WIAS-1200G
802.11G Internet Access Server
User's Manual
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WIAS-1200G and is the answer not in the manual?

Questions and answers

Related Manuals for AirLive WIAS-1200G

Summary of Contents for AirLive WIAS-1200G

  • Page 1 WIAS-1200G 802.11G Internet Access Server User’s Manual User’s Manual...
  • Page 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE) The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000.

  • Page 4: Declaration Of Conformity

    OvisLink Corp. 5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien City, Taipei County, Taiwan Declare that the product 802.11G Internet Access Server WIAS-1200G is in conformity with In accordance with 89/336 EEC-EMC Directive and 1999/5 EC-R & TTE Directive Clause Description EN 300 328 V1.6.1...
  • Page 5 [Portuguese] disposições da Directiva 1999/5/CE. aplicables o exigibles de la Directiva 1999/5/CE. ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ OvisLink Corp. ΔΗΛΩΝΕΙ OvisLink Corp izjavlja, da je ta WIAS-1200G v skladu Ελληνική [Greek] ΟΤΙ WIAS-1200G ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ Slovensko z bistvenimi zahtevami in ostalimi relevantnimi določili ΟΥΣΙΩΔΕΙΣ...
  • Page 6 This device uses software which is partly or completely licensed under the terms of the GNU General Public License. The author of the software does not provide any warranty. This does not affect the warranty for the product itself. To get source codes please contact: OvisLink Corp., 5F, No. 96, Min-Chuan Rd, Hsin-Tien City, Taipei, Taiwan, R.O.C. A fee will be charged for production and shipment for each copy of the source code.

  • Page 7: Table Of Contents

    AirLive WIAS-1200G User’s Guide Table of Contents Before You Start ............................1 Audience ..............................1 Document Conventions...........................1 System Overview ...........................2 Introduction of AirLive WIAS-1200G....................2 System Concept ............................3 Specification ............................4 2.3.1 Hardware Specification..........................4 2.3.2 Technical Specification ..........................5 Base Installation ...........................7 Hardware Installation..........................7 3.1.1 System Requirements............................7...
  • Page 8 AirLive WIAS-1200G User’s Guide 4.3.4 Walled Garden List .............................87 4.3.5 Proxy Server Properties ..........................88 4.3.6 Dynamic DNS.............................89 Utilities..............................90 4.4.1 Network Utilities............................91 4.4.2 Change Password ............................92 4.4.3 Backup/Restore Setting..........................95 4.4.4 Firmware Upgrade ............................96 4.4.5 Restart .................................96 Status..............................97 4.5.1 System Status ..............................98 4.5.2...

  • Page 9: Before You Start

    This manual is for Hotspot owners or administrators in enterprises to set up network environment using AirLive WIAS-1200G. It contains step by step procedures and graphic examples to guide MIS staff or individuals with slight network system knowledge to complete the installation.

  • Page 10: System Overview

    Friendly Management and Application Interfaces AirLive WIAS-1200G is easy to install. All of the functions of the system can be performed with a simple few clicks. The full web-based management interface allows users to operate and manage the system online via browsers.

  • Page 11: System Concept

    SSL encrypted web interface. This interface is compatible to most desktop devices and palm computers. The following figure is an example of AirLive WIAS-1200G set to control a part of the company’s intranet. The whole managed network includes the cable network users and the wireless network users.

  • Page 12: Specification

    The users located at the managed network will be unable to access the network resource without permission. When the browser of a user attempts to connect to a website, the AirLive WIAS-1200G will force the browser to redirect to the user login webpage. The user must enter the username and password for authentication. After the identity is authenticated successfully, the user will gain proper access right defined on the AirLive WIAS-1200G.

  • Page 13: Technical Specification

    AirLive WIAS-1200G User’s Guide 2.3.2 Technical Specification Standards This system supports IEEE 802.1x, 802.11b and 802.11g Networking WAN interface supports Static IP, DHCP client, PPPoE client, and PPTP client Supports NAT mode and Router mode Built-in DHCP server Built-in NTP client Supports Redirect of network data Supports IPSec (ESP), PPTP and H.323 pass through (under NAT)
  • Page 14 AirLive WIAS-1200G User’s Guide Administration Provides online status monitoring and history traffic Supports SSL encrypted web administration interface and user login interface Customizable user login & logout web interface Customizable redirect after users are successfully authenticated during login & logout...

  • Page 15: Base Installation

    Standard 10/100BaseT including five network cables with RJ-45 connectors All PCs need to install the TCP/IP network protocol 3.1.2 Package Contents The standard package of AirLive WIAS-1200G includes: AirLive WIAS-1200G x 1 Quick Installation Guide x 1 CD-ROM x 1...

  • Page 16: Panel Function Descriptions

    RESET: Press this button to restart the system. WAN: The WAN port is used to connect to a network which is not managed by the AirLive WIAS-1200G, and this port can be used to connect the ATU-Router of ADSL, the port of Cable Modem, or the Switch or Hub on the LAN of a company.

  • Page 17: Installation Steps

    After the hardware of AirLive WIAS-1200G is installed completely, the system is ready to be configured in the following sections. The manual will guide you step by step to set up the system using a single AirLive WIAS-1200G to manage the network.

  • Page 18: Quick Software Configuration

    There are two simple ways to configure the system: Instant Account and Configuration Wizard. 3.2.1 Instant Account WIAS-1200G provides three different level account; admin, manager and operator. The default username and password as follows: Admin: The administrator can access all area of the AirLive WIAS-1200G.
  • Page 19 AirLive WIAS-1200G User’s Guide Please check the following steps to complete the quick configuration Login with admin account: 1. Select System Configuration WAN Configuration, and set up the WAN type and enter the necessary data. For more detail information please check chapter 4.1.3 WAN configuration.
  • Page 20 AirLive WIAS-1200G User’s Guide 1. Select User Authentication Authentication On-demand User; in this item you Configuration can define the Postfix name, Monetary Unit, WALN ESSID and the other information if needed. 2. Select User Authentication Authentication Configuration On-demand User Billing Configuration, define the related information based on your policy.
  • Page 21 AirLive WIAS-1200G User’s Guide 1. Click Create to create a new account. 2. Click Printout to print ticket. Following is the list to display the access right of WIAS-1200G feature per each account: admin manager operator System Configuration Authentication Configuration...

