  • Page 1 User manual Built In Electric Oven...
  • Page 2 Dear Customer Thank you for choosing one of our high quality products. With this appliance you will experience the perfect combination of functional design and cutting edge technology. Convince yourself that our appliances are engineered to deliver the best per formance and control indeed we are setting the highest standards of excel lence.

  • Page 3: Table Of Contents

    Contents Contents Operating Instructions Safety instructions Description of the Appliance General Overview The electronic oven controls Indicators Buttons Oven Features Oven accessories Before Using for the first time Setting the language Setting the clock Initial cleaning Using the Oven Menu operation in overview The Oven Functions menu The Options menu Use of the oven functions...
  • Page 4 Contents Oven interior Accessories Fat Filter Cleaning function for oven cleaner spray Performing Pyroluxe cleaning Shelf Support Rails Oven Lighting Oven door Oven door glass What to do if … Disposal Installation Instructions Safety information for the installer Guarantee/Customer Service Index Service...

  • Page 5: Operating Instructions

    Operating Instructions Operating Instructions Safety instructions This appliance conforms with the following EU Directives: – 73/23/EEC dated 19.02.1973 Low Voltage Directive – 89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending Directive 92/31/EEC – 93/68/EEC dated 22.07.1993 CE Marking Directive Electrical safety •...

  • Page 6: How To Avoid Damage To The Appliance

    Safety instructions How to avoid damage to the appliance • Do not line the oven with aluminium foil and do not place baking trays, pots, etc. on the oven floor, as the heat that builds up will damage the oven enamel. •...

  • Page 7: Description Of The Appliance

    Description of the Appliance Description of the Appliance General Overview Oven displays and buttons Door handle Full glass door...

  • Page 8: The Electronic Oven Controls

    Description of the Appliance The electronic oven controls Indicators Symbol status bar Menu status bar Text line ___________________ PROFI HOT AIR 150û c 12. 0 5 00. 0 6 Heat indicator Shelf positions Temperature Time Clock functions Meat core temperature Period of operation Menu status bar In the menu status bar the current position within a menu is shown by a flash...

  • Page 9: Buttons

    Description of the Appliance Buttons wm¸¹º»¼-+ Button Function To select oven functions. To move down and up in the menu. ¸ To open the Options menu. To close the Options menu (press and hold button). ¹ Confirm, change to the sub menu. º...

  • Page 10: Oven Features

    Description of the Appliance Oven Features Top heat and heating elements Oven lighting Shelf positions Meat probe socket Fat Filter Oven lighting Fan heating element Bottom Heat Oven shelf runners, removable...

  • Page 11: Oven Accessories

    Description of the Appliance Oven accessories Oven shelf For cookware, cake tins, roasts and grilled foods. Baking tray For cakes and biscuits. Roasting Pan For baking and roasting or as a pan for col lecting fat. Meat probe For determining exactly how far joints of meat are cooked.

  • Page 12: Before Using For The First Time

    Before Using for the first time Before Using for the first time Setting the language 1. When the appliance has been con LANGUAGE MENU nected to the electrical supply, ý ý ý ý ý ýþ ýþ ý ý ý ý ý SPRACHE EINSTELLEN LANGUAGE 888û...

  • Page 13: Setting The Clock

    Before Using for the first time Setting the clock 1. TIME OF DAY lights up. In the clock display you see 12.00. 2. Using the button, set TIME OF DAY the current time. ý ý ý ý ý ýþ ýþ ý ý...

  • Page 14: Initial Cleaning

    Before Using for the first time Initial cleaning Clean the oven before using it for the first time. Important: Do not use caustic or abrasive cleaning agents! These can damage the oven surfaces. For the metal surfaces, use commercially available cleaning agents. 1.

  • Page 15: Using The Oven

    Using the Oven Using the Oven Menu operation in overview Oven Menu Functions Menu Options PROFI HOT AIR RECIPE MENU AL GUSTO HOT AIR MEMORY MENU ¸ CONVENTIONAL CLEANING MENU ROTITHERM SETTINGS MENU ¹ DUAL GRILL SINGLE GRILL KEEP WARM DEFROST RAPID HEAT UP MENU BOTTOM HEAT...

  • Page 16: The Oven Functions Menu

    Using the Oven The Oven Functions menu • When you switch the appliance on, you find yourself in the Oven Functions menu. • Select the desired oven function using the arrow buttons . In the menu status bar, the currrent position within the menu is shown. Setting an example oven function 1.

  • Page 17: The Options Menu

    Using the Oven The Options menu • Using the OPTION button, open the Options menu. • Select the desired option using the arrow buttons . In the menu status bar, the current position within the menu is shown. • Use the OK button to change to the menu of the selected option.

