Grundig WST 864 User Manual

Grundig WST 864 User Manual

Wireless sound transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
COLOR TELEVISION
WIRELESS SOUND TRANSMITTER
WST 864
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WST 864 and is the answer not in the manual?

Questions and answers

Related Manuals for Grundig WST 864

Summary of Contents for Grundig WST 864

  • Page 1 COLOR TELEVISION WIRELESS SOUND TRANSMITTER WST 864 ENGLISH...

  • Page 2: Table Of Contents

    CONTENTS __________________________________________________________________________ Scope of delivery Safety The Wireless Sound Transmitter Setting-up Setting up in shelf unit Mounting on the wall Connecting and setting Connecting transmitter Setting transmission channel Starting Switching on and operation Notes on operation and possible interference Information Technical data Rectifying malfunctions...

  • Page 3: Scope Of Delivery

    Two rear panels with connecting cable (3 m) for wall mounting Operating instructions Two installation angles One cinch cable One 14 Volt plug power supply SURROUND • • • • • • • COLOR TELEVISION WIRELESS SOUND TRANSMITTER WST 864...

  • Page 4: Safety

    SAFETY ___________________________________________________________________________________ To ensure that this high-quality and user-friendly WIRELESS SOUND TRANSMITTER gives you lasting satisfaction and enjoyment, it is very important that the following points are observed when setting up the appliances. The sound system is designed for transmitting and receiving sound signals. Any other use is explicitly forbidden.

  • Page 5: The Wireless Sound Transmitter

    To the »SURROUND« socket on the TV set Note: Use your Grundig TV set speakers (e.g. with Arganto DPL) for the black-colo- red WIRELESS SOUND TRANSMITTER system. If you have purchased the “polar-colored” WIRELESS SOUND TRANS- MITTER system, you can order the matching speakers at your authorized...
  • Page 6 SETTING-UP OPTIONS ______________________________________________ The TU 864 transmitter is placed next to your TV set; you have 3 options for setting up the RU 864 receivers and the swiveling Surround speakers: Receiver and speaker can be set up on a shelf, for example. The speakers can be mounted on the wall.

  • Page 7: Setting-Up

    SETTING UP ________________________________________________________________________ Installation on a shelf Fasten speaker to the rear panel by pressing button on speaker and pushing both parts together. Wall mounting Fasten the installation angle to the wall Note: You can stabilise the position of the angle with 2 pins. Fasten the supplied rear panel with connecting cable (3m) to the speaker by pressing the button on the speaker and pushing both parts together.
  • Page 8 SETTING UP ________________________________________________________________________________ Insert the speaker cable through the rear hole of the mounting angle. Screw the speaker to the installation angle with the supplied screw. Lay speaker cable. Remove cover from receiver unit. To do so, press latch on the top left of the cover, fold cover to the front and them pull away upwards.

  • Page 9: Connecting And Setting

    CONNECTING AND SETTING ______________________________ Connecting transmitter Connect the »SURROUND« cinch socket on the TV set with the »SURROUND« cinch sockets on the transmitter using the cinch cable SURROUND provided. • • • • • • • Insert the plug power supply socket into the »14V« socket. To the Insert plug power supply into the mains socket.

  • Page 10: Starting

    STARTING _____________________________________________________________________________ Switching on and operation Switch on both receivers by using the »POWER« switch. – The displays illuminate red. Switch on your television set. Activate the »Dolby Surround Prologic« (see the operating manual for your O F F TV set) function in the sound menu for your television set. Notes: The transmitter will be automatically switched on if the TV programme or the AUDIO/VIDEO playback is transmitted with Dolby Surround Prologic.

  • Page 11: Information

    INFORMATION ________________________________________________________________ Technical data Transmitter Voltage supply: 10.5 V – 16 V- Power requirement: 2.2 W Transmitter frequency: 864 MHz/7 channels Dimensions (W x H x D): 127 mm x 52 mm x 135 mm Receiver Voltage supply 230 V~, 50/60 Hz Power requirement: 50W;...

  • Page 12: Rectifying Malfunctions

    INFORMATION __________________________________________________________________________ Rectifying malfunctions If the remedial measures listed below do not lead to a satisfactory result, please consult a GRUNDIG authorized dealer. Fault Possible cause Remedial measures The Surround speakers Both receivers and the transmitter Change the position have ceased to function.
