point of the driver bit in the 003848 Standard bolt screw head. Apply forward pressure to the tool to the extent that the bit will not slip off the screw and turn the tool on to start operation.

  • Page 14: Maintenance

    1 minute. Then check the tool while running and elec- tric brake operation when releasing the switch trigger. If elec- tric brake is not working well, ask your local Makita service 1. Brush holder cap center for repair.
  • Page 15 Memo...
  • Page 16 Memo...
  • Page 17 First-Class Postage Required Post Office will not deliver without proper postage. Makita U.S.A., Inc. 14930 Northam Street La Mirada, CA 90638-5753 Fold...
  • Page 18 Design Repair Service Industrial Maintenance Features Durability Home Maintenance Size Power Hobby Price Other ( Other ( Makita Brand 5. Any comments: DATE PURCHASED MODEL NO. MONTH YEAR SERIAL NO. STATUS INTL. LAST NAME / COMPANY NAME Married Single STREET ADRESS...

  • Page 19: Factory Service Centers

    Date Purchased When you need service: Send complete tool (prepaid) to one Dealer’s Name & Address of the Makita Factory Service Centers listed, or to an Authorized Makita Service Center. Be sure to attach a letter to the outside of Model No.
  • Page 20 MAKITA LIMITED ONE YEAR WARRANTY Warranty Policy Every Makita tool is thoroughly inspected and tested before leaving the factory. It is warranted to be free of defects from workmanship and materials for the period of ONE YEAR from the date of original purchase.
