WATER PUMP
WH15X WH20X
OWNER'S MANUAL
MANUEL DE L'UTILISATEUR
BEDIENUNGSANLEITUNG
MANUAL DE EXPLICACIONES

Advertisement

Table of Contents
loading

Related Manuals for Honda WH15X

Summary of Contents for Honda WH15X

  • Page 1 WATER PUMP WH15X WH20X OWNER'S MANUAL MANUEL DE L'UTILISATEUR BEDIENUNGSANLEITUNG MANUAL DE EXPLICACIONES...

  • Page 2: Table Of Contents

    5. STARTING THE ENGINE ..............Carburetor Modification for High Altitude Operation ..... 6. OPERATION ..................7. STOPPING THE ENGINE ..............8. MAINTENANCE ................. 9. TRANSPORTING/STORAGE ............. 10. TROUBLESHOOTING ................ 11. SPECIFICATIONS ................12. MAJOR Honda DISTRIBUTOR ADDRESSES IN EUROPE ....
  • Page 3 All information in this publication is based on the latest product information available at the time of approval for printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.

  • Page 4: Safety Instruction

    SAFETY INSTRUCTION To ensure safe operation Honda water pump is designed to give safe and dependable service if operated according to in- structions. Read and understand the Owner’s Manual be- fore operating the water pump. Failure to do so could result in personal injury or equipment dam- age.
  • Page 5 To ensure safe operation Gasoline is extremely flammable and is explosive under certain conditions. Refuel in a well-ventilated area with the engine stopped. Do not smoke or allow flames or sparks in the refueling area or where gasoline is stored. Do not overfill the tank.

  • Page 6: Safety Label Locations

    These labels warn you of potential hazards that can cause serious inju- ry. Read the labels and safety notes and precautions described in this manual carefully. If a label comes off or becomes hard to read, contact your Honda deal- er for a replacement. [DFE and DXE types only]...
  • Page 7 [Except DFE and DXE types] (WH20X) French labels come with the water pump.

  • Page 8: Ce Mark And Noise Label Locations

    CE mark and noise label locations [DFE and DXE types only] NOISE LABEL [Example: WH20X NOISE LABEL] CE MARK Manufacturer and address Model Year of manufacture Machine mass (Standard specification)

  • Page 9: Component Identification

    COMPONENT IDENTIFICATION WH15X FUEL TANK CAP CARRYING HANDLE MUFFLER AIR CLEANER THROTTLE LEVER CHOKE LEVER STARTER GRIP OIL DRAIN PLUG FUEL VALVE PRIMING WATER FILLER CAP DISCHARGE PORT ENGINE SWITCH HOSE CONNECTOR (except C type) STRAINER SUCTION PORT OIL FILLER CAP/DIPSTICK...
  • Page 10 WH20X DF type THROTTLE LEVER MUFFLER FUEL TANK CAP CHOKE LEVER FUEL VALVE DISCHARGE PORT FRAME STARTER GRIP OIL FILLER CAP/DIPSTICK ENGINE SWITCH PRIMING WATER FILLER CAP AIR CLEANER SUCTION PORT STRAINER OIL DRAIN PLUG PUMP DRAIN PLUG...

