Page 1 ES-6000 Email Server Appliance User’s Manual...
Page 2 Copyright & Disclaimer No part of this publication may be reproduced in any form or by any means, whether electronic, mechanical, photocopying, or recording without the written consent of OvisLink Corp. OvisLink Corp. has made the best effort to ensure the accuracy of the information in this user’s guide. However, we are not liable for the inaccuracies or errors in this guide.
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction ......................... 5 1.1 Functions and Features ........................5 1.2 Front Panel ............................7 1.3 Packing List............................7 Chapter 2 System Wizard ......................8 Chapter 3 System ........................14 3.1 Admin ..............................14 3.2 Interface ............................17 3.3 Setting ...............................
Page 4 6.1 Configure ............................88 6.1.1 Setting ........................... 88 6.1.2 Mail Notice..........................90 6.2 Anti-Spam............................97 6.2.1 Setting ........................... 97 6.2.2 Personal Rule........................100 6.2.3 Global Rule.......................... 101 6.2.4 Whitelist..........................103 6.2.5 Blacklist ..........................104 6.2.6 Auto-Whitelist ........................105 6.2.7 Training..........................106 6.3 Anti-Spam Configuration Example ....................
Page 5 11.2 A (Address)............................ 187 11.3 CNAME (Canonical NAME) ......................188 11.4 MX (eXchanger) ..........................189 11.5 SPF (Sender policy FrameWork) ....................191 11.6 Example ............................192 11.6.1 Setup a host name server ....................192 11.6.2 Mapping between Servers (Web / FTP / Mail) and Domain Name ........196 Chapter 12 Web Server Setting ....................
Page 6: Chapter 1 Introduction
IMAP(s), it also supports the Web Mail to allow user accessing mail via browser no matter where you are, and the Web Disk function to offer a solution for delivering large file, so user can download file from ES-6000 directly, and do not need to worry about mail box’s limitation. Meanwhile, the ES-6000 Push Mail function can deliver mail subject to mobile phone, so user can check the mail in anytime and anywhere without carrying laptop.
Page 7 DNS service at ISP. Remote Backup ES-6000 will record every passing mail as the record, and backup the record to NAS or File Server by schedule. Those mail records can also be retrieved from NAS or File Server via ES-6000.
Page 8: Front Panel
Use this port to connect to a router, DSL modem, Cable modem, or Switch. Mail Port Use this port to connect another ES-6000 device for HA function HA Port 9-pin serial port connector for checking setting and restore to the factory...
Page 9: Chapter 2 System Wizard
When it is first time for user to login ES-6000, system will switch to Wizard page automatically, so user can follow the wizard to configure mail server setting step by step. Connect the PC and ES-6000’s port 1 to the same Hub / Switch, and launch the browser (IE or Step1.
Page 10 Select the language and character encoding. (Figure 2-3) Step4. Figure 2-3 Select the language and character encoding When system can not identify the data character encoding that is going to be saved into database, it will use the default setting. Go to System ( Interface, enter the following setting: (Figure 2-4) Step5.
Page 11 Go to System Synchronize System Clock, enable Synchronize with an Internet Time Step6. Server and set up offset hours from GMT to assure the correct time. (Figure 2-5) Figure 2-5 Synchronize time setting If the local area executes the daylight saving time, then enable the Daylight Saving Time Setting. Enter corresponding domain alias.
Page 12 Apply permitted mail relay segments and domains. (Figure 2-7) Step8. Figure 2-7 Mail relay setting If resolving domain name is needed, please enable the DNS Setting option. Once the DNS Step9. Setting is enabled, the install wizard will take you to a further DNS setting after you click Finish. (Figure 2-8) Figure 2-8 Install completed...
Page 13 Step10. Figure 2-9 Setup account learning approach and default value for new account If necessary, select to enable HA feature and configure the IP address of another ES-6000. Both Step11. devices will synchronize the database when the connection builds up. (Figure 2-10)
Page 14 Prompt users that the listed ports below should be remaining open on Perimeter Gateway while Step12. ES-6000 is functioning. (Figure 2-12) Figure 2-12 Attention Click Finish. Step13.
Page 15: Chapter 3 System
The system administration refers to the competency to manage the ES-6000. In this Chapter, it will be defined as the Admin, Interface, Setting, Date/ Time, Logout, Install Wizard, Language, and Software Update. 3.1 Admin ES-6000 is managed by the main system administrator. The main system administrator can add or delete any system settings and monitor the system status.
Page 16 Adding a Sub Admin In Admin Setting window, click the New Sub Admin. Step1. In Add New Sub Admin window, enter the following information : (Figure 3-1) Step2. Sub Admin : sub_admin Password : 12345 Confirm Password : 12345 Privilege set Low. If a new sub admin was given high privilege, which will make him a main admin.
Page 17 Step1. that admin. In Modify Admin Password window, enter the following information : Step2. Password : airlive New Password : 52364 Confirm Password : 52364 (Figure 3-2) Click OK to change the password or click Cancel to cancel the setting.
Page 18: Interface
3.2 Interface Interface Interface Address The administrator can set the IP login information in ES-6000. Interface Address Setting Go to System Interface, enter the following setting : Step1. In IP Address, Netmask and Default Gateway fields, enter a valid IP of the LAN subnet.
Page 19: Setting
Management Interface Port ES-6000 allows system administrator to perform remote control from everywhere through web browser. The port number for HTTP or HTTPS protocol is alterable. The port number is required for accessing the management interface from external network. User can choose to select HTTP or HTTPS based on the requirement.
Page 20 Exporting System Setting to Client Go to System next to Export System Step1. Setting System Setting, click Setting to Client. When confirmation dialogue box File Download appears, click Save button, and it will show Step2. where the file will be saved. Click Save button again. The system setting file will be copied to the appointed directory.
