Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
XJ6F
XJ6FA
1CW-28199-E0

Advertisement

Table of Contents
loading

Related Manuals for Yamaha XJ6F

Summary of Contents for Yamaha XJ6F

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XJ6F XJ6FA 1CW-28199-E0...
  • Page 2 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. DECLARATION of CONFORMITY Company: YAMAHA MOTOR ELECTRONICS CO., LTD. Address: 1450-6, Mori, Mori-Machi, Shuchi-gun, Shizuoka-Ken, 437-0292 Japan Hereby declare that the product:...
  • Page 3 Yamaha a reputation for dependability. Please take the time to read this manual thoroughly, so as to enjoy all advantages of your XJ6F/XJ6FA. The Owner’s Manual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and others from trouble and injury.

  • Page 4: Important Manual Information

    IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 XJ6F/XJ6FA OWNER’S MANUAL ©2009 by Yamaha Motor Co., Ltd. 1st edition, August 2009 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    FUNCTIONS ........3-1 OPERATION AND IMPORTANT play ........... 6-22 Immobilizer system ......3-1 RIDING POINTS......... 5-1 Brake light switches (XJ6F) ..6-23 Main switch/steering lock ....3-2 Starting the engine ......5-1 Brake light switches (XJ6FA)..6-23 Indicator and warning lights ....3-4 Shifting ........... 5-2 Checking the front and rear brake Multi-function meter unit ....3-8...
  • Page 7 ...........6-36 Replacing a turn signal light bulb ...........6-37 Replacing the license plate light bulb ...........6-37 Auxiliary light bulb ......6-38 Front wheel (XJ6F) ......6-38 Rear wheel (XJ6F) ......6-40 Troubleshooting ......6-42 Troubleshooting charts ....6-43 MOTORCYCLE CARE AND STORAGE ..........7-1 Matte color caution ......7-1 Care ..........7-1...

  • Page 8: Safety Information

    SAFETY INFORMATION EAU10283 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly...
  • Page 9 SAFETY INFORMATION due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective apparel...
  • Page 10 Yamaha accessories, which are avail- Shifting weights can create a sud- accessories to your motorcycle. Use able only from a Yamaha dealer, have den imbalance. Make sure that ac- extra care when riding a motorcycle been designed, tested, and approved cessories and cargo are securely that has added cargo or accessories.

  • Page 11: Specifications

    SAFETY INFORMATION modifications not specifically recom- clearance or cornering clearance, tor and may limit control ability, mended by Yamaha, even if sold and limit suspension travel, steering therefore, such accessories are installed by a Yamaha dealer. travel or control operation, or ob- not recommended.

  • Page 12: Description

    DESCRIPTION EAU10410 Left view 1. Air filter element (page 6-17) 9. Engine oil filter cartridge (page 6-11) 2. Idle adjusting screw (page 6-18) 10.Engine oil drain bolt (page 6-11) 3. Seat lock (page 3-18) 4. Main fuse (page 6-33) 5. Fuse box (page 6-33) 6.

  • Page 13: Right View

    DESCRIPTION EAU10420 Right view 1. Helmet holder (page 3-19) 9. Brake pedal (page 3-14) 2. Battery (page 6-32) 10.Rear brake light switch (page 6-23) 3. Rear brake fluid reservoir (page 6-24) 11.Shock absorber assembly spring preload adjusting ring (page 3-21) 4.

  • Page 14: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-13) 2. Left handlebar switches (page 3-12) 3. Main switch/steering lock (page 3-2) 4. Multi-function meter unit (page 3-8) 5. Front brake fluid reservoir (page 6-24) 6. Right handlebar switches (page 3-12) 7.

  • Page 15: Instrument And Control Functions

    Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.

  • Page 16: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS Keep other immobilizer system EAU10472 EAU38530 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power; the meter lighting, taillight, li- ference. cense plate light and auxiliary light come on, and the engine can be start- ed.
  • Page 17 INSTRUMENT AND CONTROL FUNCTIONS EAU10683 To unlock the steering ECA11020 LOCK NOTICE The steering is locked, and all electrical Do not use the parking position for systems are off. The key can be re- an extended length of time, other- moved.