  • Page 18: Use Of The Oven Functions

    Using the Oven Use of the oven functions The oven has the following functions: Heating Oven function Application element/fan PROFI HOT AIR For baking on up to three oven lev Top heat, bottom heat, els at the same time. rear wall heating Set the oven temperatures element, fan 20 40 °C lower than when using Con...

  • Page 19: Meat Programmes

    Using the Oven Meat programmes Meat programmes Application Weight range with weight input POULTRY Chicken, duck, goose 0.9 to 4.7 kg PORK Roast pork, shoulder of pork 1.0 to 3.0 kg BEEF Roast beef, pot roast 1.0 to 3.0 kg VEAL Roast veal 1.0 to 3.0 kg...

  • Page 20: Switching The Oven On And Off

    Using the Oven Switching the Oven On and Off Selecting an oven function 1. Switch appliance on using the ON/OFF button. ____________________ 2. Using the arrow buttons CONVENTIONAL select the desired oven function. ý ý ý ý ý ýþ ýþ ý ý...

  • Page 21: Cooling Fan

    Using the Oven Cooling fan The fan switches on automatically in order to keep the appliance’s surfaces cool. When the oven is switched off, the fan continues to run to cool the appliance down, then switches itself off automatically. Pre heating with the RAPID HEAT UP function After an oven function has been selected, with the additional function RAPID HEAT UP the pre heating time can be shortened.

  • Page 22: Heat Indicator

    Using the Oven Heat indicator Heating up indicator When the oven function has been CONVENTIONAL switched on the four bars that ý ý ý ý ý ýþ ýþ ý ý ý ý ý slowly light up one after the other 180û...

  • Page 23: Inserting The Oven Shelf, Baking Tray And Roasting Pan

    Using the Oven Inserting the Oven Shelf, Baking Tray and Roasting Pan Shelf runner safety and anti tip device As a shelf runner safety device, all insertable components have a small curved indentation at the bottom on the right and left hand edge. Always insert insertable components so that this indentation is at the back of the oven interior.

  • Page 24: Inserting/Removing The Grease Filter

    Using the Oven Inserting/Removing the Grease Filter Only use the grease filter when roasting to protect the rear heating elements from fat splashes. Inserting the grease filter Hold the grease filter by the grip and insert the two mounts down wards into the opening on the rear wall of the oven (fan opening).

  • Page 25: Setting Meat Probe Core Temperature

    Using the Oven Setting meat probe core temperature To switch the oven off when the temperature at the centre of a roast reaches a core temperature set by you. There are two temperatures to consider: – The oven temperature: See Roasting Table –...

  • Page 26: Removing The Meat Probe

    Using the Oven Removing the meat probe Warning: The meat probe is very hot. There is a risk of being burned when removing the plug and the tip of the meat probe. 1. Remove the meat probe’s plug from the socket and take the meat out of the oven.

  • Page 27: Automatic Programmes

    Using the Oven Automatic programmes In addition to the oven functions for individually setting baking and roasting, you have the option of working with various automatic programmes: 1. Meat programmes with weight input (OVEN FUNCTIONS menu) 2. Meat programmes with meat probe (OVEN FUNCTIONS menu) 3.

  • Page 28: Meat Programmes With Meat Probe

    Using the Oven Meat programmes with meat probe When the meat probe is plugged in, the OVEN FUNCTIONS menu offers addition al meat programmes with meat probe. These programmes offer optimum settings for each type of meat. Important: Only the meat probe supplied may be used. If replacing, please use only original replacement parts.

  • Page 29: Options

    Using the Oven Options RECIPE MENU in overview ¸ RECIPE MENU ¹ BAKING RECIPES ¹ LEMON SPONGE CAKE SWEDISH CAKE SPONGE CAKE CHEESE CAKE FRUIT CAKE STREUSEL PLAIT YEAST PLAIT ¹ WHITE BREAD BACK ROASTING RECIPES ¹ PIZZA POTATO GRATIN ONION TARTE QUICHE LORRAINE LASAGNE...

  • Page 30: Recipe Menu

    Using the Oven BAKING RECIPES and ROASTING RECIPES For this function, use the recipes supplied in the booklet “Tables, Tips and Reci pes”. This function offers optimum settings for each recipe. Selecting a recipe. _____ 1. Use the OPTION button to RECIPE MENU change to the Options menu.
  • Page 31 Using the Oven _______ 6. An acoustic signal will sound when ONION TARTE the cooking time has finished. í ý ý ý ý ýþ ýþ ý ÒÓ ý ý ý – “00:00:” flashes in the clock dis 280û c þ þ...
  • Page 32 Using the Oven In the category OTHER RECIPES you will find the following menu options: POWDER CAKE For baking ready made cakes and cake mixes. FROZEN PIZZA For baking ready made meals such as pizza, lasagne, gratins and chips from the deep freeze. DRYING HERBS For drying fruit, herbs and mushrooms.