Page 21 System Setting; click Browse next to Import System Setting to Step1. Setting Client. In Choose File window, go to the directory where the ES-6000 system setting file was stored Step2. and select the file, then click Open. (Figure 3-5) Click the lower right OK, the window will closed.
Page 22 Resetting Factory Setting & Formatting Built-in Hard Disk Go to System Setting, select Reset Factory Setting and Format Hard Disk. Step1. Click OK on the lower right, it will start restoring to the factory setting and formatting the built-in Step2. hard disk at the same time.
Page 23 Mail Notice Setting Enter the name of the company in the blank field next to Company Name. Step1. Enter “ES-6000” in the blank field next to Device Name. Step2. Tick Enable Mail Alert Notification / Report. Step3. Enter an internal email address in Internal E-mail Account field.
Page 24: Storage Device
User can define the mail server’s storage device to store the mail; by default, the mail will be stored at ES-6000 local hard disk, but its capacity is limited; it can be also stored at remote storage device such as file server or NAS, the capacity is flexible but the performance is less than local hard disk.
Page 25: Date/Time
3.5 Date/Time Date / Time Synchronize System Clock This option can synchronize system clock with the administrator’s PC or the external time server. The international standard time (Greenwich Mean Time: GMT) Daylight Saving Time Daylight saving time (also called DST, or Summer Time) is a portion of the year in which a region's local time is advanced by an hour from its standard official time.
Page 26: Software Update
Version Number indicates the current version that is running. Log onto Internet to obtain the Step1. latest version of firmware and download it onto the ES-6000 built-in hard disk. Click Browse, then Choose File window pops up, after that, please select the latest firmware Step2.
Page 27: Chapter 4 Mail Management
4.1 Configure Mail configure refers to policies of mail services, it is divided into three parts, namely mail management, domain alias and mail relay. Mail setting: Determines of which cryptographic method and port number will be used in each service Assigns a port exclusively for logging to web mail interface.
Page 28 Max. message queueing time: What if users’ mails failed the delivery, the mail will save in ES-6000 queue and waiting for the next delivery. Users can define the lifetime of mail in queue, when the lifetime is end, the mail will be removed from queue and return a failure notification to sender.
Page 29 Figure 4-2 Mail Configuration setting Default Value of New Account: Allocates the default size of mailbox, Inbox, Web Disk and the maximum size of incoming mails. (The settings here does not apply to those settings made in individual mail management ) Below is an example for your reference : 1.
Page 30 Figure 4-3 Mail management configuration Once Inbox Quota Auto-Adjustment is enabled, ES-6000 will check each built-in mail account for available inbox storage. Both the account user and the system administrator will receive an e-mail notification about inbox usage reaching 80%; when inbox usage reaches 90%, the device will send out an e-mail notification as well as delete the older e-mail messages until the usage has lowered to 70%.
Page 31 Figure 4-4 Opening Internet Accounts 2. Click Mail tab and then the desired account to change. Next, click Properties on the right. (Figure 4-5) Figure 4-5 Opening Internet Accounts...
Page 32 3. In the Properties window, click Advanced tab to adjust the port numbers for SMTP and POP3 protocols. When finished, click OK. (Figure 4-6) Figure 4-6 Server Port Number Settings 4. Close Internet Accounts window. (Figure 4-7) Figure 4-7 Closing Internet Accounts...
Page 33: Web Mail Logo
4.1.2 Web Mail Logo ES-6000 allows user to upload a background picture as web mail wallpaper. The image file should be limited Max. File Size: 1 Mbytes Resolution: 1022 x 622 pixels File Types: jpg, jpeg, jpe, gif, bmp, png... (Figure 4-8) Figure 4-8 Upload picture as wallpaper If user would like to check the display, click “Preview”...
Page 34: Multiple Domains
Domain Alias On ES-6000, each mail domain can also create Domain Alias. The difference between Multiple Domain and Domain Alias is that Multiple Domains have their own mail accounts, but the account of Domain Alias is the same one of Mail Domain. So, when user sends mail to an account of Mail Domain and Domain Alias, actually the mails will be sent to the same mail box.
Page 35 Figure 4-11 Typing the Domain Alias Figure 4-12 Alias Added Figure 4-13 Typing the Second Domain Name Figure 4-14 Typing the Domain Alias Figure 4-15 Alias Added Figure 4-16 Second Entry Completed E-mails that go to stan@test.com or its alias stan@test1.com will be stored in the same storage Step3.
Page 36 E-mails that go to stan@test-info.com or its alias stan@test-sales.com will be stored in the same Step4. storage location, the internal account “stan” will be able to retrieve them by logging in to either account. It can be concluded from Step 3 and 4 no matter how many aliases a domain has, whether Step5.
Page 37: Mail Relay
ES-6000 Virtual IP Address set as 192.168.0.248 ES-6000 Physical IP Address set as 60.250.158.64 Map registered domain name “airlive.com” to DNS IP address which is assigned mail server IP to MX record. Enable internal senders to send mails, please go to Mail Management Step1.
Page 38 Mail Relay for settings: Click New Entry. Check Domain Name. (This enables relay to this Domain name) Domain Name set as airlive.com Click OK to complete the setup process. (Figure 4-21, 4-22) Figure 4-21 Enter an domain name to enable relay...
Page 39: Mail Signatures
4.1.5 Mail Signatures Enable Mail Signature function will add the signature on all outgoing mails. On Mail Management Mail Signature setting, add a new entry. Step1. Configure Click Add signatures to all outgoing messages. Fill in the content you want to publish on the message. Press OK to finish the setting.
Page 40 User will fine the message on the bottom of mail content for all outgoing mails. (Figure 4-24) Step2. Figure 4-24 Recipient receives mail with signature...
Page 41: Mail Routing
Supposed the Relayed Domain Name / Mail Address setting is given an asterisk ( ), then e-mail delivery to the mail accounts, except for those of ES-6000, will be processed by the relay server you designated.
