060220-00 Rev. A
June 2007
OmniSwitch
Transceivers Guide
www.alcatel-lucent.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OmniSwitch 6800 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alcatel-Lucent OmniSwitch 6800 Series

Summary of Contents for Alcatel-Lucent OmniSwitch 6800 Series

  • Page 1 060220-00 Rev. A June 2007 OmniSwitch Transceivers Guide www.alcatel-lucent.com...
  • Page 2 OmniSwitch 6800, 6850 and 9000 Series of switches. The information described in this guide is subject to change without notice. Copyright © 2007 by Alcatel-Lucent. All rights reserved. This document may not be reproduced in whole or in part without the express written permission of Alcatel-Lucent.

  • Page 3: Table Of Contents

    10-Gigabit Small Form Factor Pluggables (XFPs) .......... 2-11 In This Chapter ......................2-11 XFP MSA Specification ....................2-12 10-Gigabit Ethernet Transceivers .................2-13 Chapter 3 SFP Compatibility Matrix ..................3-15 OmniSwitch 9000 Series ....................3-15 OmniSwitch 6850 Series ....................3-16 OmniSwitch 6800 Series ....................3-17 OmniSwitch Transceivers Guide June 2007...
  • Page 4 Contents Chapter 4 XFP Compatibility Matrix ..................4-18 OmniSwitch 9000 Series ....................4-18 OmniSwitch 6850 Series ....................4-18 OmniSwitch 6800 Series ....................4-19 OmniSwitch Transceivers Guide June 2007...

  • Page 5: About This Guide

    This OmniSwitch Transceivers Guide provides specifications and compatibility information for the supported OmniSwitch SFP and XFP transceivers. Supported Platforms This information in this guide applies to the following products: OmniSwitch 6800 Series • OmniSwitch 6850 Series • OmniSwitch 9000 Series •...

  • Page 6: Who Should Read This Manual

    Who Should Read this Manual? About This Guide Who Should Read this Manual? The audience for this user guide is network administrators and IT support personnel who need to provide network connectivity using SFP or XFP transceivers on an OmniSwitch. When Should I Read this Manual? Read this guide as soon as you are ready to integrate your OmniSwitch into your network and you are ready to provide connectivity using the supported transceivers.

  • Page 7: How Is The Information Organized

    About This Guide How is the Information Organized? How is the Information Organized? Chapters in this guide are broken down by transceiver type, SFP or XPF. Additional sub-sections are provided for the various types of SFP transceivers. Specification Information. Each transceiver has an associated table providing individual specifications for all supported transceivers.
  • Page 8 Documentation Roadmap About This Guide Stage 3: Integrating the Switch Into a Network Pertinent Documentation: Network Configuration Guide Advanced Routing Configuration Guide When you are ready to connect your switch to the network, you will need to learn how the OmniSwitch implements fundamental software features, such as 802.1Q, VLANs, Spanning Tree, and network routing protocols.

  • Page 9: Related Documentation

    About This Guide Related Documentation Related Documentation The following are the titles and descriptions of all the related OmniSwitch 6800/6850/9000 user manuals: OmniSwitch 6800 Family Getting Started Guide • Describes the hardware and software procedures for getting an OmniSwitch 6800 Family switch up and running.
  • Page 10 • Includes SFP and XFP transceiver specifications and product compatibility information. Technical Tips, Field Notices • Includes information published by Alcatel-Lucent’s Customer Support group. Release Notes • Includes critical Open Problem Reports, feature exceptions, and other important information on the features supported in the current release and any limitations to their support.

  • Page 11: User Manual Cd

    All user guides are included on the User Manual CD that accompanied your switch. This CD also includes user guides for other Alcatel-Lucent data enterprise products. In addition, it contains a stand-alone version of the on-line help system that is embedded in the OmniVista network management application.
  • Page 12 Technical Support About This Guide page xii OmniSwitch Transceivers Guide June 2007...

  • Page 13: Small Form-Factor Pluggables (Sfps)

    1 Small Form-Factor Pluggables (SFPs) OmniSwitch Series switches use both copper-based and fiber-based optical Small Form Factor Pluggable (SFP) transceivers. SFPs are fully hot-swappable and are available for both short-reach and long-reach applications. Copper-based and fiber-based optical SFPs can be mixed on the same module. In This Chapter This chapter describes the technical specifications for all the OmniSwitch supported SFP transceivers.

