American Standard 2742 Parts List

JET BODY
ASSEMBLY
Pump Suction Coupling
O-Ring
Pump Discharge Coupling
Air Control Valve
Air Control Valve Housing and Nut
Jet Nozzle Assembly
Escutcheon Assembly
Jet Body Assembly
Suction Guard
Suction Fitting
Suction Fitting Elbow
Discharge Tee
WOW Pump w/Air Switch (1 HP)
Air Switch
Air Actuator Cap and Body
Air Actuator Tubing
NOTE: Schedule 40 Rigid PVC Piping available through
See Section "J" for Additional Parts and Accessories.
Removal/installation requires tool part no. 047530-0070A.
Removal/installation requires tool part no. 047605-0070A.
P r o d u c t n a m e s l i s t e d h e r e i n a r e t r a d e m a r k s o f A m e r i c a n S t a n d a r d I n c .
A m e r i c a n S t a n d a r d I n c . 2 0 0 2
C
AIR ACTUATOR
CAP AND BODY
AIR CONTROL
AIR
VALVE
CONTROL
HOUSING
VALVE
AND NUT
ESCUTCHEON
ASSEMBLY
JET NOZZLE
ASSEMBLY
1/2" RIGID
PVC TUBING
DESCRIPTION
(See Section J)
local plumbing supply outlets.
AIR
ACTUATOR
TUBING
AIR SWITCH
(SEE SECTION J)
P/O
MOTOR
WOW
PUMP
SYSTEM I
1" RIGID
SUCTION
PVC TUBING
FITTING
PART NUMBER
047186-0070A
047187-0070A
047186-0070A
751676-XXX0A
068917-XXX0A
047587-XXX0A
047588-XXX0A
047627-0070A
047463-XXX0A
047550-XXX0A
047546-0070A
047438-0070A
752538-0070A
752388-0070A
752439-XXX0A
047602-0070A
TOWNSQUARE 6' x 42"
WHIRLPOOL
MODEL NUMBER
2742.018
2742.428
DISCHARGE
DISCHARGE
COUPLING
O-RING
PUMP
SUCTION
COUPLING
O-RING
SUCTION
GUARD
SUCTION
FITTING
ELBOW
PKG QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3 ft.
Replace XXX with
Fixture Color Code
TEE
PUMP
1-1/2" RIGID
PVC TUBING
H-111