Page 42: Account Management
4.2.1 Setting Learning Account Setting Once recipient has logged in ES-6000, mail account will automatically be created on ES-6000 according to the account and password that has logged in; Or via communicating with the old mail server or the LDAP server, mail account will be imported as an internal account when the authentication is specified.
Page 43 When recipient has logged in ES-6000, with the old mail server’s authentication, mail account will automatically be created on ES-6000 according to recipient’s account and password. Meanwhile, ES-6000 will start to retrieve mails on the old mail server until all mails are all being transferred.
Page 44 Check Connect to LDAP Server and apply correlative addresses and settings. Click OK. (Figure 4-30) When recipient has logged in ES-6000, with the LDAP mail server’s authentication, mail account will automatically be created on ES-6000 according to recipient’s account and password.
Page 45: Individual
4.2.2 Individual Definition Export Account: To export exist accounts for backup and rearrangement, please go to Mail Management Account Management Individual: Click Export next to Export Account. Click Save in the confirmation dialogue box, then select folder for storage, after that, click Save.
Page 46 Figure 4-33 Choose account list file to import Figure 4-34 Choose import file type Figure 4-35 Confirm to import accounts...
Page 47 Individual Setting: To adjust individual setting, please go to Mail Management Account Management Individual: Click Add to Individual Setting. Enter account information in the Add New Account window. (Figure 4-36) Click OK to complete adding new account. (Figure 4-37) Check unwanted account, and then click Remove next to Individual Setting. Click OK in the confirmation dialogue box.
Page 48 Figure 4-38 Remove an account Auditing specific account can be achieved by forwarding or duplicating every mail into an assigned mailbox. User can find the user quickly with Classification function. Just click the first letter of name and it will display the account list started with specific letter.
Page 49: Group
4.2.3 Group In the path of Mail Management Group, set as followed: Account Management Click Add next to Group Setting. Name the group and select group member, then click the lower right OK in the Add New Group screen. (Figure 4-39, 4-40) Mails that go to a group account will be distributed to each group member.
Page 50: Shared Address Book
4.2.4 Shared Address Book User can search the target via Name, E-mail Address, Company Name, Office Name, and Job Title, and find out the matched one in ES-6000 Shared Address Book records. Export Address Book: To export the address book, go to Mail Management...
Page 51 Figure 4-42 Choose file to import Address Book Figure 4-43 Confirm to import Address Book Import Address Book from LDAP Server: To add contacts from a LDAP server, select Mail Management Account Management Shared Address Book and then set as below: Click on the hyperlink Add Addresses from LDAP, then enter all the necessary information in the pop-up window.
Page 52 Figure 4-44 Importing Contacts from a LDAP Server Figure 4-45 Contacts Imported from LDAP server Modify Address Book from LDAP Server: To add or modify Address books information: Click on New Entry on the bottom. In the Add Contact screen, fill out the contact’s information. (Figure 4-46) Click OK to complete adding new contact.
Page 53 Figure 4-46 Adding a Contact Figure 4-47 New Contact Added...
Page 54 Figure 4-48 Removing a Contact Search Address Book: Go to Mail Management Account Management Shared Address Book Click the search icon Type keyword in the column of “E-Mail Address”. Press Search button Display the searching result. (Figure 4-49) Figure 4-49 Address Book searching result...
Page 55 Search user mail address via Outlook Express: Shared Address Book is not only co-worked with ES-6000 Web Mail, user’s mail address also can be searched by Mail client software. We take Outlook Express as example to demonstrate how to search: Open Outlook Express Address Book.
Page 56 Figure 4-50 Open Outlook Express Address Book Figure 4-51 Open Internet Accounts managed windows...
Page 57 Figure 4-52 Create new Internet Account Figure 4-53 Define LDAP server IP address...
Page 58 Figure 4-54 Do not check Email Address due to the setting is incomplete Figure 4-55 Click Finish to complete the setting...
Page 59 Figure 4-56 Select new created Internet Account and Click Properties for more setting Figure 4-57 Highlight and copy ES-6000Shared Address Book LDAP directory...
Page 60 Figure 4-58 Configure LDAP server Advanced setting...
Page 61 Figure 4-59 Press Find People button to search target Figure 4-60 Select Advanced to define the searching condition and find the target...
Page 62: Queue
4.3 Queue Detailed delivery status is available for MIS engineer to have a better understanding and be able to react to it on the spot. Monitoring Mail Delivery Status, Responding on the Spot Go to Mail Management Mail Setting, set as followed: Step1.
Page 63 Figure 4-64 Resuming a Failed Delivery Figure 4-65 Erasing an E-Mail Delivery Figure 4-66 Queue Emptied...
Page 64: Connection Track
4.4 Connection Track Whether it is receiving, sending, or retrieving e-mails from mail server, Connection Track has the detailed log corresponding to each e-mail process. By which system administrator may use the log as reference to manage and adjust e-mail service. 4.4.1 Outbound SMTP User can use date, IP address, sender, recipient and content as keyword to search matched records.
Page 65: Inbound Smtp
4.4.2 Inbound SMTP User can use date, IP address, sender, recipient and content as keyword to search matched records stored in ES-6000. To use this feature, please follow the steps below: Press icon to enter the web page for searching mail log. (Figure 4-69) Figure 4-69 Inbound SMTP Enable searching duration and assign a period of time.
Page 66: Pop3 / Imap
4.4.3 POP3 / IMAP User can use date, IP address, sender, recipient and content as keyword to search matched records stored in ES-6000. To use this feature, please follow the steps below: Press icon to enter the web page for searching mail log. (Figure 4-71) Figure 4-71 POP3 / IMAP Enable searching duration and assign a period of time.
Page 67 Ex. Viewing Mail Log of Outgoing Mail Go to Mail Management Outbound SMTP, there it shows mail log of Step1. Connection Track outgoing mails. (Figure 4-73) Figure 4-73 Mail log of Outbound SMTP Click Detail for detail information. (Figure 4-74) Step2.