  • Page 14: Sfp Msa Specification

    SFP MSA Specification Small Form-Factor Pluggables (SFPs) SFP MSA Specification The Small Form-Factor Pluggable (SFP) MSA (Multi Source Agreement) is a specification for a common interface for optical modular transceivers. The SFP connector consists of a 20-pin receptacle and an SFP housing cage.

  • Page 15: Gigabit Ethernet Transceivers

    Small Form-Factor Pluggables (SFPs) Gigabit Ethernet Transceivers Gigabit Ethernet Transceivers SFP-GIG-SX 1000Base-SX Gigabit Ethernet optical transceiver. Supports multimode fiber and uses an LC connector. Connector Type Standards Supported 802.3z, SFP MSA Connections Supported 1000Base-SX Fiber Type Wavelength 850 nm Optical Power Output -9.5 to -4 dBm Receiver Sensitivity -17 dBm...
  • Page 16 Gigabit Ethernet Transceivers Small Form-Factor Pluggables (SFPs) Gigabit Ethernet Transceivers (cont.) SFP-GIG-LH70 1000Base-LH Gigabit Ethernet optical transceiver. Supports single mode fiber and uses an LC connector. Connector Type Standards Supported 802.3z, SFP MSA Connections Supported 1000Base-LH70 Fiber Type Wavelength 1550 nm Optical Power Output 0 to +5 dBm Optical Power Input...
  • Page 17 Small Form-Factor Pluggables (SFPs) Gigabit Ethernet Transceivers Gigabit Ethernet Transceivers (cont.) SFP-GIG-EXTND Extended 1000Base-SX Gigabit Ethernet optical transceiver. Supports multimode fiber and uses an LC connec- Connector Type Standards Supported 802.3z, SFP MSA Connections Supported 1000Base-SX Fiber Type Wavelength 850 nm Optical Power Output 0 to +5 dBm Optical Power Input...

  • Page 18: Dual-Speed Ethernet Transceivers

    Dual-Speed Ethernet Transceivers Small Form-Factor Pluggables (SFPs) Dual-Speed Ethernet Transceivers SFP-DUAL-MM Dual Speed 100Base-FX or 1000Base-LX Ethernet optical transceiver. Supports multimode fiber and uses an LC connector. Connector Type Standards Supported 802.3z, 802.3ah, SFP MSA Connections Supported 100Base-FX, 1000Base-LX Fiber Type Wavelength 1310 nm Average Power Output...

  • Page 19: Bi-Directional 100 Fx Ethernet Transceivers

    Small Form-Factor Pluggables (SFPs) Bi-directional 100 FX Ethernet Transceivers Bi-directional 100 FX Ethernet Transceivers SFP-100-BX20LT 100Base-BX SFP optical transceiver with an SC type interface. This bi-directional transceiver is designed for use over single mode fiber on a single strand. Connector Type Standards Supported 802.3ah, SFP MSA, ITU-T G.983 Connections Supported...

  • Page 20: 100 Fx Ethernet Transceivers

    100 FX Ethernet Transceivers Small Form-Factor Pluggables (SFPs) 100 FX Ethernet Transceivers SFP-100-LC-MM 100Base-FX SFP optical transceiver with an LC type interface. This transceiver is designed for use over multi- mode fiber. Connector Type Standards Supported 802.3u, SFP MSA Connections supported 100Base-FX Fiber Type Wavelength...
  • Page 21 Small Form-Factor Pluggables (SFPs) 100 FX Ethernet Transceivers 100 FX Ethernet Transceivers (cont.) SFP-100-LC-SM40 100Base-FX SFP optical transceiver with an LC type interface. This transceiver is designed for use over single mode fiber. Connector Type Standards Supported 802.3u, SFP MSA Connections Supported 100Base-FX Fiber Type...

  • Page 22: Cwdm Gigabit Ethernet Transceivers

    CWDM Gigabit Ethernet Transceivers Small Form-Factor Pluggables (SFPs) CWDM Gigabit Ethernet Transceivers SFP-GIG-CWD Coarse Wavelength Division Multiplexing (CWDM) is an optical transceiver supporting single-mode fiber over various wavelengths. CWDMs are hot-pluggable and are available for long-reach applications. Connector Type Standards Supported 802.3z, SFP MSA Connections Supported 1000Base-LX...

  • Page 23: 10-Gigabit Small Form Factor Pluggables (Xfps)

    10-Gigabit Small Form Factor Pluggables (XFPs) In This Chapter 2 10-Gigabit Small Form Factor Pluggables (XFPs) 10-Gigabit Small Form Factor Pluggables (XFPs) are fiber-based optical transceivers. XFPs are fully hot- swappable and are available for both short-reach and long-reach applications. In This Chapter This chapter describes the technical specifications for all the OmniSwitch supported XFP transceivers.