  • Page 22: Configuration Wizard

    WIAS-1200G. You just need to follow the procedures and instructions given by the Wizard to enter the required information step by step. After saving and restarting AirLive WIAS-1200G, it is ready to use. There will be 7 steps as listed below: 1.
  • Page 23 AirLive WIAS-1200G User’s Guide After successfully logging into AirLive WIAS-1200G, a web management interface with a welcome message will appear. To logout, simply click the Logout on the upper right corner of the interface to return. Then, run the configuration wizard to complete the configuration. Click System Configuration to the System Configuration homepage.
  • Page 24 NTP Server: Enter the URL of the external time server for AirLive WIAS-1200G time synchronization or use the default. DNS Server: Enter a DNS Server provided by your ISP (Internet Service Provider). Contact your ISP if you are not sure of DNS IP Address.
  • Page 25 An authentication method has to be selected from one of the five options appeared in this window ( Local User is selected for this example). Local User is authentication method that uses the built-in u database supported by AirLive WIAS-1200G. Click Next to continue.
  • Page 26 AirLive WIAS-1200G User’s Guide Local User: Add User A new user can be a dded to the local user data base. To add a user here, enter the Username (e.g. test), Password (e.g. test), and MAC (optional). Assign a policy to add this particular local user (or use the default).
  • Page 27 6. Set Wireless – Acc ess Point Connection SSID: Enter a SSID (up to 32 characters) for system. The default is AirLive. SSID (Service Set Identifier) is a unique identifier used for the wireless client’s devices to associate with the built in AP AirLive WIAS-1200G.
  • Page 28 AirLive WIAS-1200G User’s Guide Setup Wizard. During AirLive WIAS-1200G restart, a “Restarting now. Please wait for a while.” m essage will appear on the screen. Please do not interrupt AirLive WIAS-1200G until the message has disappeared. This indicates that a complete and successful restart process has finished.

  • Page 29: Web Interface Configuration

    AirLive WIAS-1200G User’s Guide 4. Web Interface Configuration This chapter will guide you through further detailed settings. The following table shows all the functions of AirLive WIAS-1200G. System User Network OPTION Utilities Status Configuration Authentication Configuration Configuration Authentication Network Address...

  • Page 30: System Configuration

    The Configuration Wizard has 7 steps providing a simple and easy way to go through the basic setups of AirLive WIAS-1200G and is served as Quick Configuration. Please refer to 3.2.2 Quick Configuration for the introduction and description of Configuration Wizard.

  • Page 31: System Information

    AirLive WIAS-1200G User’s Guide 4.1.2 System Information These are some main information about AirLive WIAS-1200G. Please refer to the following description for these blanks: System Name: Set the system’s name or use the default. Administrator Info: Enter the Administrator’s information here, such as administrator’s name, telephone number, e-mail address, etc.
  • Page 32 10.0.0.3, if you are using the IP address 10.0.0.3, you can reach the administration page of AirLive WIAS-1200G. If you would like to allow any IP address to access the remote management, enter the address range with 0.0.0.0/0.0.0.0. The default setting is to disable remote managed function.

  • Page 33: Wan Configuration

    AirLive WIAS-1200G User’s Guide 4.1.3 WAN Configuration There are 4 methods of obtaining IP address for the WAN Port: Static IP Address, Dynamic IP Address, PPPoE and PPTP Client. Static IP Address: Manually specifying the IP address of the WAN Port is applicable for the network environment where the DHCP service is unavailable.
  • Page 34 AirLive WIAS-1200G User’s Guide PPTP Client: Select STATIC to specify the IP address of the PPTP Client manually or select DHCP to get the IP address automatically. The fields with red asterisks are required to be filled in. There is a Dial on Demand function under PPPoE.

  • Page 35: Lan1 & Lan2 Configuration

    IP PNP: Users can use any IP address to connect to the system. Regardless of what the IP address at the user end is, users can still be authenticated through AirLive WIAS-1200G and access the network. User Authentication: Choose to enable or disable this function. If “User Authentication” is disabled, users can access Internet without being authenticated.
  • Page 36 AirLive WIAS-1200G User’s Guide DHCP Scope: Enter the “Start IP Address” and the “End IP Address” of this DHCP block. These fields define the IP address range that will be assigned to the Public LAN clients. Preferred DNS Server: The primary DNS server for the DHCP.

  • Page 37: Lan3 & Lan4 Configuration

    AirLive WIAS-1200G User’s Guide 4.1.5 LAN3 & LAN4 Configuration In this section, set the related configuration for LAN3/LAN4 port and DHCP server. LAN3 & LAN4 Port Operation Mode: Choose one of the two modes, NAT mode and Router mode, by the requirements.
  • Page 38 AirLive WIAS-1200G User’s Guide DHCP Scope: Enter the “Start IP Address” and the “End IP Address” of this DHCP block. These fields define the IP address range that will be assigned to the Private LAN clients. Preferred DNS Server: The primary DNS server for the DHCP.

  • Page 39: Wireless Configuration

    AirLive WIAS-1200G User’s Guide 4.1.6 Wireless Configuration This section is for setting related configurations for the wireless port.
  • Page 40 AirLive WIAS-1200G User’s Guide Wireless Configuration The SSID is the unique name shared among all devices in a wireless network. The SSID must be the SSID: same for all devices in the wireless network. It is case sensitive, must not exceed 32 characters and may be any character on the keyboard.
  • Page 41 4. Basic Rate: The basic rate offers three options, All, Set1 and Set2 and the default value is Set1. Depending on the wireless mode selected, AirLive WIAS-1200G will deliver a pre-defined data rate. Select “All” to activate all transmission rates to be compatible with the majority of the devices.
  • Page 42 IP PNP: Use any IP address to connect to the system. Regardless of what the IP address at the users end is, they can still be authenticated through AirLive WIAS-1200G and access the network. User Authentication: If “User Authentication” is disabled, “Specific Route Profile” needs to be specified for the users to access Internet.
  • Page 43 This function can extend the range of accessing the network. It has to work with a repeater. A repeater is a peripheral device supporting AirLive WIAS-1200G to extend the wireless access by receiving requests from APs or clients and passing the requests to AirLive WIAS-1200G to obtain authentication.