Page 68 Ex. Viewing Mail Log of Incoming Mail Go to Mail Management Inbound SMTP, there it shows mail log of Step1. Connection Track incoming mails. (Figure 4-75) Figure 4-75 Mail log of Inbound SMTP Click Detail for detail information. (Figure 4-76) Step2.
Page 69 Ex. Viewing Mail Log of Retrieved Mails from ES-6000 Go to Mail Management POP3 / IMAP, there it shows mail log of Step1. Connection Track retrieved mails from ES-6000. (Figure 4-77) Figure 4-77 Mail log of POP3 Click Detail for detail information. (Figure 4-78) Step2.
Page 70: Chapter 5 Web Mail
5.1 How to use Web Mail The example shows you how to use web mail: To use the web mail service, please type the default IP address 192.168.1.1 with the HTTP port Step1. (8080) or HTTPS port (1443) in the address of web browser. For example, http://192.168.1.1:8080 or https://192.168.1.1:1443 (Using 8080 or 1443 depends on protocol type.) (Figure 5-1) Enter user account and password.
Page 71 When user first uses web mail service, system will require user to enter basic information. Step2. Click Continue. (Figure 5-2) Select language, timezone offset, sender address and edit your signature below User Preference. (Figure 5-3) Click Save. Display preferences successfully saved. (Figure 5-4) Click Continue.
Page 72 Web based mail for easy mail access. (Figure 5-5) Step3. Figure 5-5 Web Mail Interface...
Page 73: How To Configure Web Mail User Preference
How to configure Web Mail User Preference Click Preference in the web-based mailbox main screen, and then set as below: (Figure 5-6) Click to edit sender name. Click sender name and the original name and mail address will be shown at the column. Rename the original name in Name field.
Page 74 Figure 5-9 Editing Personal Information...
Page 75: Importing Address Book From Outlook Express
Importing Address Book from Outlook Express To export the address book from Outlook Express, follow these steps: Step1. On the File menu, point to Export, and then click Address Book. (Figure 5-10) In the Address Book Export Tool dialog box, click Text File (Comma Separated Values), and then click Export.
Page 76 Figure 5-11 Selecting a File Type to Export Figure 5-12 Specifying the Storage Path and File Name...
Page 77 Figure 5-13 Selecting the Desired Fields to Export Figure 5-14 Export Process Completed...
Page 78 To import the address book, follow these steps: Step2. Click Address Book. (Figure 5-15) Click Import. (Figure 5-16) Locate the file by clicking Browse. Select “CSV (first line contains field names.csv)” as file format. Select “English Version” for Charset. Click Import. (Figure 5-17, 5-18) Figure 5-15 Clicking into Address Book Figure 5-16 Clicking into Import Screen...
Page 79 Figure 5-17 Clicking into Import Screen Figure 5-18 Address Book Successfully Imported...
Page 80: Using Web Disk To Transfer Large File
Using Web Disk to Transfer Large File Click Web Disk tab in the web-based mailbox main screen, and then: (Figure 5-19) Step1. Locate the file by clicking Browse under the Upload File to Web Disk bar. Click Upload button. (Figure 5-20, Figure 5-21) Figure 5-19 Select Web Disk on the web-based mailbox main screen...
Page 81 Figure 5-20 Uploading a File to ES-6000’s Built-in Web Disk Figure 5-21 File Uploaded...
Page 82 Click New Mail in the web-based mailbox main screen, and then: (Figure 5-22) Step2. In the Attachment column, click Browse corresponding to Web Disk field. Click the desired file and then click OK. (Figure 5-23) Click Add corresponding to Web Disk field. (Figure 5-24) Complete this e-mail with necessary information, such as subject, content and recipient address.
Page 83 Figure 5-24 Click Add to add hyperlink file to receiver Figure 5-25 Sending out the Message...
Page 84 The recipient opens the attachment and then download the attachment file through a HTML Step3. page provided by ES-6000 device: (Figure 5-26, Figure 5-27) Figure 5-26 Opening the Attachment Figure 5-27 Opening the Attachment...
Page 85: Using White List And Black List To Filter E-Mails
Using White List and Black List to Filter E-Mails Supposed the domain name “airlive.com” is registered to your organization; and you are using the account “josh” to log onto Web Mail, then: Click Preference in the Web Mail main screen, and then set as below: Step1.
Page 86 Figure 5-31 Creating the First Entry of Black List Figure 5-32 Creating the Second Entry of Black List Figure 5-33 Black List Completed When josh@airlive.com receives an e-mail from a Hotmail account: Step3. If the address is 123xyz@hotmail.com, then Josh will receive it.
Page 87: Using Push Mail To Access Instant Messages
Using Push Mail to Access Instant Messages Supposed the domain name “airlive15.dyndns.org” is registered to your organization; and you are using the account “jacky” to log onto Web Mail, then: Click Preference in the Web Mail main screen, and then set as below: Step1.
Page 88 Figure 5-35 User-defined Rule Settings When Jacky receives e-mails from any account except the hotmail account, then: Step2. He will be able to receive them on his mobile device immediately on condition that his mobile device supports push mail. He will not be able to receive mail from hotmail account on his mobile phone.
Page 89: Chapter 6 Mail Security
6.1 Configure Mail Security Configure item is the foundation of ES-6000 Anti-Spam and Anti-Virus engine to filter email; the feature is divided as Setting and Mail Notice. 6.1.1 Setting Definition Mail Scanned Settings: To define spam and virus mail size as the standard, if virus mail size exceeds the definition, the mail will not be scanned.
Page 90 A mail notice with the customized subject and message: (Figure 6-2) Figure 6-2 A Mail Notice with Customized Subject and Message Unscanned e-mails will be marked as “---Unscanned---” in front of the subject. (Figure 6-3) Figure 6-3 An E-Mail Marked as “Unscanned”...