  • Page 18: Indicator And Warning Lights

    The oil level warning 3 4 5 high beam of the headlight is switched light will flash ten times, then go off for 2.5 seconds. If this occurs, have a Yamaha dealer check the EAU11254 Oil level warning light “ ” vehicle.
  • Page 19 INSTRUMENT AND CONTROL FUNCTIONS For radiator-fan-equipped vehi- cles, the radiator fan(s) automati- cally switch on or off according to the coolant temperature in the ra- diator. If the engine overheats, see page 6-43 for further instructions.
  • Page 20 INSTRUMENT AND CONTROL FUNCTIONS Coolant Display Conditions What to do temperature Under 39 °C Message “Lo” is displayed. OK. Go ahead with riding. (Under 103 °F) 40–116 °C Temperature is displayed. OK. Go ahead with riding. (104–242 °F) Stop the vehicle and allow it to idle until 117–134 °C Temperature display flashes.
  • Page 21 If this oc- circuit. tem reverts to conventional braking. curs, have a Yamaha dealer check the Therefore, be careful not to cause When the key is turned to “OFF” and 30 self-diagnosis system. (See page 3-10...

  • Page 22: Multi-Function Meter Unit

    INSTRUMENT AND CONTROL FUNCTIONS EAU46763 multi-function meter unit Tachometer Multi-function meter unit equipped with the following: a speedometer a tachometer an odometer two tripmeters (which show the distance traveled since they were last set to zero) a fuel reserve tripmeter (which shows the distance traveled since the left segment of the fuel meter 1.

  • Page 23: Fuel Meter

    INSTRUMENT AND CONTROL FUNCTIONS Clock 5. Push the “RESET” button to set mode “F-TRIP” and start counting the the minutes. distance traveled from that point. In that 6. Push the “SELECT” button and case, push the “SELECT” button to then release it to start the clock. switch the display between the various tripmeter and odometer modes in the Odometer and tripmeter modes...
  • Page 24 3 NOTICE If a problem is detected in any of those seconds. If this occurs, have a Yamaha circuits, the engine trouble warning light Do not continue to operate the en- dealer check the electrical circuit.

  • Page 25: Anti-Theft Alarm (Optional)

    This model can be equipped with an If the display indicates an error this could be caused by transponder in- optional anti-theft alarm by a Yamaha code, the vehicle should be checked terference. If this error code appears, dealer. Contact a Yamaha dealer for as soon as possible in order to avoid try the following.

  • Page 26: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS EAU12348 Right position. To cancel the turn signal Handlebar switches lights, push the switch in after it has re- turned to the center position. Left EAU12500 Horn switch “ ” Press this switch to sound the horn. EAU12660 Engine stop switch “...

  • Page 27: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12733 EAU12820 EAU12870 Hazard switch “ ” Clutch lever Shift pedal With the key in the “ON” or “ ” posi- tion, use this switch to turn on the haz- ard lights (simultaneous flashing of all turn signal lights).

  • Page 28: Brake Lever

    Brake lever Brake pedal ABS (for ABS models) The brake lever is located at the right The Yamaha ABS (Anti-lock Brake handlebar grip. To apply the front System) features a dual electronic con- brake, pull the lever toward the handle- trol system, which acts on the front and bar grip.

  • Page 29: Fuel Tank Cap

    Open the fuel tank cap lock cover, in- required, so please consult your sert the key into the lock, and then turn Yamaha dealer when performing it 1/4 turn clockwise. The lock will be re- this test. leased and the fuel tank cap can be ECA16120 opened.

  • Page 30: Fuel

    INSTRUMENT AND CONTROL FUNCTIONS EAU13221 Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10881 WARNING not properly closed and locked.

  • Page 31: Fuel Tank Breather/Overflow Hose

    Make sure that the end of the fuel tank breather/overflow hose is not Your Yamaha engine has been de- blocked, and clean it if necessary. signed to use regular unleaded gaso- line with a research octane number of 91 or higher.

  • Page 32: Catalytic Converter

    INSTRUMENT AND CONTROL FUNCTIONS EAU13433 ECA10701 EAU32980 Catalytic converter Seat NOTICE This model is equipped with a catalytic Use only unleaded gasoline. The use converter in the exhaust system. To remove the seat of leaded gasoline will cause unre- 1. Insert the key into the seat lock, EWA10862 pairable damage to the catalytic WARNING...