  • Page 33: Memory Menu

    Using the Oven MEMORY MENU With this function you can save the optimum settings for your own recipes. The first three “Personal recipes” can be called up again directly in the Oven Functions menu. There are 10 memory positions available for recipes with pre set cooking times and 10 for recipes with pre set meat probe core temperatures.

  • Page 34: Overwriting A Memory Position

    Using the Oven 8. Use the button to move DAD’S PIZZA the dash to the right or the left. ý ý ý ý ý ýþ ýþ ý ý ý ý ý The next letter flashes and can be 280û c þ...

  • Page 35: Settings Menu

    Using the Oven SETTINGS MENU Independent of the current use of the oven, you can change various base set tings. These remain permanently set, until they are changed again. RAPID HEAT UP MENU The function RAPID HEAT UP MENU is automatically switched on with suitable oven functions.
  • Page 36 Using the Oven Adjusting SETTINGS MENU 1. Using the OPTION button, open the Options menu. 2. Using the arrow buttons select the menu option SETTINGS MENU. 3. Using the OK button, change to the SETTINGS MENU menu. 4. Using the arrow buttons go to the setting that you want to adjust.

  • Page 37: Clock Functions

    Using the Oven Clock Functions MINUTE MINDER To set a countdown. A signal sounds after the time has elapsed. This function does not affect the functioning of the oven. DURATION To set how long the oven is to be in use. To set when the oven is to switch off again.

  • Page 38: Minute Minder

    Using the Oven 2. Using the button, set MINUTE MINDER the desired Countdown time ý ý ý ý ý ýþ ýþ ý ý ý ñ ý (max. 99 minutes). 888û c þ þ ü þ 1 ü 4 . 3 ü 5 ý...
  • Page 39 Using the Oven DURATION 1. Select oven function and temperature. 2. Press the SELECTION button re DURATION peatedly until DURATION and the í ý ý ý ý ýþ ýþ ý ý ý ý ý symbol is displayed. 200û c þ þ...
  • Page 40 Using the Oven 1. Select the oven function and temperature. 2. Press the SELECTION button re peatedly until END and the symbol ý î ý ý ý ýþ ýþ ý ý ý ý ý are displayed. 200û c þ þ ü þ 1 ü 4 . 3 ü 5 ý...
  • Page 41 Using the Oven DURATION and END combined DURATION and END can be used simultaneously, if the oven is to be switched on and off automatically at a later time. 1. Select the oven function and temperature. 2. Using the DURATION function, DURATION set the time that the dish needs to...

  • Page 42: Additional Functions

    Using the Oven Additional functions CHILD LOCK for the oven As soon as the CHILD LOCK is activated, the appliance cannot be operated. Switching on the CHILD LOCK 1. If necessary, switch on the appliance using the ON/OFF button. No oven function must be selected. 2.

  • Page 43: Button Lock

    Using the Oven BUTTON LOCK To ensure that all oven functions set are not accidentally altered. Switching on BUTTON LOCK 1. If necessary, switch on the appliance using the ON/OFF button. 2. Select the oven function. BUTTON LOCK 3. Press the SELECTION ý...

  • Page 44: Cleaning And Care

    Cleaning and Care Cleaning and Care Warning: For cleaning, the appliance must be switched off and cooled down. Warning: For safety reasons, do not clean the appliance with steam jet or high pressure cleaning equipment. Attention: Do not use any scouring agents, sharp cleaning tools or scour ers.

  • Page 45: Cleaning Function For Oven Cleaner Spray

    Cleaning and Care Cleaning function for oven cleaner spray With the cleaning function for oven cleaner spray you can pre heat the oven to the optimum effective temperature for oven cleaner sprays. Important: Only use oven cleaner sprays that require the oven to be heated. Follow manufacturer’s instructions.
  • Page 46 Cleaning and Care 5. Spray oven cleaner spray inside the oven interior. After another 5 mins. another signal sounds for 2 minutes. By this time the spraying should be finished. (After this point the oven would already have cooled down too much). The time the oven cleaner spray needs to be left to work depends on the manu facturer’s instructions.

  • Page 47: Performing Pyroluxe Cleaning

    Cleaning and Care Performing Pyroluxe cleaning Warning: The oven gets very hot during this process. Keep small children away. Important Before carrying out the pyrolytic cleaning process, all removable parts, including the side rails, must be removed from the oven. If you use the oven shelf runners that are available as special accessories, these must be removed before pyrolytic cleaning.
  • Page 48 Cleaning and Care ____ 6. Using the arrow buttons PYROLUXE NORMAL select the length of Pyroluxe. í ý ý ý ý ýþ ýþ ý ý ý ý ý – PYROLUXE LIGHT for a light de 888û c þ þ ü þ 1 ü 5 . 0 ü 5 ý...