Page 91: Mail Notice
6.1.2 Mail Notice Mail Notice feature is not just to inform the mail report, administrator can also retrieve the mail from Mail Notice. The example will show you the procedure and demonstrate how to retrieve the mail. In the path of Mail Security Mail Notice, there you can select notice accounts: Step1.
Page 92 Enable Add Notice Account Automatically Click OK When a new account is created on ES-6000, this account will be automatically created in Selected Accounts and receiving mail notice periodically. (Figure 6-5) Figure 6-5 Mail notice settings 1. When inbound or outbound mails are inspected as spam or virus mails, and those mails happen to be the mails of Selected Account, system will send mail notice to those accounts.
Page 93 When receiving mail notice, recipient can: Step3. Retrieve incoming mail by clicking Retrieve in the Inbound List. (Figure 6-6) After system resend mail, it shows completed. (Figure 6-7) Resend outgoing mail by clicking Resend in the Outbound List. (Figure 6-8) After system resend mail, it shows completed.
Page 94 Figure 6-8 Check mails to resend Figure 6-9 Resend completed To retrieve or resend mails that inspected as spam or virus mail: Method 1: Open the attachment (Spam_Notice.html or Virus_Notice.html) of mail notice. (Figure 6-10) Check Open it and click OK in the Open Attachment Warning window. (Figure 6-11) Check the box next to Sender under the Retrieve button, and click Retrieve to retrieve all mails.
Page 95 To modify Java Script feature setting in Outlook Express, please go to Tools Options Virus Protection, check Internet Zone. After doing so, user will be able to Security check all boxes at once by checking the box next to the Sender under the Retrieve or Resend button Figure 6-10 Open the attachment of notice mail Figure 6-11 Confirm to open attachment...
Page 96 Figure 6-12 Check all mails to retrieve Figure 6-13 Check all mails to resend...
Page 97 Figure 6-14 Check all mails to retrieve in a HTML Mail Notice Figure 6-15 Check all mails to resend in a HTML Mail Notice...
Page 98: Anti-Spam
6.2 Anti-Spam ES-6000 can filter every incoming and outgoing e-mail. Users will no longer receive plenty of spam which saves your precious time for work rather than waste your time on taking the business e-mails out of spam. It also lowers the risk of deleting the business e-mails when deleting spam.
Page 99 Inspection Direction Action to inbound spam e-mails can be deleted, or delivered, or quarantined. Action to outbound spam e-mails can be deleted, or delivered, or quarantined. Refer to the steps below to make settings: Under Inspection Direction bar, tick both Action of Inbound Spam Mail and Action of Outbound Spam Mail, then tick Deliver to the recipient for both.
Page 100 The figure below shows a normal e-mail merely has a score tag (optional) in the subject. (Figure 6-18) Figure 6-18 Normal E-Mail with a Score Tag in the Subject...
Page 101: Personal Rule
6.2.2 Personal Rule The Mail server administrator can help user to search the target mail, and verify if the target mail was delivered successfully or not. It can also retrieve mail from quarantine. For the further feature of personal rule, administrator can manage user’s personal whitelist or blacklist as well. (Figure 6-19) Figure 6-19 Personal Rule Definition:...
Page 102: Global Rule
6.2.3 Global Rule Global rule works to identify mail rule to filter all incoming or outgoing mails, once the mail matches the rule, it will be processed based on configuration. (Figure 6-20) Figure 6-20 Global Rule Definition: Rule Name The name of the custom spam mail determination rule Comment To explain the meaning of the custom rule Combination...
Page 103 You can choose Store in quarantine, Delete spam mail, Deliver to the recipient, or Same as Spam Setting to process the spam mail. Item To judge if it is spam mail according to the Header, Body, Size or else content of the mail. The item includes Received, Envelope-To, From, To, Cc, Bcc, Subject, Sender, Reply-To, Errors-To, Message-ID,...
Page 104: Whitelist
6.2.4 Whitelist When the mail matches ES-6000 Whitelist, it will forward to recipient directly without passing the examination of Anti-Spam. (Figure 6-21) Figure 6-21 Whitelist Definition: Mail Account Used as a reference for inspecting ham e-mails. Direction From: Inspects e-mails sent from a specific sender address...
Page 105: Blacklist
6.2.5 Blacklist When the mail matches ES-6000 Blacklist, it will be defined as spam mail and be arranged based on Spam Setting. (Figure 6-22) Figure 6-22 Blacklist Definition: Mail Account Used as a reference for inspecting ham e-mails. Direction From: Inspects e-mails sent from a specific sender address...
Page 106: Auto-Whitelist
6.2.6 Auto-Whitelist Definition: Auto-Whitelist Factor Obtained by dividing the Total Score (the amount of spam emails sent) by Count (the amount of emails sent). It directly affects the Mean Score and also is the major factor that decides whether an email is to be identified as spam. Source IP The subnet belonging to the sender(s) of email Count...
Page 107: Training
Ham e-mails can be imported onto the device for training to lift up the inspection accuracy. Account for Training Spam and ham will be sent to the assigned e-mail accounts respectively and retrieved by ES-6000 periodically for training so as to raise the inspection accuracy Training Time ES-6000 can be scheduled a daily time for spam or ham training.
Page 108: Anti-Spam Configuration Example
6.3 Anti-Spam Configuration Example Here are four application examples of Anti-Spam 1. Using Whitelist and Blacklist to Filter E-Mails 2. Using Global Rule to Filter E-Mails 3. Raising Bayesian Filtering Accuracy by Spam or Ham Training ( Outlook Express) 4. Raising Bayesian Filtering Accuracy by Account Training 6.3.1 Using Whitelist and Blacklist to Filter E-Mails Select Mail Security Setting, and then set as below: (Figure 6-24)
Page 109 Select “To” for Direction Click OK (Figure 6-26) Click New Entry again Type an e-mail address in the Mail Account field. For example, josh@airlive.com Select “From” for Direction Click OK (Figure 6-27) Click New Entry again Type an e-mail address in the Mail Account field. For example, josh@airlive.com...