  • Page 33: Helmet Holder

    INSTRUMENT AND CONTROL FUNCTIONS EAU46750 Helmet holder 1. Projection 1. Helmet 2. Seat holder 2. Helmet holding cable 1. Helmet holder 3. Helmet holder 2. Push the rear of the seat down to 2. Owner’s tool kit 3. Place the helmet on the right side lock it in place.

  • Page 34: Storage Compartment

    Do not exceed the load limit of 3 kg (7 lb) for the storage com- partment. Do not exceed the maximum load of XJ6F 185 kg (408 lb) XJ6FA 180 kg (397 lb) for the ve- hicle. When storing the Owner’s Manual or...

  • Page 35: Rear View Mirrors

    INSTRUMENT AND CONTROL FUNCTIONS EAU47260 EAU47000 Rear view mirrors Adjusting the shock absorber The rear view mirrors of this vehicle can assembly be folded forward for parking in narrow This shock absorber assembly is spaces. Fold the mirrors back to their equipped with a spring preload adjust- original position before riding.

  • Page 36: Sidestand

    INSTRUMENT AND CONTROL FUNCTIONS Do not tamper with or attempt to EAU15303 below and have a Yamaha dealer re- Sidestand open the cylinder assembly. pair it if it does not function proper- The sidestand is located on the left side Do not subject the shock ab- of the frame.

  • Page 37: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS EAU44902 Ignition circuit cut-off system The ignition circuit cut-off system (com- prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions. It prevents starting when the trans- mission is in gear and the side- stand is up, but the clutch lever is not pulled.
  • Page 38 ”. stand during this inspection. • 3. Turn the key on. If a malfunction is noted, have a Yamaha 4. Shift the transmission into the neutral position. dealer check the system before riding. 5. Push the start switch. Does the engine start? With the engine still running: The neutral switch may not be working correctly.

  • Page 39: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 6-14 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 40 • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-19, 6-28 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-28 •...
  • Page 41 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 3-22 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 42: Operation And Important Riding Points

    Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this position.

  • Page 43: Shifting

    (See page 5-2.) The quate lubrication may damage neutral indicator light should come the transmission. 1. Shift pedal on. If not, ask a Yamaha dealer to 2. Neutral position Always use the clutch while check the electrical circuit. changing gears to avoid damag- Shifting gears lets you control the 3.

  • Page 44: Tips For Reducing Fuel Consumption

    Yamaha dealer check the vehi- to the correct operating clearances. Turn the engine off instead of let- cle.

  • Page 45: Parking

    OPERATION AND IMPORTANT RIDING POINTS EAU17213 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10311 WARNING Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them and be burned.

  • Page 46: Periodic Maintenance And Adjustment

    If If you do not have the tools or experi- you are not familiar with vehicle ser- ence required for a particular job, have vice, have a Yamaha dealer perform a Yamaha dealer perform it for you. service.

  • Page 47: Periodic Maintenance Chart For The Emission Control System

    From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi). Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.

  • Page 48: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU1770C General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ Air filter element •...
  • Page 49 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check chain slack, alignment and condition. Every 1000 km (600 mi) and after washing the motorcycle, riding in the rain or Drive chain •...
  • Page 50 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Change. √ √ √ √ √ √...
  • Page 51 PERIODIC MAINTENANCE AND ADJUSTMENT Hydraulic brake service • Regularly check and, if necessary, correct the brake fluid level. • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid. • Replace the brake hoses every four years and if cracked or damaged.

  • Page 52: Removing And Installing Cowlings And Panels

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18712 EAU46740 Removing and installing cowl- Cowling A ings and panels To remove the cowling The cowlings and panels shown need Remove the bolts, and then take the to be removed to perform some of the cowling off.
  • Page 53 PERIODIC MAINTENANCE AND ADJUSTMENT 2. Remove the quick fastener and the bolts, and then take the cowl- ing off. 1. Turn signal light lead 3. Install cowling A. 2. Guide 3. Turn signal light lead coupler EAU46770 Panel A 1. Cowling B To install the cowling 2.
  • Page 54 PERIODIC MAINTENANCE AND ADJUSTMENT 1. Panel A 1. Panel B 3. Pull the panel backward to remove 2. Bolt 2. Quick fastener 3. Quick fastener 3. Bolt 2. Slide the panel backward, and To install the panel then lift up the rear of the panel Place the panel in the original position, slightly.

