1. Make sure that the power cord is unplugged.
Attach a Wheel (81) to the Base (80) with a 3/8" x
2 1/2" Bolt (2) and a 3/8" Nut (3). Do not over-
tighten the Nut; the Wheel must turn freely.
Attach the other Wheel (not shown) to the
other side of the Base (80) in the same way.
2. Remove the ties securing the Upright Wire (70) to
the Base (80). Pull the Upright Wire and the Base
Ground Wire (92) through the indicated hole in
the Base.
Attach the Base Ground Wire (92) to the Base
(80) with a #8 x 1/2" Ground Screw (1).
Press a Base Cap (77) into each side of the Base
(80). Press the Grommet (67) into the square
hole in the Base.
3. Identify the Left Upright (75), which is either
marked "Left" or "L." Have a second person hold
the Left Upright near the Base (80).
See the inset drawing. Tie the wire tie in the
Left Upright (75) securely around the end of the
Upright Wire (70). Then, pull the other end of the
wire tie until the Upright Wire is routed through
the Left Upright.
1
80
2
Hole
77
92
1
70
3
75
70
Wire Tie
7
2
81
67
80
70
75
Wire
Tie
80
3