  • Page 11: Pre-Operation Check

    PRE-OPERATION CHECK Connect the suction hose. Use commercially available hose, hose connector, and hose bands. The suction hose must be of reinforced, noncollapsible construction. Suction hose length should not be longer than necessary, as pump performance is best when the pump is not far above the water level. Self-priming time is also proportional to hose length.
  • Page 12 Connect the discharge hose. Use a commercially available hose, hose connector, and hose band. A short, large-diameter hose is most efficient. Long or small-diameter hose increases fluid friction and reduces pump output. Tighten the hose band securely to prevent the hose from disconnecting under high pressure.
  • Page 13 OIL FILLER NECK OIL FILLER CAP UPPER LEVEL RECOMMENDED OIL Use 4-stroke motor oil that meets or exceeds the requirements for API service classification SE or later (or equivalent). Always check the API service label on the oil container to be sure it includes the letters SE or later (or equivalent).
  • Page 14 Check the fuel level. Remove the fuel tank cap and the check the fuel level. Refill the tank if the fuel level is low. Use automotive unleaded gasoline with a Research Octane Number of 91 or higher (a Pump Octane Number of 86 or higher). Never use stale or contaminated gasoline or an oil/gasoline mixture.
  • Page 15 Gasolines containing alcohol If you decide to use a gasoline containing alcohol (gasohol), be sure it’s octane rating is at least as high as that recommended by Honda. There are two types of ‘‘gasohol’’: one containing ethanol, and the other containing methanol. Do not use gasohol that contains more than 10% ethanol.
  • Page 16 Check the air cleaner element. Remove the wing nut, washer and air cleaner cover. Check the element for dirt or obstruction. Clean the element if necessary (see page WING NUT AIR CLEANER COVER WASHER AIR CLEANER ELEMENT Never run the engine without the air cleaner. Rapid engine wear will result from contaminants such as dust and dirt being drawn through the carburetor into the engine.

  • Page 17: Starting The Engine

    STARTING THE ENGINE Turn the fuel valve ON. Close the choke lever. Do not use the choke if the engine is warm or the ambient temperature is high. FUEL VALVE CHOKE LEVER CLOSE CLOSE Turn the engine switch to the ON position. ENGINE SWITCH...
  • Page 18 Move the throttle lever slightly to the left. HIGH THROTTLE LEVER Pull the starter grip lightly until you feel resistance, then pull it briskly in the direction of the arrow as shown below. Do not allow the starter grip to snap back against the engine. Return it gently to prevent damage to the starter.
  • Page 19 Let the engine warm up for several minutes. If the choke lever has been moved to the CLOSE position, move it gradually to the OPEN position as the engine warm up. CHOKE LEVER CLOSE OPEN OPEN...

  • Page 20: Carburetor Modification For High Altitude Operation

    High altitude performance can be improved by specific modifications to the carburetor. If you always operate your water pump at altitudes above 1,500 meters (5,000 feet), have your authorized Honda servicing dealer perform this carburetor modification. This engine, when operated at high altitude with the carburetor modifications for high altitude use, will meet each emission standard throughout its useful life.

  • Page 21: Operation

    OPERATION Never use the pump for muddy water, rejected oil, wine, etc. Start the engine according to the procedures described in page Set the throttle at the desired speed. THROTTLE LEVER HIGH...

  • Page 22: Stopping The Engine

    STOPPING THE ENGINE To stop the engine in an emergency, turn the engine switch to the OFF position. To stop the engine in normal circumstances: Move the throttle lever fully to the right. Turn the engine switch to the OFF position. THROTTLE LEVER ENGINE SWITCH Turn the fuel valve OFF.

  • Page 23: Maintenance

    If the pump has been used with sea water, etc., pump clean, fresh water immediately afterward to reduce corrosion or remove sediment. Use genuine Honda parts or their equivalent for maintenance or repair. Replacement parts which are not of equivalent quality may damage the pump.

  • Page 24: Maintenance Schedule

    Service more frequently when used in dusty areas. These items should be serviced by your servicing dealer, unless you have the proper tools and are mechanically proficient. Refer to Honda shop manual for service procedures. For commercial use, log hours of operation to determine proper maintenance intervals.
  • Page 25 Changing oil Drain the oil while the engine is still warm to assure rapid and complete draining. Remove the oil filler cap/dipstick and the drain plug, then drain the oil. Install the drain plug securely using a new sealing washer. Refill with the recommended oil (see page ) to the specified level.
  • Page 26 Air cleaner service A dirty air cleaner will restrict air flow to the carburetor. To prevent carburetor malfunction, service the air cleaner regularly. Service more frequently when operating the pump in extremely dusty areas. Do not use gasoline or low flash point solvents for cleaning. They are flammable and explosive under certain conditions.
  • Page 27 Spark plug service Recommended spark plug: BPR6ES (NGK) W20EPR-U (DENSO) To ensure proper engine operation, the spark plug must be properly gapped and free of deposits. If the engine has been running, the muffler will be very hot. Be careful not to touch the muffler.
  • Page 28 Measure the plug gap with a feeler gauge. Correct as necessary by bending the side electrode. The gap should be: 0.70 0.80 mm (0.028 0.031 in) 0.70 0.80 mm (0.028 0.031 in) SIDE ELECTRODE SEALING WASHER Check that the sealing washer is in good condition, and thread the spark plug in by hand to prevent cross-threading.
  • Page 29 Spark arrester maintenance (optional parts) The muffler becomes very hot during operation and remains hot for a while after stopping the engine. Be careful not to touch the muffler while it is hot. Allow it to cool before proceeding. The spark arrester must be serviced every 100 hours to maintain its efficiency.

