Brandt WFH1066K Installation, Operating And Maintenance Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

LAVE-LINGE
WASAUTOMAAT
VASKEMASKINE
WASCHMASCHINE

WASHING MACHINE

F
MANUEL D'INSTALLATION,
D'UTILISATION
ET D'ENTRETIEN
NL
HANDLEIDING VOOR
INSTALLATIE, GEBRUIK EN
ONDERHOUD
DK
INSTALLATIONS, BETJENINGS OG
VEDLIGEHOLDELSESVEJLEDNING
..............................................................Side 42
D
INSTALLATIONS-
GEBRAUCHS- UND
PFLEGEANLEITUNG
GB
INSTALLATION, OPERATION &
MAINTENANCE
INSTRUCTIONS
........................Page 2
......................Bladzijde 22
................Seite 62
..........................Page 82

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WFH1066K and is the answer not in the manual?

Questions and answers

Related Manuals for Brandt WFH1066K

Summary of Contents for Brandt WFH1066K

  • Page 1: Washing Machine

    LAVE-LINGE WASAUTOMAAT VASKEMASKINE WASCHMASCHINE WASHING MACHINE MANUEL D’INSTALLATION, D’UTILISATION ET D’ENTRETIEN ......Page 2 HANDLEIDING VOOR INSTALLATIE, GEBRUIK EN ONDERHOUD ......Bladzijde 22 INSTALLATIONS, BETJENINGS OG VEDLIGEHOLDELSESVEJLEDNING ..............Side 42 INSTALLATIONS- GEBRAUCHS- UND PFLEGEANLEITUNG ....Seite 62 INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS ......Page 82...

  • Page 2: Table Of Contents

    Contents Page • Safety instructions ......................• The environment and tips on saving energy ..............• Description of the machine .................... 1 - How to install your machine for the first time • Removing the transport clamps from your machine ..........•...

  • Page 3: Safety Instructions

    Safety instructions This machine is designed solely for domestic use, for washing, rinsing and spinning machine-washable textiles. You must comply with the following instructions. We will refuse any liability and rescind the guarantee if these recommendations are not observed, which can cause damage to equipment or physical injury.

  • Page 4: Description Of The Machine

    Description of the machine Control panel Detergent Dispensing Drawer Door Opener Door Drain pump access hatch Button to open the drain pump access hatch Adjustable feet Fixing screw for the top of the machine Water supply connection Securing screw Electrical power cable Drain hose...

  • Page 5: Removing The Transport Clamps From Your Machine

    Removing the transport clamps from your machine YOU MUST PERFORM THE OPERATIONS DESCRIBED BELOW BEFORE USING THE MACHINE These operations consist of removing all the elements designed to immobilize your machine's internal components while it is being transported. These so-called "releasing" operations are required for your machine to operate properly and to comply with the prevailing safety standards.

  • Page 6: Preparing To Install Your Machine

    Preparing to install your machine Your machine's surroundings: Fig. 4 If you are installing your machine next to another appliance or a unit, we recommend that you always leave a gap between them to help the air to circulate. On the other hand, we would strongly advise you NOT: - To install your machine in a damp, poorly ventilated room.

  • Page 7: Connecting The Water Supply

    Connecting your machine Connecting to the cold water supply To avoid any water leaks, remember to Connect the water hose (Fig. 6) : fit the rubber seals in each end and tighten your connections correctly. The - By screwing the elbowed end to the seals are provided in the accessories connection on the back of the machine bag.

  • Page 8: Connecting To The Drain

    Connecting your machine Draining away the waste water The hose must not be twisted or kinked and must be held by the hose hook to avoid it falling to the ground (Fig. 8). Connect the drain hose (Fig. 7) : The hose hook must be placed 40 to •...

  • Page 9: Preparing Your Washing (Sorting, Colour Test, Loads And Checks)

    Preparing your washing Sorting your washing Please ensure that all your items are machine-washable. Please refer to the labels on your items to select the most suitable programme . When washing a mixed load, use the programme suitable for its most fragile items. For new items, as a precaution, first of all check that they are colour-fast: see "Colour test"...

  • Page 10: Loading The Washing

    Loading your washing Proceed as follows: you close it. Open the machine • Close the door by pressing it gently. • Ensure that the door is locked. If it is not, a • To access the drum, pres the "Door" button safety system will prevent you from starting located just above the door.
  • Page 11 Programming Start/Pause: short press Cancel: long press Safety systems display: Tap closed, Foam detected, Child safety Selection: Child safety, Current time Cycle progress Stop, Type of items and Special programmes Remplacement Delayed Spin speed, Hold and Rinse, No spin Start control Options: Pre-wash, Extra rinse, Anti-crease Remplacement Delayed Start display...
  • Page 12 Programming Programming a washing cycle without options: Lights • Use the knob to select a programme(*) shows the maximum spin speed that the selected textile can withstand. • Use the button Spin speed light or "No spin" light - Either to alter the proposed spin speed, - Or to select No spin the cycle will finish by draining without a spin, or "Hold and Rinse"...

  • Page 13: Child Safety

    Programming Child safety: Lights and/or display • If you wish to protect your programme settings, use the "Child Safety" + The light is lit system by simultaneously holding down for at least 3 seconds the following throughout the cycle until it is buttons : "Pre-wash"...

  • Page 14: Programming / Cancelling A Programme

    Programming To select the most suitable programme for your type of washing, follow the instructions on the labels attached to most textiles. Programmes' table Type of textile COTTON - 90° SYNTHETICS Cold - 60° DELICATES - 40° Cold WOOLLENS - 40° Cold Special programmes HAND-WASHABLE TEXTILES...

  • Page 15: Details Of The Functions

    Details of the functions Then: Rinse only “ ” - Either you wish to drain and spin. A separate rinse, followed by: -Set the knob to “Spin" and use the - Either a spin and drain button , to select a suitable - Or drain only ("No Spin"...

  • Page 16: Altering A Washing Programme

    Altering a washing programme During programming : • When you have selected a "Delayed Start”, you can only activate the "Pre-wash" Any alteration is possible before you press the “ ” (anti-creasing) options "Start/Pause" button during the period before the cycle effectively starts.

  • Page 17: Automatic Safety Systems

    Automatic safety systems Door safety lock: Your washing machine is fitted with a safety system to limit spinning when it detects a As soon as the washing cycle starts, the door poorly distributed load (this poor distribution on your machine locks. is called an "imbalance").

  • Page 18: General Maintenance

    General maintenance Cleaning the machine • Run a 90°C washing cycle at least once a month. To clean the casing, the control panel and all the plastic components in Risk of frost general, use a sponge or a cloth dampened only with water and liquid If there is a risk of frost, disconnect the water soap.

  • Page 19: Cleaning The Filters

    Cleaning the filters Cleaning the pump filter slightly unscrew the filter by turning it anti- clockwise, This filter collects any small items that you - If your receptacle becomes full before you may have inadvertently left in the clothes and have drained the machine completely, prevents them from disrupting the pump's screw in the filter, empty your receptacle...

  • Page 20: Incidents That May Arise

    Incidents that may arise Some incidents may occur while you are using your machine; these are the points to check. Incidents Possible causes / remedies The cycle does not start • You have forgotten to press the "Start/Pause" button • There is no electricity to the machine: - Check that the plug is correctly connected.
  • Page 21 Problems that you can rectify yourself In this section, we explain how you can rectify these problems very easily. Your machine automatically detects certain operating faults and informs you of these by means of the indicator lights, which light up red. t t h h e e l l i i g g h h t t Causes / Remedies The water tap is closed.