  • Page 44: User Authentication

    AirLive WIAS-1200G User’s Guide 4.2 User Authentication This section includes the following functions: Authentication Configuration, Black List Configuration, Policy Configuration, Guest User Configuration and Additional Configuration. 4.2.1 Authentication Configuration This function is to configure the settings for 802.1x authentication, authentication server, and on-demand user...
  • Page 45 AirLive WIAS-1200G User’s Guide 802.1x Authentication Configuration There are two kinds of 802.1x authentication methods and one encryption mechanism: 802.1x, WPA w/802.1x and WPA-PSK. Click the hyperlink 802.1x Authentication Configuration to set the related configurations. After completing and clicking Apply to save the settings, go back to the previous page to check the item box next to 802.1x Authentication Configuration to enable this function.
  • Page 46 AirLive WIAS-1200G User’s Guide 2. WPA w/802.1x: Enable the supported WPA-Enterprise, Wireless Protection Access with 802.1x. Authentication Server IP: The IP address or domain name of the Authentication server. Authentication Port: The port of the authentication server. The default value is 1812.
  • Page 47 AirLive WIAS-1200G User’s Guide Authentication Server Configuration The system provides 3 servers and one on-demand server that the administrator can apply with different policy. Click on the server name to set the related configurations for that particular server. After completing and clicking Apply to save the settings, go back to the previous page to choose a server to be the default server and enable or disable any server on the list.
  • Page 48 AirLive WIAS-1200G User’s Guide from the store to log in the system for wireless access. There are 2000 On-demand User accounts available. For detailed information about configuration, please see 4.2.1.6 Authentication Method – On-demand User 4.2.1.1 Authentication Method – Local User Setting Choose “Local User”...
  • Page 49 AirLive WIAS-1200G User’s Guide Add User: Click this to enter the Add User interface. Fill in the necessary information such as “Username”, “Password”, “MAC” and “Remark” (optional). Then, select a desired Policy and click Apply to complete adding the user or users.
  • Page 50 AirLive WIAS-1200G User’s Guide Upload User: Click this to enter the Upload User interface. Click the Browse button to select the text file for the user account upload. Then click Submit to complete the upload process. The uploading file should be a text file and the format of each line is "ID, Password, MAC, Policy, Remark"...
  • Page 51 AirLive WIAS-1200G User’s Guide Refresh: Click this to renew the user list. Search: Enter a keyword of a username to be searched in the text field and click this button to perform the search. All usernames matching the keyword will be listed.
  • Page 52 AirLive WIAS-1200G User’s Guide 4.2.1.2 Authentication Method – POP3 Choose “POP3” in the Authentication Method field, the hyperlink beside the pull-down menu will become “POP3 Setting”. Click the hyperlink for further configuration. Enter the related information for the primary server and/or the secondary server (the secondary server is not required).
  • Page 53 Radius Client Configuration list for further configuration. In the Radius Client Configuration table, the clients, which are using 802.1X as the authentication method, shall be put into this table. AirLive WIAS-1200G will forward the authentication request from these clients to the configured Radius Servers.
  • Page 54 AirLive WIAS-1200G User’s Guide 4.2.1.4 Authentication Method – LDAP Choose “LDAP” in the Authentication Method field, the hyperlink beside the pull-down menu will become “LDAP Setting”. Click the hyperlink for further configuration. Enter the related information for the primary server and/or the secondary server (the secondary server is not required).
  • Page 55 These settings will become effective immediately after clicking the Apply button. Server IP address: Enter the server IP address of the domain controller. Transparent Login: If the function is enabled, users will log into AirLive WIAS-1200G automatically when they log into the Windows domain.
  • Page 56 AirLive WIAS-1200G User’s Guide 4.2.1.6 Authentication Method – On-demand User On-demand User Server Configuration: Administrators can enable and configure this authentication method to provide wireless access in a Hotspot environment. Major functions include accounts creation, users monitoring list, billing plan, billing report statistics, and external payment gateway support.
  • Page 57 AirLive WIAS-1200G User’s Guide Users List: Click to enter the On-demand Users List page. In the On-demand Users List, detailed information will be documented here. By default, the On-demand user database is empty. Search: Enter a keyword of a username that needs to be searched in the text field and click this button to perform the search.
  • Page 58 AirLive WIAS-1200G User’s Guide format in the uploading file or delete the duplicated user account in the database, then try again. The unit of data transfer is byte. The unit of session length is second. ID (Username) and Password must be given in upper case.
  • Page 59 AirLive WIAS-1200G User’s Guide Billing Configuration: Administrators can configure up to 10 billing plans. Status: Select to enable or disable this billing plan. Type: Set the billing plan by “Data” (the maximum volume allowed is 9,999,999 Mbyte) or “Time” (the maximum days allowed is 999 days).
  • Page 60 AirLive WIAS-1200G User’s Guide Billing Report: Administrators can get a complete report or a report of a particular period. Report All: Click this to get a complete report including all the on-demand records. This report shows the total expenses and individual accounting of each plan for all plans available.
  • Page 61 AirLive WIAS-1200G User’s Guide Search: Select a time period to get a period report. The report tells the total expenses and individual accounting of each plan for all plans available for that period of time. Payment: This section is for merchants to set up an external payment gateway to accept payments in order to provide wireless access service to end customers who wish to pay for the service on-line.
  • Page 62 AirLive WIAS-1200G User’s Guide Authorize.Net Before setting up “Authorize.Net”, it is required that the merchant owners have a valid Authorize.Net account. Please see Appendix B – Accepting Payments via Authorize.Net, Appendix E – Examples of Making Payments for End Users for more information about opening an Authorize.Net account and related maintenance functions.
  • Page 63 AirLive WIAS-1200G User’s Guide Service Disclaimer Content/ Credit Card Payment Page/Client’s Purchasing Record Service Disclaimer Content View service agreements and fees for the standard payment gateway services here as well as adding new or editing services disclaimer. Credit Card Payment Page Billing Configuration These 10 plans are the plans in Billing Configuration, and desired plan can be enabled.
  • Page 64 AirLive WIAS-1200G User’s Guide Credit Card Payment Page Fields Configuration/ Credit Card Page Remark Content Credit Card Payment Page Fields Configuration Item: Check the box to show this item on the customer’s payment interface. Displayed Text: Enter what needs to be shown for this field.
  • Page 65 AirLive WIAS-1200G User’s Guide information of a transaction. This field may contain any format of information. First Name: The first name of a customer associated with the billing or shipping address of a transaction. In the case when John Doe places an order, enter John in the First Name field indicating this customer’s name.
  • Page 66 AirLive WIAS-1200G User’s Guide PayPal Before setting up “PayPal”, it is required that the merchant owners have a valid PayPal “Business Account”. Please see Appendix D – Accepting Payments via PayPal, Appendix E – Examples of Making Payments for End Users for more information about setting up a PayPal Business Account, relevant maintenance functions, and example for end users.
  • Page 67 AirLive WIAS-1200G User’s Guide Service Disclaimer Content /Billing Configuration for Payment Page Service Disclaimer Content View service agreements and fees for the standard payment gateway services here as well as adding new or editing services disclaimer. Billing Configuration for Payment Page These 10 plans are the plans in Billing Configuration, and desired plan can be enabled.
  • Page 68 AirLive WIAS-1200G User’s Guide Client’s Purchasing Record/ PayPal Payment Page Remark Content Client’s Purchasing Record Invoice Number: An invoice number may be provided as additional information against a transaction. This is a reference field that may contain any format of information.

