- Page 1 IROX-ER + IROX-XL Bedienungsanleitung Mode d emploi Modo di uso User manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION page 94 2. BASIC OPERATION OF BUTTONS page 96 3. MODE CHANGE OPERATION page 98 4. TIME MODE page 99 5. COMPASS MODE page 102 6. BAROMETER MODE page 106 7. ALTIMETER MODE page 110 8. -
Page 3: Introduction
IROX-XL IROX-ER 1 INTRODUCTION This device is a digital product that provides altimeter, barometer, com- pass, altimeter data, dual time, chronograph, chronograph data and alarm functions. Features: Altimeter – 1 meter (or foot) resolution and with working range from –700 meters (-296 feet) to 9000 meters (29520 feet). - Page 4 Barometer – 1 hPa resolution and with working range from 300 hPa to 1100 hPa. – Graphical expression of changes provided. – Both sea level pressure and absolute pressure can be shown. – Weather forecast. – Temperature displayed in °F or °C selectable. Compass –...
-
Page 5: Basic Operation Of Buttons
2 BASIC OPERATION OF BUTTONS A: – SWITCH AMONG DISPLAYS – TAKE BEARING – STORE ALTITUDE DATA (PRESS AND HOLD) – FORWARD SELECTION OF ALTITUDE DATA – START/LAP OF CHRONOGRAPH – RETRIEVE DATA IN RUN – TURN ALARM ON AND OFF –... - Page 6 – REVERSE SELECTION OF ALTITUDE DATA – STOP CHRONOGRAPH – STORE CHRONOGRAPH DATA (PRESS AND HOLD) – SELECT RUN NUMBER – SWITCH BETWEEN ALARM 1 AND ALARM 2 – REVERSE SETTING (SET OR CALIBRATION) C: – MODE CHANGE – DIRECT CHANGE TO TIME MODE (PRESS AND HOLD) –...
-
Page 7: Mode Change Operation
3 MODE CHANGE OPERATION There are 9 modes: Normal Time, Dual Time, Compass, Barometer, Altime- ter, Altimeter Data, Chronograph, Chronograph Data and Alarm. Press C to change from mode to mode, hold down B to switch between Normal Time mode and Dual Time mode as in the following: Hold B NORMAL TIME DUAL TIME... -
Page 8: Time Mode
4 TIME MODE Normal Time Dual Time indicator indicator Indicator Indicator Hold B Use C to enter Time mode. * Mode prompt “TIME” is displayed first. – There are 2 time modes, Normal Time (indicated by T1) and Dual Time (indicated by T2), and they count up individually with the same second. - Page 9 To switch among the 3 time displays Use A or E to switch among the 3 displays for time. * “TIME”, “BAROMETER” or “WEATHER” is displayed first. Graph of sea Weather indicators Day of the week level pressure A or E A or E Temperature Time...
- Page 10 To set time 1. Hold down D until the hour digits start to flash on the display, which indicates the setting screen. 2. Use A (+) and B (–) to change the setting. Holding down either button scrolls the setting at high speed. 3.
-
Page 11: Compass Mode
5 COMPASS MODE South indicator Cardinal indicator Bearing North indicator Compass mode Hold D indicator CALIBRATION SCREEN Use C to enter Compass mode. * Mode prompt “COMP” is displayed first and bearings will be taken auto- matically. – Compass mode indicator is shown. –... - Page 12 * Declination is the difference between true north and magnetic north. Importance 1. The compass should be calibrated before use. 2. The compass must be kept in a level position when in use. 3. Compass readings are easily affected by disturbing sources of magne- tism, so the compass should always be used in the open air.
- Page 13 * When E or W is flashing, press A or B to switch between East and West. * You should consult your local organization for information of declination. Declination angles for major cities are listed below for reference only. City Declination City Declination...
- Page 14 6. Press D to end calibration. * If “ERR” indicating error is displayed, calibrate the compass again. * If there is no button operation for 2-3 minutes during calibration or at declination angle setting screen, the display will return to Compass mode automatically.
- Page 15 6 BAROMETER MODE Graph of Weather indicator Sea level pressure Current Sea level pressure Barometer mode indicator Unit indicator of pressure Use C to enter Barometer mode. * Mode prompt “BARO” is displayed first. – Barometer mode indicator is shown. –...
- Page 16 – Temperature is of 0.1 degree resolution and with working range from –4°F (–20°C) to 158°F (70°C). And unit in °F or °C selectable. – There are 3 displays for Barometer mode. To switch among the 3 displays for barometer mode Use A or E to switch among the 3 displays for barometer mode.