  • Page 30: Transporting/Storage

    TRANSPORTING/STORAGE To avoid severe burns or fire hazards, let the engine cool before transporting the pump or storing it indoors. When transporting the pump, turn the fuel valve to the OFF position, and keep the pump level to prevent fuel spillage. Spilled fuel or fuel vapor may ignite.
  • Page 31 Change the engine oil. Remove the spark plug, and pour about a tablespoon of clean engine oil into the cylinder. Crank the engine several revolutions to distribute the oil, then reinstall the spark plug. Pull the starter grip until you feel resistance. Continue pulling until the notch on the starter pulley aligns with the hole on the recoil starter (see illustration below).

  • Page 32: Troubleshooting

    Is the spark plug in good condition? Remove and inspect the spark plug. Clean, readjust gap and dry the spark plug. Replace it if necessary. If the engine still does not start, take the water pump to an authorized Honda dealer.
  • Page 33 Is the pump fully primed? Is the strainer clogged? Are the hose bands installed securely? Are the hose damaged? Is the suction head too high? If the pump still does not operate, take the water pump to an authorized Honda dealer.

  • Page 34: Specifications

    SPECIFICATIONS WH15X K1 Model WZAV Power product description code Dimensions and Weight 415 mm (16.3 in) Length 360 mm (14.2 in) Width 405 mm (15.9 in) Height 22.0 kg (48.5 lbs) Dry mass [weight] Engine GX120 K1 Model 4-stroke, overhead valve, 1 cylinder Engine type 118 cm (7.2 cu-in)
  • Page 35 WH20X K1 Model WASJ Power product description code Dimensions and Weight 425 mm (16.7 in) 520 mm (20.5 in) Length 375 mm (14.8 in) 400 mm (15.7 in) Width 405 mm (15.9 in) 450 mm (17.7 in) Height 23.5 kg (51.8 lbs) 27.0 kg (59.5 lbs) Dry mass [weight] Engine...
  • Page 36 Noise WH15X K1 WH20X K1 Model 88 dB 91 dB Sound pressure level (Lp Tested by EN12639 Guaranteed sound 104 dB 106 dB power level (L Tested by 2000/14/EC Tune-up ITEM SPECIFICATION MAINTENANCE Spark plug gap 0.7 0.8 mm Refer to page: 26 (0.028 0.031 in)

  • Page 37: Major Honda Distributor Addresses

    Fax: 223-66-4130 Austria Honda Power Equipment Sweden A.B. Ostmästargränd 8 Tel: 08-602-24-60 Stockholm-Årsta Fax: 08-722-36-27 Sweden Honda Produtos De Força, Portugal, S.A. Lugar da Abrunheira Tel:351-1-9150374 S. Pedro de Penaferrim Fax:351-1-9111021 2710 Sintra, Portugal Berema A/S Berghagan 5, Langhus Tel: 64-86-05-00...
  • Page 38 Fax: 22-685 16 03 Poland MO.TOR.PEDO Ltd. 1134 Budapest, Tel: 1-4652080 Dózsa Gy·út 61-63. Fax: 1-4652081 Hungary For Canadian NAME OF FIRM (COMPANY) ADDRESS TEL: FAX: Honda Canada Inc. 715 Milner Avenue Tel: 1-888-946-6329 Toronto ON Fax: 1-887-939-0909 M1B 2K8 Canada...
  • Page 39 WH15XK1 WH20XK1J Honda Motor Co., Ltd. 2002 36YB7715 2000.2007.07 N HC 00X36-YB7-7150 Printed in Japan...