  • Page 69: Black List Configuration

    AirLive WIAS-1200G User’s Guide 4.2.2 Black List Configuration The administrator can add, delete, or edit the black list for user access control. Each black list can include 40 users at most. If a user in the black list wants to log into the system, the user’s access will be denied. The administrator can use the pull-down menu to select the desired black list.

  • Page 70: Policy Configuration

    AirLive WIAS-1200G User’s Guide 4.2.3 Policy Configuration Every Policy has three profiles, Firewall Profile, Specific Route Profile, and Schedule Profile as well as Bandwidth setting for that policy and for individual clients. Firewall Profile Click the hyperlink of Setting for Firewall Profile, the Firewall Profiles list will appear. Click the numbers of Filter Rule Item to edit individual rules and click Apply to save the settings.
  • Page 71 AirLive WIAS-1200G User’s Guide Source MAC Address: The MAC address of the source IP address. This is for specific MAC address filter. Source/Destination Interface: There are four interfaces to choose, WAN, Wireless, Public LAN (LAN1/LAN2) and Private LAN (LAN3/LAN4). Source/Destination IP: Enter the source and destination IP addresses.

  • Page 72: Guest User Configuration

    This function can permit guests to log into the system. Select “Enable Guest User” and click Apply to save the settings. Guest User List: AirLive WIAS-1200G offers 10 guest users for log in. To activate a guest user, just enter the password in the corresponding “Password” text field for that guest account. Guest accounts with blank password will not be activated.

  • Page 73: Additional Configuration

    Internet Connection Detection: Enter a specific URL or IP address and AirLive WIAS-1200G will try to detect the network connection by sending packets directly to that specific URL or IP address. If there is a problem in the connection of the WAN port of the system such that the URL or IP address specified cannot be reached, there will be a connection failed message showing on the users’...
  • Page 74 AirLive WIAS-1200G User’s Guide Click Use Default Certificate to use the default certificate and key. 2. Login Page: The administrator can use the default login page or get the customized login page by setting the template page, uploading the page or downloading from the specific website. After finishing the setting, click Preview to see the login page.
  • Page 75 AirLive WIAS-1200G User’s Guide c. Choose Uploaded Page and you can get the login page by uploading. Click the Browse button to select the file for the login page upload. Then click Submit to complete the upload process.
  • Page 76 After the image file is uploaded, the file name will show on the “Existing Image Files” field. Check the file and click Delete to delete the file. In AirLive WIAS-1200G, the end user first gets a login page when she/he opens its web browser right after...
  • Page 77 AirLive WIAS-1200G User’s Guide associating with an access point. However, in some situations, the hotspot owners or MIS staff may want to display “terms of use” or announcement information before the login page. Hotspot owners or MIS staff can design a new disclaimer/announcement page and save the page in their local server. After the agreement shown on the page is read, users are asked whether they agree or disagree with the disclaimer.
  • Page 78 AirLive WIAS-1200G User’s Guide d. Choose the External Page selection and you can get the login page from the specific website. Enter the website address in the “External Page Setting” field and then click Apply. The External Page prepared to be loaded here needs to have the following code as well to let the system...
  • Page 79 AirLive WIAS-1200G User’s Guide...
  • Page 80 AirLive WIAS-1200G User’s Guide 3. Logout Page: The users can apply their own logout page here. The process is similar to that of Logout Page. The different part is the HTML code of the user-defined logout interface must include the following HTML code that the user can enter the username and password.
  • Page 81 AirLive WIAS-1200G User’s Guide b. Choose Template Page to make a customized login success page here. Click Select to pick up a color and then fill in all of the blanks. You can click Preview to see the result first.
  • Page 82 AirLive WIAS-1200G User’s Guide Enter or browse the filename of the images to upload in the Upload Images field on the Upload Images Files page and then click Submit. The system will show the used space and the maximum size of the image file of 512K.
  • Page 83 AirLive WIAS-1200G User’s Guide b. Choose Template Page to make a customized login success page for On-Demand here. Click Select to pick up a color and then fill in all of the blanks. You can click Preview to see the result first.
  • Page 84 AirLive WIAS-1200G User’s Guide c. Choose Uploaded Page and click the Browse button to select the file for the login success page for On-Demand upload. Then click Submit to complete the upload process. After the upload process is completed, the new login success page for On-Demand can be previewed by clicking Preview button at the bottom.
  • Page 85 AirLive WIAS-1200G User’s Guide d. Choose the External Page selection and you can get the login success page for On-Demand e from the specific website. Enter the website address in the “External Page Setting” field and then click Apply. After applying the setting, the new login success page for On-Demand can be previewed by clicking Preview button at the bottom of this page.
  • Page 86 AirLive WIAS-1200G User’s Guide b. Choose Template Page to make a customized logout success page here. Click Select to pick up a color and then fill in all of the blanks. Click Preview to see the result first. c. Choose Uploaded Page and click the Browse button to select the file for the logout success page upload.
  • Page 87 AirLive WIAS-1200G User’s Guide Enter or browse the filename of the images to upload in the Upload Images field on the Upload Images Files page and then click Submit. The system will show the used space and the maximum size of the image file of 512K.
  • Page 88 Enhance User Authentication: With this function, only the users with their MAC addresses in this list can log into AirLive WIAS-1200G. However, user authentication is still required for these users. Please enter the Permit MAC Address List to fill in these MAC addresses, select Enable, and then click Apply.

  • Page 89: Network Configuration

    AirLive WIAS-1200G User’s Guide 4.3 Network Configuration This section includes the following functions: Network Address Translation, Privilege List, Monitor IP List, Walled Garden List, Proxy Server Properties and Dynamic DNS.

  • Page 90: Network Address Translation

    AirLive WIAS-1200G User’s Guide 4.3.1 Network Address Translation There are three parts, Static Assignments, Public Accessible Server and Port and Redirect, need to be set. Static Assignments A computer within the Static Assignments is unprotected by firewall and typically all port accesses are routed through to that computer.
  • Page 91 AirLive WIAS-1200G User’s Guide Port and IP Redirect This function allows the administrator to set 40 sets of the IP addresses at most for redirection purpose. When the user attempts to connect to a destination IP address listed here, the connection packet will be converted and redirected to the corresponding destination.

  • Page 92: Privilege List

    IP addresses of these workstations in this list. The “Remark” blank is not necessary but is useful to keep track. AirLive WIAS-1200G allows 100 privilege IP addresses at most. These settings will become effective immediately after clicking Apply.
  • Page 93 AirLive WIAS-1200G User’s Guide Note: Permitting specific MAC addresses to have network access rights without going through standard authentication process at the Public LAN (LAN1/LAN2) may cause security problems.

