AXIS 540/640 User's Guide
Product Overview
The AXIS 540+/542+ Print Server
Ethernet
10base2
Connector
External Power
Supply Connector
The AXIS 640/642 Print Server
Token Ring
STP
Connector
External Power
Supply Connector
LPT1 Printer
Connector
Ethernet
or
10baseT
Connector
LPT1 Printer
Connector
Token Ring
or
UTP
Connector
Product Overview
Test Button
Network Indicator
Power Indicator
Ring Speed
Switch
(recessed)
Test Button
Network Indicator
Power Indicator
5