  • Page 49: Shelf Support Rails

    Cleaning and Care Shelf Support Rails The shelf support rails on the left and right hand sides of the oven can be re moved for cleaning the side walls. Removing the shelf support rails First pull the front of the rail away from the oven wall (1) and then unhitch at the back (2).

  • Page 50: Oven Lighting

    Cleaning and Care Oven Lighting Warning: There is a danger of electric shock! Prior to changing the oven light bulb: – Switch off the oven! – Remove the fuses in the fuse box or switch off the circuit breaker. Place a cloth on the oven floor to protect the oven light and glass cover. Replacing the oven light bulb/cleaning the glass cover 1.

  • Page 51: Oven Door

    Cleaning and Care Oven door For easier cleaning of the oven interior the oven door of your appliance can be taken off its hinges. Removing the oven door from its hinges 1. Open the oven door as far as it will go. 2.
  • Page 52 Cleaning and Care Hanging the oven door back on its hinges 1. From the handle side take hold of the oven door with a hand on each side and hold at an angle of approx. 45°. Position the recesses on the bottom of the oven door on the hinges on the oven.

  • Page 53: Oven Door Glass

    Cleaning and Care Oven door glass The oven door is fitted with four panels of glass mounted one behind the other. The inner panels can be removed for cleaning. Important Rough handling, especially around the edges of the front panel, can cause the glass to break.
  • Page 54 Cleaning and Care Cleaning the door glass panels Clean the door glass panels thoroughly with a solution of water and washing up liquid. Then dry them carefully. Putting the door glass panels back. 1. From above insert the door glass panels one after the other into the door profile at the bottom edge of the door at an angle and lower them.
  • Page 55 Cleaning and Care 3. Open the oven door as far as it will go. 4. Fold up the clamping levers (A) on both door hinges back into their original posi tions. 5. Close the oven door.

  • Page 56: What To Do If

    What to do if … What to do if … Problem Possible cause Remedy The oven does not heat The oven is not switched on Switch the oven on The clock is not set Set the current time on the clock The required settings have not Check the settings...

  • Page 57: Disposal

    Disposal Warning! Repairs to the appliance are only to be carried out by qualified service engineers. Considerable danger to the user may result from improper repairs. If the appliance has been wrongly operated, the visit from the customer service technician or dealer may not take place free of charge, even during the warranty period.

  • Page 58: Installation Instructions

    Installation Instructions Installation Instructions Attention: The new appliance may only be installed and connected by a regis tered expert. Please comply with this. If you do not, any damage resulting is not covered by the warranty. Safety information for the installer •...
  • Page 59 Installation Instructions...
  • Page 60 Installation Instructions...
  • Page 61 Installation Instructions...
  • Page 62 Installation Instructions...

  • Page 63: Guarantee/Customer Service

    European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these coun...
  • Page 64 Industriestrasse 10, CH 5506 Mägenwil Svizzera Electrolux Ljubljana d.o.o. Slovenija +38 61 24 25 731 Gerbiceva 98, 1000 Ljubljana Electrolux Slovakia s.r.o., Electrolux Domáce spot Slovensko +421 2 43 33 43 22 rebièe SK, Seberíniho 1, 821 03 Bratislava Suomi www.electrolux.fi...
  • Page 65 Guarantee/Customer Service Electrolux Service, S:t Göransgatan 143, Sverige +46 (0)771 76 76 76 S 105 45 Stockholm Tarlabaþý caddesi no : 35 Taksim Türkiye +90 21 22 93 10 25 Istanbul 129090 Ìîñêâà, Îëèìïèéñêèé Ðîññèÿ +7 095 937 7837 ïðîñïåêò, 16, ÁÖ „Îëèìïèê“...

  • Page 66: Index

    Index Index Memory menu Menu Accessories Options Oven Functions overview Baking tray Menu status bar Button lock Buttons Operating period indicator Oven Child lock accessories Cleaning light accessories Oven functions Oven interior Oven Shelf oven light bulb Oven shelf Oven spray Pre cleaning Pyroluxe Pre heating...

  • Page 67: Service

    Service Service In the event of technical faults, please first check whether you can remedy the problem yourself with the help of the operating instructions (section “What to do if…”). If you were not able to remedy the problem yourself, please contact the Cus tomer Care Department or one of our service partners.
  • Page 68 www.electrolux.com...