  • Page 94: Monitor Ip List

    4.3.3 Monitor IP List AirLive WIAS-1200G will send out a packet periodically to monitor the connection status of the IP addresses on the list. If the monitored IP address does not respond, the system will send an e-mail to notify the administrator that such destination is not reachable.

  • Page 95: Walled Garden List

    AirLive WIAS-1200G User’s Guide 4.3.4 Walled Garden List This function provides some free services to the users to access websites listed here before login and authentication. Up to 20 addresses or domain names of the websites can be defined in this list. Users without the network access right can still have a chance to experience the actual network service free of charge.

  • Page 96: Proxy Server Properties

    Internal Proxy Server: AirLive WIAS-1200G has a built-in proxy server. If this function is enabled, the end users will be forced to treat AirLive WIAS-1200G as the proxy server regardless of the end-users’ original proxy settings.

  • Page 97: Dynamic Dns

    4.3.6 Dynamic DNS AirLive WIAS-1200G provides a convenient DNS function to translate the IP address of WAN port to a domain name that helps the administrator memorize and connect to WAN port. If the DHCP is activated at WAN port, this function will also update the newest IP address regularly to the DNS server.

  • Page 98: Utilities

    AirLive WIAS-1200G User’s Guide 4.4 Utilities This section provides four utilities to customize and maintain the system including Change Password, Backup/Restore Setting, Firmware Upgrade and Restart.

  • Page 99: Network Utilities

    AirLive WIAS-1200G User’s Guide 4.4.1 Network Utilities The system provides three network diagnostic tools like PING, Trace Route, and ARP Table, for the administrator to diagnose the network status. PING: Enter the desired IP address such as “10.30.1.254” and click PING button to execute PING. The ping result will be shown on the screen.

  • Page 100: Change Password

    4.4.2 Change Password There are three levels of authorities to use: admin, manager or operator. The default usernames and passwords are as follow: Admin: The administrator can access all configuration pages of the AirLive WIAS-1200G. User Name: admin Password: airlive Manager: The manager can only access the configuration pages under User Authentication to manage the user accounts, but has no permission to change the settings of the profiles for Firewall, Specific Route and Schedule.
  • Page 101 AirLive WIAS-1200G User’s Guide Operator: The operator can only access the configuration page of Create On-demand User to create and print out the new on-demand user accounts. User Name: operator Password: airlive...
  • Page 102 AirLive WIAS-1200G User’s Guide The administrator can change the passwords here. Please enter the current password and then enter the new password twice to verify. Click Apply to activate this new password. Note: If the administrator’s password is lost, the administrator’s password still can be changed through the text...

  • Page 103: Backup/Restore Setting

    Restore System Setting: Click Browse to search for a .db database backup file created by AirLive WIAS-1200G and click Restore to restore to the same settings at the time the backup file was created. Resetting to the Factory-Default configuration: Click Reset to load the factory default settings of AirLive...

  • Page 104: Firmware Upgrade

    This function allows the administrator to safely restart AirLive WIAS-1200G and the process should take about three minutes. Click YES to restart AirLive WIAS-1200G; click NO to go back to the previous screen. If the power needs to be turned off, restarting AirLive WIAS-1200G first and then turning off the power after completing the restart process is highly recommended.

  • Page 105: Status

    AirLive WIAS-1200G User’s Guide 4.5 Status This section includes System Status, Interface Status, Current Users, Traffic History, and Notification Configuration to provide system status information and online user status.

  • Page 106: System Status

    Description Item The present firmware version of AirLive WIAS-1200G Current Firmware Version The system name. The default is AirLive WIAS-1200G System Name The information to be shown on the login screen when a Admin Info user has a connection problem.
  • Page 107 AirLive WIAS-1200G User’s Guide The IP address and port number of the external Syslog Syslog server-On demand User log Server. N/A means that it is not configured. Enabled/disabled stands for that the system is currently Proxy Server using the proxy server or not.

  • Page 108: Interface Status

    AirLive WIAS-1200G User’s Guide 4.5.2 Interface Status This section provides an overview of the interface for the administrator including WAN, LAN1 & LAN2, LAN3 & LAN4, and Wireless Port.
  • Page 109 The IP address of the wireless port. IP Address The Subnet Mask of the wireless port. Subnet Mask Wireless The ESSID of the wireless port, such as AirLive SSID WIAS-1200G. The assigned Channel of the Wireless port. Channel Enabled/disabled stands for the status of the encryption Encryption Function function of the wireless port.

  • Page 110: Current Users

    AirLive WIAS-1200G User’s Guide The IP address of the LAN3 & LAN4. IP Address The Subnet Mask of the LAN3 & LAN4. Subnet Mask Enable/disable stands for status of the DHCP server on Status the LAN3 & LAN4 port The WINS server IP on DHCP server. N/A means that it is WINS IP Address LAN3 &...

  • Page 111: Traffic History

    User’s Guide 4.5.4 Traffic History This function is used to check the history of AirLive WIAS-1200G. The history of each day will be saved separately in the DRAM for at least3 days. Note: Since the history is saved in the SDRAM, if you need to restart the system and also keep the history, then please manually copy and save the information before restarting.

  • Page 112: Notify Configuration

    4.5.5 Notify Configuration The AirLive WIAS-1200G will save the traffic history into the internal DRAM. If the administrator wants the system to automatically send out the history to a particular email address, please enter the related information in these fields.

  • Page 113: Help

    AirLive WIAS-1200G User’s Guide 4.6 Help On the screen, the Help button is on the upper right corner. Click Help to the Online Help window and then click the hyperlink of the items to get the information.

  • Page 114: Appendix A - Console Interface

    Enter key to make selection or confirm what you enter. 3. Once the console port of AirLive WIAS-1200G is connected properly, the console main screen will appear automatically. If the screen does not appear in the terminal simulation program automatically, please try to press the arrow keys, so that the terminal simulation program will send some messages to the system and the welcome screen or the main menu should appear.
  • Page 115 AirLive WIAS-1200G User’s Guide Utilities for network debugging The console interface provides several utilities to assist the Administrator to check the system conditions and to debug any problems. The utilities are described as follow: Ping host (IP): By sending ICMP echo request to a specified host and wait for the response to test the network status.
  • Page 116 Although it does not require a username and password for the connection via the serial port, the same management interface can be accessed via SSH. Therefore, we recommend you to immediately change the AirLive WIAS-1200G Admin username and password after logging in the system for the first time.