- Page 17 * It is not possible to get the exact reading from the graph. User can only get the trend of changes from the graph. To switch between °F and °C 1. Use A or E to switch to the barometer display with temperature. 2.
- Page 18 To set current weather 1. Hold down D until “SET CURRENT WEATHER” scrolls on the display, which indicates the weather setting screen. * The weather indicators start to flash. 2. Use A (+) and B (–) to change the setting as in the following: 3.
- Page 19 7 ALTIMETER MODE Altitude graph Unit indicator of altitude Current Altitude reading Time Altimeter mode indicator Use C to enter Altimeter mode. * Mode prompt “ALTI” is displayed first. – Altimeter mode indicator is shown. – The altimeter is of 1 meter (or foot) resolution and with working range from –700 meters (–2296 feet) to 9000 meters (29520 feet).
- Page 20 15 minutes while each column represents the relative reading of altitude in that time. * It is not possible to get the exact reading from the graph. User can only get the trend of changes from the graph. To switch between meters and feet Hold down B until the unit indicator (M or Ft) stops flashing to switch altitude reading between meters and feet.
-
Page 21: Altimeter Data Mode
8 ALTIMETER DATA MODE Data number Time 3 seconds or E Month-Day Altitude reading Use C to enter Altimeter Data mode. * Mode prompt “ALTI DATA” is displayed first. – Data number, time, date and altitude reading can be retrieved. * Altitude data are shown in 2 different displays. -
Page 22: Chronograph Mode
9 CHRONOGRAPH MODE Lap time indicator Lap time Split time Lap number Split time indicator Use C to enter Chronograph mode. * Mode prompt “CHRO” is displayed first. – The chronograph is of 1/100-second resolution for the first hour and 1- second resolution for the rest and with working range up to 24 hours, then the chronograph stops automatically. - Page 23 * When you take lap/split times, the display will be frozen to show lap time, split time and lap number for about 6 seconds, then the display will show the current running times automatically. To measure elapsed time 1. Press A to start the chronograph. 2.
- Page 24 4. Press B when the last runner finishes. * Time measurement is stopped. 5. Hold down B until the next run number is shown on the display. * Data of the current run is stored and chronograph is reset to all zeros. * The finish times for the runners are the split times stored in Chronograph Data mode.
- Page 25 Special function for the model IROX-ER (not for IROX-XL) To show number of unused lap When the chronograph shows all zeros, press E and the number of unused lap (indicated by “FREE”) will be shown for 3 seconds. * Returns to chronograph display automatically after 3 seconds or when any button is pressed.
-
Page 26: Chronograph Data Mode
10 CHRONOGRAPH DATA MODE Run number Lap time indicator Lap time 2 seconds Split time Month-Day Split time indicator Lap number Use C to enter Chronograph Data mode. * Mode prompt “CHRO DATA” is displayed first. – Run number, date, lap/split time of each lap, best lap time and average lap time can be retrieved. - Page 27 Lap number Lap/split time of lap 1 Best lap time Average lap time To clear one particular run 1. Use B to select the run to be cleared. 2. Hold down D until “CLEAR HOLD ALL” is shown on the display, release D and the selected run will be cleared.
-
Page 28: Alarm Mode
11 ALARM MODE T1 indicator Alarm 1 indicator Alarm time ON/OFF status indicator Chime on indicator Alarm on indicator Use C to enter Alarm mode. * Mode prompt “ALRM” is displayed first. – There are 2 daily alarms and they can be set to refer to Normal Time (indicated by T1) or Dual Time (indicated by T2). - Page 29 * If chime is turned on, confirmation sound will be given whenever a button is pressed. To switch between alarm 1 and alarm 2 Press B to switch between alarm 1 (indicated by AL-1) and alarm 2 (indi- cated by AL-2). To set alarm time and turn chime on and off 1.
- Page 30 If chime is turned on, the chime on indicator will be shown after exiting setting screen. 4. Press D to exit the setting screen. * The alarm turns on, which is indicated by ON and the appearance of the alarm on indicator. * If there is no button operation for 2-3 minutes at setting screen, the display will return to Alarm mode automatically.
-
Page 31: Service
12 SERVICE 12.1 RESETTING THE PRODUCT Hold down A, B, C and D simultaneously, all segments will be “on”, then release the buttons and the product will be reset. * After reset, there will not be any measurement of altitude, pressure or temperature until A, C or E is pressed. - Page 32 Certificato di garanzia Warranty Gerät / Modèle / Nome del prodotto / Product Händler (Adresse) / Nom du revendeur (Adresse) / Nome del negoziante (Indirizzo) / Dealer’s name (Adress): Kaufdatum / Date d’achat / Data d’acquisito / Date of purchase www.irox.com...