  • Page 55: Checking The Spark Plugs

    Do not attempt to diagnose wipe off any grime from the spark plug such problems yourself. Instead, have threads. a Yamaha dealer check the vehicle. If a spark plug shows signs of electrode Tightening torque: Spark plug: erosion and excessive carbon or other 12.5 Nm (1.25 m·kgf, 9.0 ft·lbf)

  • Page 56: Engine Oil And Oil Filter Cartridge

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU46721 Engine oil and oil filter car- If a torque wrench is not available when tridge installing a spark plug, a good estimate The engine oil level should be checked of the correct torque is 1/4–1/2 turn before each ride.
  • Page 57 An oil filter wrench is available at a en the oil filler cap. Yamaha dealer. To change the engine oil (with or 6. Apply a thin coat of clean engine oil to the O-ring of the new oil filter without oil filter cartridge replace- cartridge.
  • Page 58 8. Install the engine oil drain bolt and In order to prevent clutch slip- off and have a Yamaha dealer check its new gasket, and then tighten page (since the engine oil also the vehicle.

  • Page 59: Coolant

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU20070 Coolant The coolant level should be checked before each ride. In addition, the cool- ant must be changed at the intervals specified in the periodic maintenance and lubrication chart. EAU47330 To check the coolant level 1.
  • Page 60 EAU47321 To change the coolant water has been added to the 1. Place the vehicle on a level sur- coolant, have a Yamaha dealer face and let the engine cool if nec- check the antifreeze content of essary. the coolant as soon as possible, 2.
  • Page 61 16. Remove the radiator cap to check the vehicle for coolant leakage. If Coolant drain bolt: the coolant level in the radiator. If coolant is leaking, have a Yamaha 10 Nm (1.0 m·kgf, 7.2 ft·lbf) necessary, add sufficient coolant dealer check the cooling system.

  • Page 62: Replacing The Air Filter Element

    1. Bolt are not pinched. If any hose is 1. Air filter element 4. Remove the air filter case cover by damaged, have a Yamaha dealer 2. Air intake manifold removing the screws. NOTICE: replace the hose before starting When removing the air filter...

  • Page 63: Adjusting The Engine Idling Speed

    If the specified idling speed cannot be follows at the intervals specified in the obtained as described above, have a periodic maintenance and lubrication Yamaha dealer make the adjustment. chart. The engine should be warm before making this adjustment. Check the engine idling speed and, if necessary, adjust it to specification by turning the idle adjusting screw.

  • Page 64: Checking The Throttle Cable Free Play

    To prevent this cle, note the following points regarding from occurring, the valve clearance the specified tires. must be adjusted by a Yamaha dealer at the intervals specified in the periodic Tire air pressure maintenance and lubrication chart.
  • Page 65 Rear: cle with excessively worn tires 250 kPa (2.50 kgf/cm², 36 psi) decreases riding stability and XJ6F 90–185 kg (198–408 lb) can lead to loss of control. XJ6FA 90–180 kg (198–397 lb): Front: The replacement of all wheel 250 kPa (2.50 kgf/cm², 36 psi)
  • Page 66 This motorcycle is fitted with super- ed below have been approved for this high-speed tires. Note the following model by Yamaha Motor Co., Ltd. points in order to make the most ef- ficient use of these tires. Use only the specified replace- ment tires.

  • Page 67: Cast Wheels

    If any damage is 2. Remove cowlings A and B. (See found, have a Yamaha dealer re- page 6-7.) place the wheel. Do not attempt 3. Loosen the locknut further down even the smallest repair to the the clutch cable.

  • Page 68: Brake Light Switches (Xj6F)

    The brake light, which is activated by the brake pedal and brake lever, should come on just before braking takes ef- fect. If necessary, have a Yamaha deal- er adjust the brake light switches. 1. Locknut (clutch cable) 2. Clutch lever free play adjusting nut (clutch cable) 1.