  • Page 117: Appendix B - Accepting Payments Via Authorize.net

    AirLive WIAS-1200G User’s Guide Appendix B – Accepting Payments via Authorize.Net This section is to show independent Hotspot owners how to configure related settings in order to accept credit card payments via Authorize.Net, making the Hotspot an e-commerce environment for end users to pay for and obtain...
  • Page 118 1. Setting Up 1.1 Open Accounts To set up AirLive WIAS-1200G to process credit card billing, the merchant owner will need two accounts (Internet Merchant account and Authorize.Net account). If you are looking for a merchant account or Internet payment gateway to process transactions, you can fill out the Inquiry Form on http://www.authorize.net/solutions/merchantsolutions/merchantinquiryform/.
  • Page 119 Verification System (AVS) → Check the boxes accordingly → Click Submit. 1.4 Test The Credit Card Payment via Authorize.Net To test the connection between AirLive WIAS-1200G and Authorize.Net, please log in AirLive WIAS-1200G. User Authentication → Authentication Configuration → Click the server On-demand User → On-demand User Server Configuration →...
  • Page 120 Authorize.Net as well as AirLive WIAS-1200G. 2.1 Void A Transaction and Remove the On-demand Account Generate on AirLive WIAS-1200G Sometimes, a transaction (as well as the related user account on AirLive WIAS-1200G) may have to be canceled before it has been settled with the bank.
  • Page 121 2.4 Send An Email Receipt to A Customer If a valid email address is provided, AirLive WIAS-1200G will automatically send the customer an email receipt for each successful transaction via Authorize.Net. To change the information on the receipt for customer, please log in AirLive WIAS-1200G.
  • Page 122 3.2 Transaction Statistics by Different Location a. To deploy more than one AirLive WIAS-1200G, the way to distinguish transactions from different locations is to make the invoice numbers different. To change the invoice setting, please log in AirLive WIAS-1200G. User Authentication →...

  • Page 123: Appendix C - Accepting Payments Via Paypal

    AirLive WIAS-1200G User’s Guide Appendix C – Accepting Payments via PayPal This section is to show independent Hotspot owners how to configure related settings in order to accept payments via PayPal, making the Hotspot an e-commerce environment for end users to pay for and obtain Internet access...
  • Page 124 AirLive WIAS-1200G User’s Guide 1. Setting Up As follows are the basic steps to open and configure a “Business Account” on PayPal. 1.1 Open An Account Step 1: Sign up for a PayPal Business Account and login. Here is a link: https://www.paypal.com/cgi-bin/webscr?cmd=_registration-run Step 2: Edit necessary settings in “Website Payment Preferences”...
  • Page 125 AirLive WIAS-1200G User’s Guide Settings Screenshots Auto Return (On) Return URL (Redirect Webpage) Type http://www.www.com or other URL. Payment Data Transfer (On) Block Non-encrypted Website Payment (Off) PayPal Account Optional (Off) Contact Telephone Number (Off) Click Save.
  • Page 126 AirLive WIAS-1200G User’s Guide 1.2 Configure AirLive WIAS-1200G with a PayPal Business Account Please log in AirLive WIAS-1200G: User Authentication → Authentication Configuration → Click the server On-demand User → On-demand User Server Configuration → Click Payment → Payment Configuration → External Payment Gateway → Select...
  • Page 127 PayPal website as well as AirLive WIAS-1200G. 2.1 Refund a completed payment and remove the on-demand account generated on AirLive WIAS-1200G (1) To refund a payment, please log in PayPal → Click History → Locate the specific payment listing in the activity history log →...
  • Page 128 → Click Details of the payment listing → Username can be found in the “Item Title” field (2) To find the password associated with a specific username, please log in AirLive WIAS-1200G: User Authentication → Authentication Configuration → Click the server On-demand User → On-demand User Server Configuration →...
  • Page 129 AirLive WIAS-1200G User’s Guide 2.4 Send an email receipt for each transaction to the merchant A copy of email receipt with payment details (including available message note from buyer) for each successful transaction will also be automatically sent to the merchant owner/administrator via PayPal.

  • Page 130: Appendix D - Examples Of Making Payments For End Users

    AirLive WIAS-1200G User’s Guide Appendix D – Examples of Making Payments for End Users 1. Making Payments via Authorize.Net Step 1: Click the link below the login window to pay for the service by credit card via Authorize.Net. Step 2: Choose I agree to accept the terms of use and click Next.
  • Page 131 AirLive WIAS-1200G User’s Guide Step 3: Please fill out the form and Click Submit to send out this transaction. There will be a confirm dialog box. Step 4: Please confirm the data and the click OK to go on the transaction or click Cancel to revise the data or cancel...
  • Page 132 AirLive WIAS-1200G User’s Guide Step 5: Click OK to complete the process or click Cancel to revise the data or cancel this transaction. Step 6: Click Start Internet Access to use the Internet access service. Note: The clients must fill in the correct credit card number and expiration date. Card code is the last 3 digits of the security code located on the back of your credit card.
  • Page 133 AirLive WIAS-1200G User’s Guide 2. Making Payments via PayPal Step 1: Click the link below the login window to pay for the service via PayPal. Step 2: Choose I agree to accept the terms of use and click Next. Step 3: Please fill out the form and Click Submit to send out this transaction. There will be a confirm dialog box.
  • Page 134 AirLive WIAS-1200G User’s Guide Step 4: You will be redirected to PayPal website to complete the payment process.
  • Page 135 AirLive WIAS-1200G User’s Guide Step 5: Click Start Internet Access to use the Internet access service. Note: 1. Payment is accepted via PayPal. PayPal enables you to send payments securely online using PayPal account, a credit card or bank account. Clicking on Buy Now button, you will be redirected to PayPal’s site to make payment.

  • Page 136: Appendix E - Proxy Setting For Hotspot

    AirLive WIAS-1200G User’s Guide Appendix E – Proxy Setting for Hotspot HotSpot is a place such as a coffee shop, hotel, or a public area where provides Wi-Fi service for mobile and temporary users. HotSpot is usually implemented without complicated network architecture and using some proxy servers provided by Internet Service Providers.
  • Page 137 AirLive WIAS-1200G User’s Guide Click the Proxy Server Properties from left menu and the homepage of the Proxy Server Properties will appear. Add the ISP’s proxy Server IP and Port into External Proxy Server Setting.
  • Page 138 AirLive WIAS-1200G User’s Guide Enable Built-in Proxy Server in Internal Proxy Server Setting. Click Apply to save the settings.

  • Page 139: Appendix F - Proxy Setting For Enterprise

    AirLive WIAS-1200G User’s Guide Appendix F – Proxy Setting for Enterprise Enterprises usually isolate their intranet and internet by using more elaborated network architecture. Many enterprises have their own proxy server which is usually at intranet or DMZ under the firewall protection.
  • Page 140 AirLive WIAS-1200G User’s Guide Gateway setting Login Gateway by using “admin”. Click the Network Configuration from top menu and the homepage of the Network Configuration will appear. Click the Proxy Server Properties from left menu and the homepage of the Proxy Server Properties will...
  • Page 141 AirLive WIAS-1200G User’s Guide Add your proxy Server IP and Port into External Proxy Server Setting. Disable Built-in Proxy Server in Internal Proxy Server Setting. Click Apply to save the settings. Note If your proxy server is disabled, it will make the user authentication operation abnormal. When users open the browser, the login page won’t appear because the proxy server is down.

