Diesel portable generator
Hide thumbs

Advertisement

Model
AC Output
AC Frequency (Hz)
AC Output voltage (V)
Rated AC Output (W)
Rated Current (A)
Circuit Breaker (A)
Power Factor
Engine
Engine Number
Engine Type
Displacement (cc)
Starting System
Fuel Type
Eubrication oil
Run Time
Fuel Tank Capacity (l)
Max. Output (hp)
Max Output (rpm)
Full Load (h)
Half Load (h)
Approvals
CE
Euro Emission
4m Noise Level LpA dB (A)
4m Noise Level LwA dB (A)
7m Noise Level LpA dB (A)
7m Noise Level LwA dB (A)
KNOW YOUR GENERATOR
See Figure 2.
The safe use of this product requires an understanding of the
information on the product and in this operator's manual as well
as a knowledge of the project you are attempting. Before use
of this product, familiarise yourself with all operating features
and safety rules.
English
fEATUREs
AGN5000DEB
50
230
4,500
19.6
20
1.0
UD186
Single-Cylinder; 4-storke;
Air-cooled; Diesel
418
DC Start
Diesel
SAE 10W/30
11.5
10.0
3,600
6.5
11.0
YES
YES
76
96
71
91
AC CIRCUIT BREAKER
The circuit breaker is provided to protect the generator against
electrical overload and can be used to turn the generator's
electrical power on or off.
AIR FILTER
The air filter helps to limit the amount of dirt and dust drawn
into the unit during operation.
DECOMPRESSION LEVER
The decompression lever is used when starting the engine.
ENGINE SPEED LEVER
The engine speed lever is used in combination with the recoil
starter grip to start the generator. It is also used to turn the
generator off.
FUEL LEVEL GAUGE
Consult the fuel level gauge to determine the amount of fuel
remaining in the generator.
FUEL TANK
The fuel tank capacity is 11.5L for diesel generator.
FUEL VALVE
The flow of fuel through the generator is controlled by the
position of the fuel valve.
GROUND TERMINAL
The ground terminal is used to assist in properly grounding
the generator to help protect against electrical shock. Consult
with a local electrician for grounding requirements in your area.
OIL DRAINAGE BOLT
When changing the engine oil, the oil drainage bolt is loosened
to allow old engine oil to be drained.
OIL CAP/DIPSTICK
Remove the oil fill cap to check and add oil to the generator
when necessary.
RECEPTACLES
Your generator has the following single phase, 50 Hz outlets:
one 230 Volt AC, 16 Amp receptacle. These can be used for
operating appropriate appliances, electrical lighting, tools,
and motor loads.
RECOIL STARTER GRIP
The recoil starter grip is used (along with the engine speed
lever) to start the generator's engine.
7