  • Page 69: Checking The Front And Rear Brake Pads

    EAU39371 Checking the front and rear Checking the brake fluid level peared, have a Yamaha dealer replace brake pads the brake pads as a set. Front brake The front and rear brake pads must be...

  • Page 70: Changing The Brake Fluid

    Changing the brake fluid is above the minimum level mark and ter the brake fluid reservoir when Have a Yamaha dealer change the replenish if necessary. A low brake fluid refilling. Water will significantly brake fluid at the intervals specified in...

  • Page 71: Drive Chain Slack

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU22760 Drive chain slack: Drive chain slack 45.0–55.0 mm (1.77–2.17 in) Using the alignment marks on each The drive chain slack should be side of the swingarm, make sure that checked before each ride and adjusted 5.

  • Page 72: Cleaning And Lubricating The Drive Chain

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU23025 may contain substances that Cleaning and lubricating the could damage O-rings. drive chain [ECA11111] The drive chain must be cleaned and lubricated at the intervals specified in the periodic maintenance and lubrica- tion chart, otherwise it will quickly wear out, especially when riding in dusty or wet areas.

  • Page 73: Checking And Lubricating The Cables

    Yamaha dealer at the intervals speci- ed if necessary. If a cable is damaged fied in the periodic maintenance chart.

  • Page 74: Checking And Lubricating The Brake And Clutch Levers

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU23142 Recommended lubricant: Recommended lubricants: Checking and lubricating the Lithium-soap-based grease Brake lever: brake and clutch levers Silicone grease Clutch lever: Brake lever Lithium-soap-based grease Clutch lever The operation of the brake and clutch levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 75: Checking And Lubricating The Centerstand And Sidestand

    The operation of the centerstand and The swingarm pivots must be lubricat- sidestand should be checked before ed by a Yamaha dealer at the intervals each ride, and the pivots and metal-to- specified in the periodic maintenance metal contact surfaces should be lubri- and lubrication chart.

  • Page 76: Checking The Front Fork

    2. Hold the lower ends of the front fork does not operate smoothly, tion. WARNING! To avoid injury, fork legs and try to move them for- have a Yamaha dealer check or re- securely support the vehicle so ward and backward. If any free pair it.

  • Page 77: Checking The Wheel Bearings

    EWA10760 WARNING To charge the battery Electrolyte is poisonous and Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to furic acid, which causes severe have discharged. Keep in mind that the burns.

  • Page 78: Replacing The Fuses

    XJ6F you do not have access to a con- stant-voltage battery charger, have a Yamaha dealer charge your battery. To store the battery 1. If the vehicle will not be used for more than one month, remove the battery, fully charge it, and then place it in a cool, dry place.
  • Page 79 PERIODIC MAINTENANCE AND ADJUSTMENT XJ6F XJ6FA XJ6FA 1. Taillight fuse 1. Starter relay cover 1. Taillight fuse 2. Spare fuse 2. Main fuse 2. ABS control unit fuse 3. Headlight fuse 3. Spare main fuse 3. ABS solenoid fuse 4. Ignition fuse 4.

  • Page 80: Replacing The Headlight Bulb

    4. If the fuse immediately blows EAU47410 Replacing the headlight bulb avoid causing extensive dam- again, have a Yamaha dealer This model is equipped with a quartz age to the electrical system and check the electrical system. bulb headlight. If the headlight bulb possibly a fire.

  • Page 81: Replacing The Tail/Brake Light Bulb

    5. Install the headlight bulb cover, 3. Remove the burnt-out bulb by pull- and then connect the coupler. ing it out. 6. Install the cowlings. 7. Have a Yamaha dealer adjust the headlight beam if necessary. 1. Headlight bulb cover 2. Headlight coupler 6-36...

  • Page 82: Replacing A Turn Signal Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU24204 EAU24313 Replacing a turn signal light Replacing the license plate bulb light bulb 1. Remove the turn signal light lens 1. Remove the license plate light unit by removing the screw. by removing the screws. 1.

  • Page 83: Auxiliary Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU39020 EAU44790 Auxiliary light bulb Front wheel (XJ6F) EWA14840 WARNING For the ABS model, have a Yamaha dealer remove and install the wheel. EAU42641 To remove the front wheel EWA10821 WARNING 1. License plate light bulb socket 2.
  • Page 84 PERIODIC MAINTENANCE AND ADJUSTMENT 4. Take the motorcycle off the center- stand so that the front wheel is on the ground, and then put the side- stand down. 5. Tighten the wheel axle, the front wheel axle pinch bolt and the brake caliper bolts to the specified torques.