  • Page 142: Client Setting

    AirLive WIAS-1200G User’s Guide Client setting It is necessary for clients to add default gateway IP address into proxy exception information so the user login successful page can show up normally. Use command “ipconfig” to get Default Gateway IP Address.
  • Page 143 AirLive WIAS-1200G User’s Guide For Firefox...

  • Page 144: Appendix G - Disclaimer For On-Demand Users

    Appendix G – Disclaimer for On-Demand Users In AirLive WIAS-1200G, the end user first gets a login page when she/he opens its web browser right after associating with an access point. However, in some situations, the hotspot owners or MIS staff may want to display “terms of use”...
  • Page 145 AirLive WIAS-1200G User’s Guide // return cookie value section i = pham.indexOf(" ", i) + 1; // move i to next name=value pair if (i == 0) break; // no more values in cookie string return null; // cookie not found function CodeCookie(str) var strRtn="";...
  • Page 146 AirLive WIAS-1200G User’s Guide if (a[i].indexOf("#")!=0){ d.MM_p[j]=new Image; d.MM_p[j++].src=a[i];}} function MM_findObj(n, d) { //v4.01 var p,i,x; if(!d) d=document; if((p=n.indexOf("?"))>0&&parent.frames.length) { d=parent.frames[n.substring(p+1)].document; n=n.substring(0,p);} if(!(x=d[n])&&d.all) x=d.all[n]; for (i=0;!x&&i<d.forms.length;i++) x=d.forms[i][n]; for(i=0;!x&&d.layers&&i<d.layers.length;i++) x=MM_findObj(n,d.layers[i].document); if(!x && d.getElementById) x=d.getElementById(n); return x; function MM_swapImage() { //v3.0 var i,j=0,x,a=MM_swapImage.arguments; document.MM_sr=new Array; for(i=0;i<(a.length-2);i+=3) if ((x=MM_findObj(a[i]))!=null){document.MM_sr[j++]=x;...
  • Page 147 AirLive WIAS-1200G User’s Guide alert("Please enter password."); form.mypassword.focus(); form.mypassword.select(); disableButton=false; return false; if(disableButton==true) alert("The system is now logging you in, please wait a moment."); return false; else disableButton=true; return true; return true; function reminder_onclick(form) Reminder.myusername.value = form.myusername.value; Reminder.mypassword.value = form.mypassword.value;...
  • Page 148 AirLive WIAS-1200G User’s Guide disclaimer.style.display='none'; login.style.display=''; return true; </script> </head> <body style="font-family: Arial" bgcolor="#FFFFFF" onload="init(Enter);MM_preloadImages('../images/submit0.gif','../images/clear0.gif','../images/remaining0.gif')"> <ilayer width=&{marquee_width}; height=&{marquee_height}; name="cmarquee01"> <layer name="cmarquee02" width=&{marquee_width}; height=&{marquee_height};></layer> </ilayer> <form action="userlogin.shtml" method="post" name="Enter"> <table name="disclaimer" id="disclaimer" width="460" height="430" border="0" align="center" background="../images/agreement.gif"> <tr> <td height="50" align="center" valign="middle"><div align="center" class="style5">Service Disclaimer</div></td>...
  • Page 149 AirLive WIAS-1200G User’s Guide information for accuracy, and verify it with third parties. We may disclose personal information to respond to legal requirements, enforce our policies, respond to claims that an activity violates the rights of others, or protect anyone's rights, property, or safety.
  • Page 150 AirLive WIAS-1200G User’s Guide <tr> <td height="40"><table width="170" height="20" border="0" align="center" cellpadding="2"> <tr> <td align="left"><input name="selection" value="1" type="radio"></td> <td><span class="style4">I agree.</span></td> </tr> <tr> <td align="left"><input name="selection" value="2" checked type="radio"></td> <td><span class="style4">I disagree.</span></td> </tr> </table></td> </tr> <tr> <td height="30"><table width="110" height="20" border="0" align="center" cellpadding="2">...
  • Page 151 AirLive WIAS-1200G User’s Guide <tr> <td colspan="2"> <div align="center"> <a onclick="javascript:if(Before_Submit(Enter)){Enter.submit();}" onMouseOut="MM_swapImgRestore()" onMouseOver="MM_swapImage('Image3','','../images/submit0.gif',1)"> <img src="../images/submit.gif" name="Image3" width="124" height="38" border="0" > </a> <a onclick="cancel_onclick(Enter)" onMouseOut="MM_swapImgRestore()" onMouseOver="MM_swapImage('Image5','','../images/clear0.gif',1)"> <img src="../images/clear1.gif" name="Image5" width="124" height="38" border="0"> </a> <a onclick="javascript:if(Before_Submit(Enter)){reminder_onclick(Enter);}" onMouseOut="MM_swapImgRestore()" onMouseOver="MM_swapImage('Image4','','../images/remaining0.gif',1)"> <img src="../images/remaining.gif" name="Image4" width="124" height="38" border="0">...
  • Page 152 AirLive WIAS-1200G User’s Guide <td width="100%"> <font color="#808080" size="2"><script language="JavaScript">document.write(copyright);</script></font></td> </tr> </table> </div> </body> </html>...