Page 110 Figure 6-28 Fourth Entry of Whitelist Figure 6-29 Setup Completed Whitelist can be exported as a file for archive and editing purpose, which can be used for restoring the list later on. Ham training takes place on the scheduled time which is configured at Training time. Select Mail Security Blacklist, and then set as below: Step3.
Page 111 Ryan will be rated as spam and quarantined. When an internal account from airlive.com sends an e-mail to both jacky@hotmail.com and Step5. portia@hotmail.com: If the sender’s address is josh@airlive.com, then both of them will be receiving the e-mail from Josh.
Page 112: Using Global Rule To Filter E-Mails
But if the sender is someone other than Josh, for instance vera@airlive.com, then only Jacky will receive the e-mail from Vera. E-mails that sent to Portia will be rated as spam and quarantined.. 6.3.2 Using Global Rule to Filter E-Mails...
Page 113 Click Next. In the second row, select “To” for Item, “Contains” for Condition and then type “jacky” as Pattern. Click Next. In the third row, select “From” for Item, “Contains” for Condition and then type “Josh” as Pattern. Click Next. In the fourth row, select “To”...
Page 114 Click Next. In the second row, select “To” for Item, “Contains” for Condition, and then type “hotmail” as Pattern. (Figure 6-36) Click OK. (Figure 6-37) Figure 6-36 Second Global Rule Completed Figure 6-37 Second Global Rule Completed The Action of a spam e-mail can be deleted, or forwarded, or quarantined, or delivered, or using the same setting of spam when Classification set as “Spam”.
Page 115 Step5. prtia@hotmail.com: If the sender’s address is josh@airlive.com, then both of them will be receiving mail from Josh. But if the sender’s address is someone else than Josh, for instance vera@airlive.com, then only Jacky will receive the e-mail from Vera. E-mails that sent to Portia will be rated as...
Page 116: Raising Bayesian Filtering Accuracy By Spam Or Ham Training (Outlook Express )
6.3.3 Raising Bayesian Filtering Accuracy by Spam or Ham Training (Outlook Express ) Training to Filter Spam E-Mails Create a new folder named “Spam Mail” in Outlook Express. Step1. Right-click Local Folders and move to New folder, then click it. (Figure 6-39) In the Create Folder window, type “Spam Mail”...
Page 117 Figure 6-40 Specifying the Folder Name Move spam e-mails from inbox to “Spam Mail” folder: Step2. In inbox, select all spam e-mails and right-click them. Next, move to Move to folder on the pop-up menu, and then to click it. (Figure 6-41) In the Move window, select “Spam Mail”...
Page 118 Figure 6-42 Moving Spam E-Mails to “Spam Mail” Folder Compress “Spam Mail” folder in order to upload to ES-6000 for training: Step3. Click “Spam Mail” folder. On the Menu Bar, go to File Compact (Figure 6-43) Folder Figure 6-43 Compressing “Spam Mail” Folder...
Page 119 Copy the storage path of “Spam Mail” folder: Step4. Right-click the “Spam Mail” folder and move to Properties on the pop-up menu, then click it. (Figure 6-44) In the Spam Mail Properties window, copy the storage path. (Figure 6-45) Figure 6-44 Right-Clicking “Spam Mail” Folder and Moving to Properties Figure 6-45 Copying the Storage Path...
Page 120 Paste the storage path of “Spam Mail” folder in the Import Spam Mail from Client field. Click OK to start importing. ES-6000 will start training on scheduled time. (Figure 6-46) Figure 6-46 Pasting the Storage Path of Compressed Spam E-Mails The file for training can be any database file.
Page 121 Training to Filter Ham E-Mails Create a new folder named “Ham Mail” in Outlook Express. Step1. Right-click Local Folders and move to New folder, then click it. (Figure 6-47) In the Creat Folder window, type “Ham Mail” as Folder name, then click OK. (Figure 6-48) Figure 6-47 Creating a New Folder...
Page 122 Figure 6-48 Specifying the Folder Name Move ham e-mails from inbox to “Ham Mail” folder: Step2. In inbox, select all ham e-mails and right-click them. Next, move to Move to folder on the pop-up menu, and then to click it. (Figure 6-49) In the Move window, select “Ham Mail”...
Page 123 Figure 6-50 Moving Ham E-Mails to “Ham Mail” Folder Compress “Ham Mail” folder in order to upload to ES-6000 for training: Step3. Click “Ham Mail” folder. On the Menu Bar, go to File Compact (Figure 6-51) Folder Figure 6-51 Compressing “Ham Mail” Folder...
Page 124 Copy the storage path of “Ham Mail” folder: Step4. Right-click the “Ham Mail” folder and move to Properties on the pop-up menu, then click it. (Figure 6-52) In the Ham Mail Properties window, copy the storage path. (Figure 6-53) Figure 6-52 Right-Clicking “Ham Mail” Folder and Moving to Properties Figure 6-53 Copying the Storage Path...
Page 125 Paste the storage path of “Ham Mail” folder in the Import Ham Mail from Client field. Click OK to start importing. ES-6000 will start training on scheduled time. (Figure 6-54) Figure 6-54 Pasting the Storage Path of Compressed Ham E-Mails Since current Ham e-mails have been compressed and uploaded to ES-6000, e-mails in this Step6.
Page 126: Raising Bayesian Filtering Accuracy By Account Training
Select all spam e-mails and right-click them, then move to Forward as attachment and click it. (Figure 6-56) In the New Message window, type spam@airlive.com in the To field, Spam in the Subject field and leave Body blank, and then click Send. (Figure 6-57)
Page 127 Figure 6-56 Selecting Spam E-Mails Figure 6-57 Forwarding Spam E-Mails as Attachment...
