- Page 1 WH105 AUTOMOTIVE STEREO HEADPHONE SYSTEM OWNER'S MANUAL INSTALLATION GUIDE...
-
Page 2: Table Of Contents
FCC Statement Even though this manual provides general installation and opera- tion instructions for your new Clarion WH 105 RF Headphones, it does not show the exact installation methods for your particular vehicle. -
Page 3: Introduction
Additional Headphones To start enjoying your new Clarion WH105 system, please The Clarion WH105 allows users to take full advantage of read all remaining instructions listed in this manual. Keep the benefits of RF audio transmission and its ability to all instructions for future reference. -
Page 4: Description Of Headphone Controls
Description Of Headphone Controls 1. Battery Cover Remove the cover and place 2 Alkaline AM batteries in the RF Headphones compartment 2. Power ON/OFF Switch Main power switch turns headphone power off to prevent accidental micro switch activation during storage. 3. -
Page 5: Description Of Rf Transmitter Box
Description RF Transmitter Box RF Wireless Automotive Transmitter i.Power Input 2.RCA Plug (Left Channel) 3.RCA Plug (Right Channel) 4.Power ON/OFF Switch 5.Channel Select Switch (Channel 1, Channel 2) 6.Antenna Cord RF Transmitter Specifications RF Wireless Transmitter General Specifications WHlOS Power Requirement: 12 Vdc Power Consumption: 1 watt, Power On... -
Page 6: Battery Installation
Battery Installation Operation Description 1. Open the battery compartment by sliding the PLEASE READ CAREFULLY TO PREVENT cover towards the bottom of the Headphone. DAMAGE TO THE HEADPHONES OR YOUR EARS. 2. Place two (2) alkaline AAA batteries into the battery compartment of the Headphone(s), 1. -
Page 7: Installation
Wiring Precautions • This unit operates on an automotive 12-volt negative ground • Do not allow liquids or foreign objects to enter the WH105 RF power source and requires additional mobile audio and video Transmitter or Headphones. components for proper operation. -
Page 8: Wiring Description
Wiring Description Antenna Riaht Channel Clarion k--' Left Channel iL-o RFWift:r~ffjfj. TrtJrJ!>rnlttC'r WHIGS Red Wire -'" RCA Inpu tfrom Audio S ouree To Aeeessory +12V Mounting The Transmitter • Do not cut the antenna or alter its length in any way, as it will change the operating frequency. -
Page 9: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an automotive installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio commun- ications. - Page 10 PIN; R90777V002...
- Page 11 CAR AUDIOOBEYOND 661 W. Redondo Beach Blvd. Gardena, CA 90247 1-800-GO-CLARION www.c1arion-usa.com Rev. 0 (09/00) ©2000 Clarion Sales Corporation...
