Network Equipment Surge Protector
Your RadioShack Network Equipment Surge
Protector provides excellent surge protection
against unforeseen surges such as electro-
static discharge, lightning, and ground surge.
The surge protector works with a wide vari-
ety of network communication equipment, in-
cluding a personal computer (PC), plotter,
printer, fax, and answering machine. It is
also an ideal surge protector for USB hubs
and cable modems.
Important: A surge or spike beyond the
specified limits might overload the protection
circuitry and make it inactive. If this happens,
the surge protector should absorb enough of
the surge to protect the connected equip-
ment, but it will not protect against future
surges and spikes. If a spike occurs and the
green
PROTECTED WHEN LIT
out, replace the surge protector.
Your surge protector's features include:
8 AC Outlet Surge Protectors with AC
Adapter Spacing — let you plug up to 8 de-
vices into your surge protector.
Swift Detection of Power Surges — de-
tects and protects against a power surge of
up to 6,000 volts and 70,500 amps within 1
nanosecond (1 billionth of a second).
Broadband ADSL Modem Surge Protector
— provides two-line protection against surg-
es from a connected fax modem or ADSL
data connection.
Safety Alarm — sounds a buzzer when the
AC line is no longer protected.
Power Cord with Right Angle Plug — en-
sures secure power cord connection.
OWNER'S MANUAL — Please read before using this equipment.
WARNING:
shock hazard, do not expose this product to rain
or moisture.
CAUTION:
ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER-SERVICE-
ABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED PERSONNEL.
indicator goes
Cautions:
• This product is intended for indoor use
• This surge protector is not a lightning
• Be sure the total power requirements of
©
2000 RadioShack Corporation. All Rights Reserved.
RadioShack and RadioShack.com are trademarks
To reduce the risk of fire or
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
TO REDUCE THE RISK OF
This symbol is intended to alert
you to the presence of uninsu-
lated dangerous voltage within
the product's enclosure that might
be of sufficient magnitude to con-
stitute a risk of electric shock. Do
not open the product's case.
This symbol is intended to inform
you that important operating and
!
maintenance
instructions
included in the literature accom-
panying this product.
only.
arrestor and will not protect against light-
ning-induced voltage surges.
all connected devices does not exceed
1,875 watts.
used by RadioShack Corporation.
!
are

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the network equipment surge protector and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Radio Shack network equipment surge protector

Summary of Contents for Radio Shack network equipment surge protector

  • Page 1 Network Equipment Surge Protector OWNER’S MANUAL — Please read before using this equipment. Your RadioShack Network Equipment Surge WARNING: To reduce the risk of fire or Protector provides excellent surge protection shock hazard, do not expose this product to rain against unforeseen surges such as electro- or moisture.

  • Page 2: Safety Precautions

    • Use the surge protector only with a three- SAFETY PRECAUTIONS prong standard AC plug and outlet or a Your Network Equipment Surge Protector grounded two-to-three prong adapter. connects your fax, modem or other data line The surge protector cannot provide pro- to a telephone line.
  • Page 3 INSTALLATION CONNECTIONS PC Power LAN Cable You can place the surge protector on a level Cord surface or mount it on a wall. Select a location that is: Wall Monitor Telephone Jack • near an AC outlet • near a telephone line jack •...
  • Page 4 OPERATION Under Normal Conditions Push down. POWER PROTECTED WHEN LIT light. The connect- GROUNDED WHEN LIT ed devices are under the surge protector's protection. Cautions: does not light, your GROUNDED WHEN LIT surge protector is not grounded. You must move it to a different grounded, three-prong AC outlet.
  • Page 5 CARE Keep the surge protector dry; if it gets wet, wipe it dry immediately. Use and store the surge protector only in normal temperature environments. Handle the surge protector carefully; do not drop it. Keep the surge pro- tector away from dust and dirt, and wipe it with a damp cloth occasionally to keep it looking new.

  • Page 6: Specifications

    SPECIFICATIONS Number of AC Outlets ..........................Eight Circuit Breaker ............................15A Housing Material ............................ Plastic Electrical Rating ......................... 125V, 15A, 1875W Cord Length ......................7 ft with Right Angle Plug Joules Rating/8x20µS ..........................1284J Surge Current ............................. 70,500 A Response Time ......................... 1 Nanosecond Number of Lines Protected ........
  • Page 7 NOTES...
  • Page 8 LIMITED FIVE-YEAR WARRANTY AND CONNECTED EQUIPMENT GUARANTEE LIMITED WARRANTY — This surge protector product is warranted by RadioShack to the original purchaser against manufacturing defects in material and workmanship under normal use for five (5) years from the date of purchase (the “Warranty Period”) from RadioShack company owned stores and authorized RadioShack franchisees and dealers.