  • Page 85: Rear Wheel (Xj6F)

    The drive chain does not need to be EWA14840 WARNING disassembled in order to remove and install the rear wheel. For the ABS model, have a Yamaha dealer remove and install the wheel. 6. While supporting the brake caliper and slightly lifting the wheel, pull EAU32874 the wheel axle out.
  • Page 86 PERIODIC MAINTENANCE AND ADJUSTMENT 7. Remove the wheel. NOTICE: Do Tightening torques: not apply the brake after the Axle nut: wheel has been removed to- 90 Nm (9.0 m·kgf, 65 ft·lbf) Locknut: gether with the brake disc, oth- 16 Nm (1.6 m·kgf, 11 ft·lbf) erwise the brake pads will be forced shut.

  • Page 87: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 88: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 89 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 90: Motorcycle Care And Storage

    Rust and corrosion can develop matte colored finished parts. Be Cleaning even if high-quality components are sure to consult a Yamaha dealer for ECA10772 advice on what products to use be- used. A rusty exhaust pipe may go un- NOTICE fore cleaning the vehicle.
  • Page 91 MOTORCYCLE CARE AND STORAGE off any detergent residue using Test the product on a small hid- plenty of water, as it is harmful den part of the windshield to Salt sprayed on roads in the winter may to plastic parts. make sure that it does not leave remain well into spring.

  • Page 92: Storage

    WARNING To prevent corrosion, avoid Contaminants on the brakes or tires Consult a Yamaha dealer for ad- damp cellars, stables (because can cause loss of control. vice on what products to use. of the presence of ammonia)
  • Page 93 MOTORCYCLE CARE AND STORAGE 3. Perform the following steps to pro- 4. Lubricate all control cables and the tect the cylinders, piston rings, etc. pivoting points of all levers and from corrosion. pedals as well as of the side- a. Remove the spark plug caps stand/centerstand.

  • Page 94: Specifications

    NGK/CR9E –20 –10 0 10 20 30 40 50 ˚C With oil and fuel: Spark plug gap: XJ6F 215 kg (474 lb) 0.7–0.8 mm (0.028–0.031 in) Recommended engine oil grade: XJ6FA 220 kg (485 lb) Clutch: API service SG type or higher, JASO...
  • Page 95 Wheel type: 37/19 (1.947) Loading: Cast wheel 3rd: Maximum load: Rim size: 28/18 (1.556) XJ6F 185 kg (408 lb) 17M/C x MT4.50 4th: XJ6FA 180 kg (397 lb) Front brake: 32/24 (1.333) (Total weight of rider, passenger, cargo and Type:...
  • Page 96 SPECIFICATIONS Wheel travel: Oil level warning light: Backup fuse: 130.0 mm (5.12 in) 7.5 A Electrical system: Turn signal indicator light: Ignition system: Coolant temperature warning light: TCI (digital) Charging system: Engine trouble warning light: AC magneto Battery: ABS warning light: Model: XJ6FA LED GT12B-4...

  • Page 97: Consumer Information

    Record the vehicle identification num- ber and model label information in the spaces provided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehicle is stolen. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1.
  • Page 98 Rear view mirrors ........3-21 Brake fluid level, checking ....6-24 Fuses, replacing ........6-33 Brake lever..........3-14 Safety information ........1-1 Brake light switches (XJ6F) ....6-23 Handlebar position, adjusting ....3-20 Seat............3-18 Brake light switches (XJ6FA) ....6-23 Handlebar switches ......3-12 Shifting ............5-2...
  • Page 99 Troubleshooting charts ......6-43 Turn signal indicator light......3-4 Turn signal light bulb, replacing.... 6-37 Turn signal switch......... 3-12 Valve clearance ........6-19 Vehicle identification number....9-1 Wheel bearings, checking ....6-32 Wheel (front) (XJ6F) ......6-38 Wheel (rear) (XJ6F)......6-40 Wheels..........6-22...
  • Page 102 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2009.09-0.4×1 CR...
