- Page 1 Electronic Air Cleaner MODELS CC & DC DIRECT DRIVE INSTALLATION AND OPERATION MANUAL MODEL DC MODEL CC...
-
Page 2: Table Of Contents
SMOKEETER MODELS CC/DC DIRECT DRIVE TABLE OF CONTENTS SECTION PAGE Specifications, Model CC ................i Specifications, Model DC................i Introduction ....................1 Inspection Note....................1 III. How Your SMOKEETER/CRYSTAL-AIRE Works...........1 Installation ....................2 Operation .....................4 Cleaning.......................4 THE FOLLOWING INFORMATION IS PROVIDED FOR TRAINED SERVICE PERSONNEL ONLY VII. - Page 3 SPECIFICATIONS — SMOKEETER MODEL CC-DAO SPECIFICATIONS — SMOKEETER MODEL DC-DAO • SHIPPING WT. — 380 LBS., 179 K.G. • HANGING WT. — 319 LBS., 145 K.G. • AIRFLOW AS SHOWN IS STANDARD (LEFT-TO-RIGHT) • AIR HANDLING CAPACITY: 2200 CFM...
-
Page 4: Introduction
It is subjected to rigorous quality control 1. PREFILTER(S) — evenly distributes the air across the checks before it leaves our factory. And, SMOKEETER is ionizing section to maximize efficiency. It traps the backed by a factory warranty as described on the larger particles that could short out the components. -
Page 5: Installation
UNIT MOUNTING openings at the corner of the unit; and turnbuckles are Models CC and DC are designed for ceiling mount only. used inbetween the rods to provide an easy method of They are provided with eyebolts for chain hanging. The unit leveling. - Page 6 1,000 lbs. safe working load is used (i.e. Star Double Expansion shield type - Cat. No. 7035-0000). The Model CC and DC Direct Drive units (115V) are provided with a 9' power cord with a three prong plug for WARNING: The units are not to be used for support connection to a 115V grounded outlet.
-
Page 7: Operation
OPERATION CLEANING For best results, your SMOKEETER should be start- This section is defined for cleaning and periodic mainte- ed before the air becomes contaminated, ensuring nance. The internal components must be removed prior clean air all the time. to cleaning. - Page 8 If a more thorough cleaning is required, the components can be cleaned by soaking in a hot CAUTION: Components must be properly installed solution of SMOKEETER brand detergent for 30 to as referenced in Figure 10. Failure to 60 minutes followed by agitation in the solution to install as shown may cause loss of high remove loosened dirt.
- Page 9 FIGURE 10 THE FOLLOWING SECTIONS ARE FOR THE USE OF TRAINED SERVICE PERSONNEL ONLY WARNING: THE FOLLOWING PROCEDURES WILL EXPOSE HAZARDOUS LIVE AND MOVING PARTS. DISCONNECT AIR CLEANER BEFORE PROCEEDING.
-
Page 10: Periodic Maintenance And Troubleshooting
Probe the ionizer at the ionizer wire support as voltage. shown in Figure 11. If ionizer voltage falls below 8 KV, the SMOKEETER is not operating efficiently. • Amp Probe — used to check motor current draw. HIGH VOLTAGE COMPONENTS POWER PACK —... -
Page 11: Parts Ordering
1. Light Disconnected — should read 10 to 15 V DC. rod as shown in Figure 12. If collection cell voltage 2. Light Connected — should read 3 to 5 V DC. falls below 4 KV, the SMOKEETER is not operating efficiently. •... - Page 12 TROUBLESHOOTING CHART PROBLEM CAUSE SOLUTION 1. Excessive dirt build-up or 1. Isolate problem between ionizer Continuous clicking noise. foreign matter causing arcing and collection cell as outlined in ionizer or collection cell. on page 7. 1. Excessive voltage to collection 1.
-
Page 13: Illustrated Parts
ILLUSTRATED PARTS FINAL ASSEMBLY SMOKEETER MODELS CC & DC — DIRECT DRIVE... - Page 14 ASSEMBLY SMOKEETER MODELS CC AND DC DIRECT DRIVE QUANTITY QUANTITY REQUIRED REQUIRED ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION — CABINET 32-0013 GROMMET 33-0001 FILTER, ALUMINUM MESH 30-0049 WASHER, 1/4" FLAT 3 (SELECT) 02-0089 IONIZER, 7 WIRE 30-0030 LOCK NUT, 1/4"...
- Page 15 AIRFOIL IONIZER ASSEMBLY* QUANTITY ITEM NO. PART NO. DESCRIPTION REQUIRED 30-0030 1/4 - 20 LOCK NUT 35-0027 4 (SELECT) 10-0465 CORNER CHANNEL (7 WIRE) 10-0426 CORNER CHANNEL (9 WIRE) 5 (SELECT) 37-0004 INSULATOR 37-0028 INSULATOR (CONVOLUTED) 6 (SELECT) 10-0570 IONIZER SUPPORT (7 WIRE) 10-0569 IONIZER SUPPORT (9 WIRE) 30-0142...
-
Page 16: Wiring Diagrams
* Lead on Model CC Direct Drive only. Model CC Direct Drive motor has low & high speed taps. Black lead is high speed. Red lead is low speed. - Page 17 UNITED AIR SPECIALISTS, INC, LIMITED WARRANTY UAS warrants all equipment manufactured and sold by UAS against defective parts and workmanship for one year from date of shipment to Purchaser, except that commercial or nonindustrial air cleaners (other than engineered systems) are warranted for three years from such date.