  • Page 153: Appendix H - Network Configuration & External Network Access

    Appendix H – Network Configuration & External Network Access 1. Network Configuration on PC After AirLive WIAS-1200G is installed, the following configurations must be set up on the PC: Internet Connection Setup and TCP/IP Network Setup. Internet Connection Setup Windows 9x/2000 1) Choose Start >...
  • Page 154 AirLive WIAS-1200G User’s Guide 3) Choose “I want to set up my Internet connection manually, or I want to connect through a local Area network (LAN)”, and then click Next. 4) Choose “I connect through a local area network (LAN)” and click Next.
  • Page 155 AirLive WIAS-1200G User’s Guide 6) Choose “No”, and click Next 7) Finally, click Finish to exit the Internet Connection Wizard. Now, the set up has been completed. Windows XP 1) Choose Start > Control Panel > Internet Option.
  • Page 156 AirLive WIAS-1200G User’s Guide 2) Choose the “Connections” label, and then click Setup. 3) Click Next when Welcome to the New Connection Wizard screen appears. 4) Choose “Connect to the Internet” and then click Next.
  • Page 157 AirLive WIAS-1200G User’s Guide 5) Choose “Set up my connection manually” and then click Next. 6) Choose “Connect using a broadband connection that is always on” and then click Next. 7) Finally, click Finish to exit the Connection Wizard. Now, you have completed the setup.
  • Page 158 With the factory default settings, during the process of starting the system, AirLive WIAS-1200G with DHCP function will automatically assign an appropriate IP address and related information for each PC. If the Windows operating system is not a server version, the default settings of the TCP/IP will regard the PC as a DHCP client, and this function is called “Obtain an IP address automatically”.
  • Page 159 AirLive WIAS-1200G. 4) Using Specific IP Address: If you want to use specific IP address, you have to ask the network administrator for the information of AirLive WIAS-1200G: IP address, Subnet Mask, New gateway and DNS server address. Note: If your PC has been set up completed, please inform the network administrator before proceeding to the following steps.
  • Page 160 AirLive WIAS-1200G User’s Guide Choose “Gateway” label and enter the gateway address of AirLive WIAS-1200G in the “New gateway:” and then click Add and OK. Choose “DNS Configuration” label. If the DNS Server column is blank, please click Enable DNS and then enter the DNS address or the DNS address provided by ISP.
  • Page 161 4) Using DHCP: If want to use DHCP, please choose “Obtain an IP address automatically” and click OK. This is also the default setting of Windows. Then, reboot the PC to make sure an IP address is obtained from AirLive WIAS-1200G.
  • Page 162 User’s Guide 5) Using Specific IP Address: If you want to use specific IP address, you have to ask the network administrator for the information of the AirLive WIAS-1200G: IP address, Subnet Mask, New gateway and DNS server address. Note: If your PC has been set up completed, please inform the network administrator before proceeding to the following steps.
  • Page 163 Add below the “Default Gateways” column and the “TCP/IP Gateway Address” window will appear. Enter the gateway address of AirLive WIAS-1200G in the “Gateway” of “TCP/IP Gateway Address” window, and then click Add. After back to the “IP Settings” label, click OK to finish.
  • Page 164 4) Using DHCP: If want to use DHCP, please choose “Obtain an IP address automatically” and click OK. This is also the default setting of Windows. Then, reboot the PC to make sure an IP address is obtained from AirLive WIAS-1200G.
  • Page 165 AirLive WIAS-1200G User’s Guide 5) Using Specific IP Address: If want to use specific IP address, you have to ask the network administrator for the information of the AirLive WIAS-1200G: IP address, Subnet Mask, New gateway and DNS server address. Note: If your PC has been set up completed, please inform the network administrator before proceeding to the following steps.
  • Page 166 2. External Network Access If all the steps are set properly, AirLive WIAS-1200G can be further connected to the managed network to experience the controlled network access environment. Firstly, connect an end-user device to the network at AirLive WIAS-1200G’s LAN1/LAN2 and set to obtain an IP address automatically. After the network address is obtained at the user end, open an Internet browser and link to any website.
  • Page 167 User’s Guide the local user account (e.g. test@Local for the username and test for the password) to connect the network. 2) Login page appearing means AirLive WIAS-1200G has been installed and configured successfully. Now, you can browse the network or surf the Internet! 3) If the screen shows “Sorry, this feature is available for...
  • Page 168 AirLive WIAS-1200G User’s Guide 5) When an on-demand user logs in successfully, the following Login Successfully screen will appear. There is an extra line showing “Remaining usage” and a “Redeem” button. Remaining usage: Show the rest of use time that the on-demand user can surf Internet.

  • Page 169: Appendix I - Common Settings

    In the Quick Installation Guide, two common scenarios are described below that allows you to use the Configuration Wizard utility to speed up the configuration process of AirLive WIAS-1200G. Please refer to section 1. Hotspot for hotspot environment and section 2. SMB for small & medium size business environment.
  • Page 170 After completing the hardware installation and successfully logging into the web management interface, AirLive WIAS-1200G can then be configured from the web browser. In the hotspot environment, it is convenient to use the built-in authentication server to quickly setup the services. One example is to set Local User authentication method in the Configuration Wizard for employees and for visitors.
  • Page 171 NTP Server: Enter the URL of the external time server for AirLive WIAS-1200G time synchronization or use the default. DNS Server: Enter a DNS Server provided by your ISP (Internet Service Provider). Contact your ISP if you are not sure of the DNS IP Address.
  • Page 172 An authentication method has to be selected from one of the five options appeared in this window (Local User is selected for this example). Local User is an authentication method that uses the built-in user database supported by AirLive WIAS-1200G. Click Next to continue.
  • Page 173 Step 6. Set Wireless – Access Point Connection SSID: Enter a SSID (up to 32 characters) for the system. The default is airlive. SSID (Service Set Identifier) is a unique identifier used for the wireless client’s devices to associate with the built in AP of AirLive WIAS-1200G.
  • Page 174 Now, the basic configuration for Hotspot environment has been finished! If all the steps are done properly, AirLive WIAS-1200G can be further connected to the managed network to experience the controlled network access environment. Firstly, connect a client’s networking device to Public Port or Wireless interface of...
  • Page 175 2. SMB (Small & Medium Size Business) AirLive WIAS-1200G used in the enterprise environment (mostly small and medium size business) is usually connected Internet through ADSL. Please refer to the following figure on connecting AirLive WIAS-1200G with ADSL modem. After completing the hardware installation and successfully logging into the web management interface, AirLive...
  • Page 176 AirLive WIAS-1200G User’s Guide Click the System Configuration from the top menu and the System Configuration page will appear. Then, click on Configuration Wizard. Click Run Wizard to begin the Configuration Wizard. The Setup Wizard will appear in a separated window.
  • Page 177 Home Page: Enter the URL that clients should be initially redirected to after successfully authenticated. NTP Server: Enter the URL of the external time server for AirLive WIAS-1200G time synchronization or use the default. DNS Server: Enter a DNS Server provided by your ISP (Internet Service Provider).
  • Page 178 AirLive WIAS-1200G User’s Guide Step 4: Select the Connection Type for WAN Port Select a proper Internet connection. Static IP Address is chosen as the example for SMB scenario. Static IP Address is an assigned IP address from the ISP used to connect to the Internet.
  • Page 179 Step 6: Set Wireless – Access Point Connection SSID: Enter a SSID (up to 32 characters) for the system. The default is airLive. SSID (Service Set Identifier) is a unique identifier used for the wireless client’s device to associate with the built in AP of AirLive WIAS-1200G.
  • Page 180 Now, the basic configuration for SMB environment has been finished! If all the steps are done properly, AirLive WIAS-1200G can b further connected to the managed network to experience the controlled network access environment. Firstly, connect a client’s networking device to Public Port or Wireless Interface...

Table of Contents
