Summary of Contents for Gigabyte 3D Mars GZ-FA2CA-AJB
- Page 1 3D MARS GZ-FA2CA-AJS/AJB English User’s Manual...
- Page 2 For further information and specifications of “3D Mars” series, please visit Gigabyte Tech. website. (http://www.gigabyte.com.tw) The following are not covered by the warranty: 1.Using the product incorrectly or in a manner other than the designed pur- pose.
-
Page 3: Table Of Contents
4-7 Installation of 3.5” Front Device Bay 4-8 Installation of 3.5” Internal Device Bay 4-9 Application of Removable/Dual Directional HDD Rack 4-10 Application of Security lock 4-11 Application of Foot Supports 4-12 Application of Liquid Cooling System 4-13 Recommended Gigabyte Tech. Thermal Solution Products... -
Page 4: Components Introduction
1. Components Introduction 1-1 Casing’s Internal Structure Power Supply Bay PCI Tool-Free Fastener Motherboard tray and PCI Slot panel 5.25” Front Device Bay 3.5” Front Device Bay... - Page 5 3.5” Internal Device Bay Foot Support 8. Accessory Box (Refer to the figures below for the attachments in the accessory box) Power Extension 3.5” Device Key x 2 Wire Clamp x 2 Copper Stand Off Cable x 2 Thumbscrews x 20 x 12 Power Supply Securing Dust Remover Cloth...
-
Page 6: Front, Rear, And Left Side Panel Structure
1-2 Front, Rear, and Left Side Panel Structure A.Left Side Panel B.Front Panel C.Rear Panel A-1 Left Side Panel B-1 Power / Reset C-1 Dual Rear fans A-2 Latch Switches and LED C-2 LCS Tube Outlets A-3 Security Lock light A-4 Ventilated Mesh / Transparent Side Panel B-2 Front Multi-Media I/O port... -
Page 7: Features
Complete front panel multi-media support, include 2 x USB 2.0, 1 x IEEE1394, 1 x Audio Set (HD & AC’97). Full Support of Gigabyte Tech. thermal solution LCS and Air cooling products lines. Supports ATX / Micro ATX / Flex ATX / CEB motherboards. -
Page 8: Specifications
3.Specification Model GZ-FA2CA-AJS/AJB Case Type FULL TOWER Size 205 x 522 x 565mm (W x H x D) Front Bezel Material Aluminum Color Silver/Black Side Panel Ventilated Mesh / Transparent Body Material Aluminum (1.0mm) Net weight 5.25” drive bay (external) 3.5”... -
Page 9: Installation Instruction
4. Installation Instruction Please follow the reference sections in order for installation 4-1 Installation of Power Supply To facilitate the installation, it is recommended to set the chassis upright on the table. 〔Required Tools: Power supply securing screw x 4〕 Remove side panel (see step Secure the power supply with When using a larger power... -
Page 10: Installation Of Add-On Card
4-3 Installation of Add-On Card This chassis supports tool-free installation of interface cards, e.g. graphics cards, sound cards, and etc. 〔Required Tools: None〕 Unlock the PCI slot retention Remove the internally attached Insert the interface card lock. dust proof PCI cover. carefully into the expansion slot and lock the PCI slot retention lock. - Page 11 4-4.2 Insert the IEEE 1394 connector into the corresponding socket on the motherboard. IEEE 1394 connector A Definition Definition TPA+ TPB- TPA- +12V +12V TPB+ IEEE 1394 connector B Definition Definition TPA+ TPB- TPA- +12V +12V TPB+ IEEE 1394 connector C Definition Definition +12V...
-
Page 12: Connection Of Fan Power Cable
4-5 Connection of Fan Power Cable This chassis has 1 x 12cm silent blue LED cooling fan at the front and 2 x 12cm silent blue LED fans at the rear. There are internal connectors that connects the front and rear fans making it into a single 3-pin power con- nector. -
Page 13: Application Of Removable/Dual Directional Hdd Rack
In case the length of the power cable is not sufficient for installation of the bottom HDDs, please use the power extension cable which can be found inside the accessory box. Connect it according to the type of connector of your HDD. 4-9 Application of Removable/Dual Directional HDD Rack This chassis includes a removable/dual directional HDD rack for preferred installation direction and optimal heat dissipation. -
Page 14: Application Of Liquid Cooling System
4-12 Application of Liquid Cooling System This chassis fully supports Gigabyte Tech. 3D Galaxy series liquid cool- ing system (also supports most of the liquid cooling systems currently available). While installing the liquid cooling system, please refer to its manual in advanced.
