Goodman CVC9/95 Installation Instructions Manual

Goodman CVC9/95 Installation Instructions Manual

Cvc9/95 & mvc95 seies two-stage gas furnace
Hide thumbs Also See for CVC9/95:
Table of Contents

Advertisement

Quick Links

I
I
NSTALLATION
NSTRUCTIONS FOR
(Type FSP CATEGORY IV Direct or Non Direct Vent Air Furnace)
ATTENTION INSTALLING PERSONNEL
As a professional installer you have an obligation to know the product better than the customer. This includes all
Prior to actual installation, thoroughly familiarize yourself with this Instruction Manual. Pay special attention to all
safety warnings. Often during installation or repair it is possible to place yourself in a position which is more
Remember, it is your responsibility to install the product safely and to know it well enough to be able to instruct a
Safety is a matter of common sense...a matter of thinking before acting. Most dealers have a list of specific good
The precautions listed in this Installation Manual are intended as supplemental to existing practices.
there is a direct conflict between existing practices and the content of this manual, the precautions listed here
IO-341F
5/11
*CVC9/95 & *MVC95 - T
Installer: Affix all manuals adjacent to the unit.
These furnaces comply with requirements em-
bodied in the American National Standard / Na-
tional Standard of Canada ANSI Z21.47·CSA-2.3
Gas Fired Central Furnaces.
RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION.
safety precautions and related items.
hazardous than when the unit is in operation.
customer in its safe use.
safety practices...follow them.
*NOTE: Please contact your distributor
or our website for the applicable
Specification Sheet referred to in this manual.
5151 San Felipe Suite 500
www.goodmanmfg.com • www.amana-hac.com
© 2009-2011 Goodman Manufacturing Company, L.P.
take precedence.
Houston, TX 77056
-S
G
WO
TAGE
AS
®
C
US
F
URNACE
However, if

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CVC9/95 and is the answer not in the manual?

Questions and answers

Related Manuals for Goodman CVC9/95

Summary of Contents for Goodman CVC9/95

  • Page 1 NSTALLATION NSTRUCTIONS FOR (Type FSP CATEGORY IV Direct or Non Direct Vent Air Furnace) These furnaces comply with requirements em- bodied in the American National Standard / Na- tional Standard of Canada ANSI Z21.47·CSA-2.3 Gas Fired Central Furnaces. RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION.
