  • Page 1                                         Planar LT3200 Owner Manual   LT3200 Owner Manual  1 | P a g e    ...
  • Page 2 This manual is designed for use with the Planar® LT3200 LookThru™ open frame transparent  display.  Information in this document has been carefully checked for accuracy; however, no  guarantee is given to the correctness of the contents.    The information contained in this document is subject to change without notice.  This  document contains proprietary information that is protected by copyright. All rights are  reserved.  No part of this document may be reproduced, translated to another language or  stored in a retrieval system, or transmitted by any means, electronic, mechanical,  photocopying, recording, or otherwise, without prior written permission.  Brands or product names are trademarks of their respective holders.        LT3200 Owner Manual  2 | P a g e    ...
  • Page 3: Table Of Contents

    LT3200 DISPLAY COMPONENTS .................... 6 PRODUCT ARCHITECTURE ....................8 DESIGNING AN ENCLOSURE FOR YOUR LT3200 .............. 9 CONNECTING THE DRIVER BOX ..................10 VII. PRESENTATION OF YOUR MATERIAL USING THE LT3200 ......... 13 VIII. APPENDIX ........................... 14   Display Module Drawing   14 ...
  • Page 4: Precautions

    Do not use abrasive cleaners, waxes or solvents for your cleaning.  Do not spray cleaner inside the display enclosure. We recommend wiping the interior with a soft cloth that has been moistened with a mild detergent.     LT3200 Owner Manual  4 | P a g e    ...
  • Page 5: Lt3200 Product Description

    The driver box contains the LED controller and the video interface circuitry and can be located remotely from the display module by as much as four feet. Power is supplied to the LT3200 driver box through the four-pin connector of the 48V power supply brick. The power brick is compatible with an input voltage range of 100 to 240VAC with a suitable power cord.
  • Page 6: Lt3200 Display Components

      III. LT3200 Display Components Front and Back Views of the Display Front View ‐ Heat strengthened Glass with AR coating    AMLCD Circuit Cover Plate   LED Strips (6x)  Display Mounting  Brackets (2x)  Display Chassis   Rear View – Display chassis with LED illuminators and mounting brackets   Edge Views of the Display AMLCD Assembly   Cable Strain  Display Mounting  AMLCD Circuit Cover Plate   Relief Pad   Brackets (2x)  Display Chassis  Front Glass   Display Mounting  AMLCD Circuit Cover Plate   Brackets (2x)  Display Chassis  Front Glass   Caution! Avoid any impact or contact with the cover plate surrounding the AMLCD circuit card.
  • Page 7   LC3200 Display Components, cont’d Top, Backside and Edge Views of the Driver Box Cable Grommet   Driver Box Lid Fasteners   Top View   Power Switch    Backside View         DisplayPort  HDMI   48V Input from  Power Switch  Power Brick     Edge View       LT3200 Owner Manual  7 | P a g e    ...
  • Page 8: Product Architecture

      IV. Product Architecture   LT3200 Block Diagram           LT3200 Owner Manual  8 | P a g e    ...
  • Page 9: Designing An Enclosure For Your Lt3200

    LED and video wiring bundle that are to be connected to the driver box. More details are found in the next section of this document. The LT3200 is a component type open frame TFT LCD display intended to be installed into a final system assembly. Therefore the mechanical enclosure, electrical enclosure, EMC enclosure and mounting function must be evaluated in the final system assembly.
  • Page 10: Connecting The Driver Box

      VI. Connecting the Driver Box The LT3200 is shipped with the wiring bundle disconnected from the Driver Box so the free end of the bundle can be routed in the enclosure as part of the assembly process. This section describes how to connect the wiring bundle to the Driver Box. You will need a small (#1) Phillips screwdriver.
  • Page 11 6- Place the video ground clasp around the bare-metal section of the video cable and attach it to the standoff near the LED connector on the LED driver board. See photo 6 at right. LT3200 Owner Manual  11 | P a g e    ...
  • Page 12 The power brick should be plugged into the driver box and a grounded power receptacle during the removal.     LT3200 Owner Manual  12 | P a g e    ...
  • Page 13: Presentation Of Your Material Using The Lt3200

    LT3200. In order to maximize the brightness of the LT3200 we have provided an extremely high level of white light illumination for your display box design. In addition to enhancing the appearance of...
  • Page 14: Appendix

      VIII. Appendix Display Module Drawing     LT3200 Owner Manual  14 | Page ...
  • Page 15: Driver Box Drawing

      Driver Box Drawing LT3200 Owner Manual  15 | Page ...
  • Page 16: Troubleshooting

    LT3200 shortly after the splash screen appears. Note that when power is applied you should also see light from the LEDs located around the perimeter of the AMLCD screen.
  • Page 17: Lt3200 Specifications

      LT3200 Specifications This section contains specifications for the LT3200 display.    Product Name  LT3200  Planar Part Number  997‐6868‐00  Viewable Size  31.25" diagonal (27.3” x 15.2”)  Viewing Angle (Typical)  178° Horizontal and Vertical   Response Time (G‐to‐G, Typical)  8 msec  Brightness (Typical)  Dependant on customer enclosure design    Native Display Resolution  1366 x 768  Aspect Ratio  16:9  Color Palette   16.7 million colors  Pixel Pitch  0.511 mm  Refresh Rate  50 to 60 Hz  Exterior Dimensions (W x H x D)  29.9” (760 mm) x 17.9” (455 mm) x 2.1” (53.3 mm)   Module Weight, less Driver Box    12.2 lbs (5.55 kg)   Driver Box Dimensions  9.19” (233 mm) x 7.50” (191 mm) x 1.38” ( 35.1mm)  Video Inputs  Digital (HDMI, DisplayPort)  LT3200 Owner Manual  17 | Page ...
  • Page 18   Power Supply  External AC adapter, 48V DC   Power Requirements  100‐240 VAC (50/60 Hz)  Power Consumption  125W  Module Mounting   Built‐in mounting bracket, see outline drawing    Service and Support  3‐Year Warranty   Product Approvals  NRTL Listed, FCC‐Class A, CE, RoHS  Environmental ‐ Operating  0° to 40°C    Temperature   Environmental ‐ Operating  ‐10° to 50°C    Temperature   LT3200 32" LookThru LCD module, Driver Box, Power Brick  In the Box  and Cord, HDMI Cable, User’s Manual          LT3200 Owner Manual  18 | Page ...
  • Page 19: Graphics Input Compatibility

    Tel: 1-866-PLANAR1 (866-752-6271) or +1 503-748-1100 Hours: M-F, 8am - 8pm Eastern Time | M-F, 5am - 5pm Pacific Time © 2013 Planar Systems, Inc. Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners.