  • Page 24: Xfp Msa Specification

    XFP MSA Specification 10-Gigabit Small Form Factor Pluggables (XFPs) XFP MSA Specification The 10-Gigabit Small Form-Factor Pluggable (XFP) MSA (Multi Source Agreement) is a specification for a common interface for optical modular transceivers. The XFP connector consists of a 30-pin receptacle and an XFP housing cage.

  • Page 25: 10-Gigabit Ethernet Transceivers

    10-Gigabit Small Form Factor Pluggables (XFPs) 10-Gigabit Ethernet Transceivers 10-Gigabit Ethernet Transceivers 10G-XFP-SR 10GBase-SR XFP optical transceiver with an LC type interface. This transceiver is designed for use over single mode fiber. Connector Type Standards Supported 802.3ae, XFP MSA Connections Supported 10GBase-SR Fiber Type Wavelength...
  • Page 26 10-Gigabit Ethernet Transceivers 10-Gigabit Small Form Factor Pluggables (XFPs) 10-Gigabit Ethernet Transceivers (cont.) 10G-XFP-ER 10GBase-ER XFP optical transceiver with an LC type interface. This transceiver is designed for use over single mode fiber. Connector Type Standards Supported 802.3ae, XFP MSA Connections Supported 10GBase-ER Cable Type...

  • Page 27: Sfp Compatibility Matrix

    SFP Compatibility Matrix OmniSwitch 9000 Series 3 SFP Compatibility Matrix OmniSwitch 9000 Series The following table shows the Ethernet transceiver configurations and supported releases on the OmniSwitch 9000 Series: OS9-GNI-C20L OS9-GNI-U24 SFP-GIG-SX 6.1.5 SFP-GIG-LX 6.1.5 SFP-GIG-LH40 6.1.5 SFP-GIG-LH70 6.1.5 SFP-GIG-EXTND 6.1.5 SFP-GIG-CWD 6.1.5...

  • Page 28: Omniswitch 6850 Series

    OmniSwitch 6850 Series SFP Compatibility Matrix OmniSwitch 6850 Series The following table shows the Ethernet transceiver configurations and supported releases on the OmniSwitch 6850: OS6850 Combo Ports OS6850-U24X SFP-GIG-SX 6.1.3 SFP-GIG-LX 6.1.3 SFP-GIG-LH40 6.1.3 SFP-GIG-LH70 6.1.3 SFP-GIG-EXTND 6.1.3 SFP-GIG-CWD 6.1.3 SFP-GIG-T 6.1.3 SFP-DUAL-MM...

  • Page 29: Omniswitch 6800 Series

    SFP Compatibility Matrix OmniSwitch 6800 Series OmniSwitch 6800 Series The following table shows the Ethernet transceiver configurations and supported releases on the OmniSwitch 6800 Series: OS6800 Combo Ports OS6800-U24 SFP-GIG-SX SFP-GIG-LX SFP-GIG-LH40 SFP-GIG-LH70 SFP-GIG-EXTND SFP-GIG-CWD SFP-GIG-T 6.1.3 6.1.3 SFP-DUAL-MM not supported 6.1.3...

  • Page 30: Omniswitch 9000 Series

    OmniSwitch 9000 Series XFP Compatibility Matrix 4 XFP Compatibility Matrix OmniSwitch 9000 Series The following table shows the 10-Gigabit Ethernet transceiver configurations and supported releases on the OmniSwitch 9000 Series: OS9-XNI-U2 OS9-XNI-U6 10G-XFP-SR 10G-XFP-LR 10G-XFP-ER 10G-XFP-ZR OmniSwitch 6850 Series The following table shows the 10-Gigabit Ethernet transceiver configurations and supported releases on the OmniSwitch 6850: All OmniSwitch 6850 10-Gigabit Models 10G-XFP-SR...
  • Page 31 XFP Compatibility Matrix OmniSwitch 6800 Series OmniSwitch 6800 Series The following table shows the 10-Gigabit Ethernet transceiver configurations and supported releases on the OmniSwitch 6800: All OmniSwitch 6800 10-Gigabit Models 10G-XFP-SR 10G-XFP-LR 10G-XFP-ER 10G-XFP-ZR OmniSwitch Transceivers Guide June 2007 page 4-19...
  • Page 32 OmniSwitch 6800 Series XFP Compatibility Matrix page 4-20 OmniSwitch Transceivers Guide June 2007...