Page 128 Select all ham e-mails and right-click them, then move to Forward as attachment and click it. (Figure 6-58) In the New Message window, type ham@airlive.com in the To field, Ham in the Subject field and leave Body blank, and then click Send. (Figure 6-59)
Page 129 Figure 6-59 Forwarding Ham E-Mails as Attachment Multi-functional firewall will retrieve e-mails from spam or ham account periodically and train Step6. itself on scheduled time. (Figure 6-60) Figure 6-60 Configuring to Train Itself on Scheduled Time...
Page 130: Anti-Virus
Clam ─ a default and free for charge virus scan engine. Sophos - The purchase of end-user license is required for legal use. To assure ES-6000 a successful update, use Test to check if the connection to the virus pattern server works or not before running update.
Page 131 Figure 6-61 Anti-Virus settings Whoever receives a virus mail detected by ES-6000 will see a warning tag, such as ---virus---, in the subject line. (Figure 6-62) Figure 6-62 A mail scanned as virus mail Available virus-scanning modes for users are Clam, Sophos, and Clam+Sophos.
Page 132: Anti-Virus Configuration Example
A hotmail mail account, portia@hotmail.com, sends a clean mail, and then ryan@airlive.com would receive it. If an internal mail account, for example josh@airlive.com, sends a mail to external accounts, Step3. such as hotmail: The mail sent to jacky@hotmail.com...
Page 133: Mail Report
6.5 Mail Report ES-6000 provides enterprise mail report in statistics and log. With the help of them, enterprise could have a clear view of mail activities. 6.5.1 Setting Periodic Report ■ It can generate and send the periodical report to recipient according to the time setting.
Page 134 Figure 6-65 Receive the periodic report...
Page 135 Figure 6-66 The first page in periodic report...
Page 136 Figure 6-67 The second page in periodic report...
Page 137 Figure 6-68 The third page in periodic report...
Page 138 Figure 6-69 The fourth page in periodic report...
Page 139 Figure 6-70 The history report setting Figure 6-71 Receive the history report...
Page 140 Figure 6-72 The first page in history report...
Page 141 Figure 6-73 The second page in history report...
Page 142 Figure 6-74 The third page in history report...
Page 143 Figure 6-75 The fourth page in history report The recipient will be receiving the mail report with an attachment in PDF format.
Page 144: Statistics
6.5.2 Statistics In the path of Mail Security Statistics, there it shows a full-scale statistics Step1. Mail Report report of scanned result. In Statistics, on the upper left corner, click Day for daily statistics report; click Week for weekly Step2. statistics report;...
Page 145: Log
6.5.3 Log User can use date, sender, sender IP address, recipient, subject, attribute, action, and attachment as keyword to search matched records stored in ES-6000. To use this feature, please follow the steps below : 1. Enable searching duration and assign a period of time.
Page 146 Figure 6-78 Downloading the Search Results as a “.txt” File Figure 6-79 Exporting the Search Results as a “.mbx” File...
Page 147 How to open “.mbx” file on your local computer: 1. Convert the “.mbx” file into a “.eml” file with a mbx2eml application (e.g., IMAPSize) and then run Outlook Express to open the “.eml” file. Run IMAPSize, Select Tools mbox2eml on the menu bar, and then click it. (Figure 6-80) In the mbox2eml window, click “Select mbox files to convert”...
Page 148 Figure 6-81 Specifying the “.mbx” File to be Converted Figure 6-82 Converting the “.mbx” File into a “.eml” File...
Page 149 Figure 6-83 File Conversion Completed Figure 6-84 Clicking and Dragging the “.eml” File into Outlook Express to Open It...
Page 150 The mail stored at quarantine can be retrieved and delivered to recipient. In the path of Mail Security Log, there it shows actions of mails. Step1. Mail Report (Figure 6-85) Figure 6-85 Scanned mail log In Log, quarantined spam and virus mails can be retrieved by assigned recipient or viewed its content simply by clicking its subject.
Page 151 Figure 6-87 View a quarantined virus mail Log icon descriptions: 1. Attribute: Icon Definition Allowed Spam Virus Unscan Invalid Recipient 2. Action: Icon Definition Delete Deliver Store Retrieve 3. Attached File:...
Page 152: Chapter 7 Mail Archie / Audit
ES-6000 can audit and archive the e-mails individually while processing the e-mails. In this chapter, it will be discussing the functionality and application of Mail Archive / Audit. 7.1 Setting Definition: Mail Archive / Audit Storage Setting E-mails to be archived or audited can be assigned a storage time and deleted when expired.
Page 153: Audit
7.2 Audit Definition: Rule Name The name for an audit rule Comments The description of an audit rule Combination And: Only when an e-mail meets all criteria is it to be audited Or: Only when an e-mail meets merely one criterion is it to be audited Action E-mails can be deleted, delayed, passed, inspected, or copied.
Page 154: Archive
7.3 Archive Search Available search criteria are date, recipient, sender, subject, action, attached, and non-attached. User can refer to the following steps to configure settings: 1. Type the complete e-mail address or a word from the e-mail address in the Recipient field. 2.
Page 155: Mail Archive / Audit Configuration Example
7.4 Mail Archive / Audit Configuration Example Auditing E-Mails Processed by ES-6000 Select Mail Archive / Audit Setting, and then set as below: (Figure 7-4) Step1. Figure 7-4 Mail Archive / Audit Settings E-mail that meets Audit criteria will be processed based on the Action of an Audit rule.
Page 156 Figure 7-5 First Audit Rule Figure 7-6 First Audit Rule Completed Select Mail Archive / Audit Audit, and then set as below: Step3. Click New Entry. Type “Mail_Deletion” in the Rule Name field. Type “Delete Mail” in the Comments field. Tick Archive Mail.
Page 157 Figure 7-8 Second Audit Rule Completed Actions to e-mails can be Delete, or Inspect, or Delay, or Pass or Copy to. When an e-mail has been scanned for virus and inspected for spam, it will be then audited and processed according to the Action. Right-click any e-mail in your Outlook Express, and then click Properties on the pop-up menu.
