Page 1
Poseidon 310 English User’s Manual GZ-AA3CB-SJS / SJB...
Page 2
. F o r f u r t h e r information and specifications of the “Poseidon” series, please visit GIGABYTE Tech. website. (http://www.gigabyte.com.tw)
Table of Contents 1. Components Introduction 1-1 Casing’s Internal Structure 1-2 Front, Rear, and Left Side Panel Structure 1.3 Removal of Side and Front Panel 2. Features 3. Specifications 4. Installation Instruction 4-1 Installation of Power Supply 4-2 Installation of Motherboard 4-3 Installation of Add-on Card 4-4 Installation of Front Multi-Media I/O port 4-5 Connection of Fan Power Cables...
1.Components Introduction 1-1 Casing’s Internal Structure Accessory Box (Refer to the figures below for the attachments in the accessory box) Securing Runner x 6 Copper Stand Off Large Wire Clamp Mini Wire Clamp Front Cable Kit (Refer to the figures below for the cable connectors) USB 2.0 Audio Set (HD &...
1-2 Front, Rear, and Left Side Panel Structure a) Left Side Panel Ventilated Mesh Side Panel Kit Left Side Panel c) Rear Panel LCS Tube Outlets Rear Fan 1-3 Removal of Side and Front Panels 1-.1 To remove side panels: 1-3.1a Remove the 4 thumb screws at the rear of the side panel, and detach the side panels.
Complete front panel multi-media support, include 2 x USB 2.0, 1 x IEEE1394, 1 x audio set (HD & AC97) Full Support of Gigabyte Tech. thermal solution LCS and Air cooling products lines Support ATX / Micro ATX / Flex ATX motherboard.
3.Specifications Model Case Type Size Front Bezel Material Color Side panel Body material Net weight 5.25” drive bay (External) 3.5 drive bay (External) 3.5 drive bay (Internal) Expansion slots Form factor System Fan (front) System Fan (rear) I / O Ports GZ-AA3CB-SJS/SJB Middle Tower 200 x 440 x 505mm (W x H x D)
Use the 4 x securing screws to secure the power supply to the rear of the chassis. 4-2 Installation of Motherboard The Poseidon 310 can support ATX / Micro ATX / Flex-ATX motherboards. Please confirm the dimension and specifications of the motherboard before installation.
Micro ATX U1-U9 Flex ATX F1-F6 4-3 Installation of Add-on Card The Poseidon 310 does not require any tools for installation of add-on cards, e.g. Graphics card and network card. Required Tools: None 4-3.1 Unlock the corresponding PCI tool-free fastener by pushing it downwards.
4-4 Installation of Front Multi-Media I/O port Incorrect connection of the slots can cause the motherboard to malfunction or completely destroy the motherboard. Please read the manual carefully in the installation as incorrect installations or connection causing faults will void your warranty. The front panel consists of: (1) 2 x USB 2.0, 1 x IEEE 1394 and 1 x Audio Set (HD &...
4-5 Connection of Fan Power Cables The Poseidon 310 has one 12cm silent cooling fan in the front and one in the rear. This case includes internal connectors that connects the front and rear fans making it a single 3-pin connector.
4-6. 4-8 Installation of 3.5” Internal Device Bay The Poseidon 310 provides built-in bays to accommodate up to 3 hard disc drives. The built-in HDD requires securing runners, which can be found in the accessory box.
4-10 Liquid Cooling System Support The Poseidon 310 casing can fully support the GIGABYTE 3D Galaxy Liquid Cooling System (it also supports majority of the liquid cooling systems available commercially). While installing the liquid cooling system, please refer to the manual provided with the liquid cooling system.