Page 158 When external user using hotmail account send e-mail both Step4. josh@airlive15.dyndns.org and portia@airlive15.dyndns.org: If the sender’s address is jacky_airlive@hotmail.com, both of them will receive it. If the sender’s address is sebastienko@hotmail.com, then only josh@airlive15.dyndns.org will receive the e-mail. E-mails that sent to portia@airlive15.dyndns.org will be deleted.
Page 159 Figure 7-12 Confirming to Resend the E-Mails Figure 7-13 Confirming to Remove the E-Mails When an internal user from airlive15.dyndns.org mail domain sends an e-mail to both Step5. airlive_jacky@hotmail.com and sebastienko@hotmail.com: If the sender’s address is josh@airlive15.dyndns.org, then both of them will receive it. If the sender’s address is portia@airlive15.dyndns.org, then airlive_jacky@hotmail.com will receive the e-mail only.
Page 160 Figure 7-14 The Archive Report Figure 7-15 Confirming to Retrieve the E-Mails Figure 7-16 Confirming to Resend the E-Mails...
Page 161 Figure 7-17 Confirming to Remove the E-Mails The icons and descriptions of Archive: Icon Deleted Inspect Delayed Archived Copied Passed Description...
Page 162: Chapter 8 Push Mail
ES-6000 features automatic e-mail transfer functionality. Whenever it receives an e-mail, it will instantly and actively transfer (push) the e-mail to user’s mobile phone. With the help of Push Mail, users may have e-mail access anytime anywhere without any complex login process.
Page 163 “Contains” for Condition and then type “Josh” as Pattern, it is to inspect the e-mail of which e-mail address contains the keyword “Jacky”. ES-6000 can instantly and actively transfer (push) e-mails to users’ mobile devices according to the availability of Internet access and the support in Push-IMAP protocol (also known as IMAP IDLE...
Page 164: Push Rule Configuration
Push e-mails will be cleaned up once the total e-mail size has exceeded the storage quota allocated for push e-mail. Nevertheless, despite the deletion of all push e-mails, the original copies remain available in each account’s inbox on ES-6000 device. Users may retrieve them by using e-mail application, such as Outlook Express.
Page 165 Under Push Mail Push Rule, set as below: Step2. Click ALL next to Classification to show all accounts. In the Enabled Account table, tick unwanted account(s) and remove it to Disabled Account table by clicking to Disabled Account in the upper right corner of the table. (Figure 8-2, 8-3, 8-4) In the Enabled Account table, apply the default rule to the selected account(s) by selecting to Push Mail from the pull-down menu and clicking OK next to it.
Page 166 Figure 8-4 Disabling Push Mail by Moving to Disabled Account List Figure 8-5 Applying Default Rule to the Selected Accounts Figure 8-6 Confirming to Apply Default Rule to the Selected Accounts...
Page 167 Under Push Mail Push Rule, set as below: Step3. In the Enabled Account table, click the desirable account to set up the user-defined rule. (Figure 8-7 Click New Entry. Type “Not Push” in the Rule Name field. Type “Not Push Mail” in the Comments field. Select “Or”...
Page 168 Figure 8-9 User-Defined Rule Created Whether an e-mail, which has been scanned for virus and inspected for spam, will be pushed to the user’s mobile device depends on individual user-defined rule. Right-click any e-mail in your Outlook Express, and then click Properties on the pop-up menu. After that, click Details tab for information on e-mail header of which can be used as reference while configuring the Item and Condition of a User-defined Rule.
Page 169 Given that ES-6000 receives e-mails dedicated to an internal account, such as Step4. jacky@airlive15.dyndns.org, then: (Based on STEP 3, e-mails from hotmail will not be pushed.) Log onto the Internet through a mobile device. Use IMAP4 protocol to retrieve e-mails dedicated to jacky@airlive15.dyndns.org.
Page 170 Figure 8-13 An E-Mails Shown on a Smartphone Figure 8-14 Reading an E-Mail...
Page 171 The icons and descriptions of Push Mail: User / Connection Status: Icon Off-line On-line Off-line, Push Mail not supported On-line, Push Mail supported Description To enable push e-mail, configure both the device and your mobile device. Follow the steps below and it will help you with the setting of push e-mail on your mobile phone: 1.
Page 172: Push Mail Example
Connection settings Outgoing e-mail to fill in user name and password. (Figure 8-30, Figure 8-31) Start the connection to receive mail from ES-6000. (Figure 8-32, Figure 8-33) Figure 8-15 Select Messag. on Menu Figure 8-16 Press Options Figure 8-17 Select Settings...
Page 173 Figure 8-18 Select Email Figure 8-19 Create new mail box Figure 8-20 Wizard Figure 8-21 Select IMAP4 protocol Figure 8-22 Enter Mail address Figure 8-23 Incoming Mail Server Figure 8-24 Outgoing Mail Server Figure 8-25 Define Mailbox Figure 8-26 Edit else setting...
Page 174 Figure 8-27 Edit Connection setting Figure 8-28 Enter Incoming setting Figure 8-29 Edit Incoming setting Figure 8-30 Enter Outgoing setting Figure 8-31 Edit Outgoing setting Figure 8-32 Connect to Mail server Figure 8-33 Receive and read mail...
Page 175: Chapter 9 Remote Backup
The archived E-mails can be periodically (according to the time setting) transferred to the assigned location to solve the storage space limit and audit time limitation. 9.1 Backup Setting Definitions: Connection Status of Remote Hard Disk. The remote hard disk status has the information of connection status, disk space for backup, and hard disk utilization.
Page 176: Browse Mail
Available search criteria are date, sender, recipient, subject, content, action, attached, and non-attached. Set as below : Recipient, enter the keywords or phrases. ( For example, Jacky, jacky@airlive.com) Enable to select the date setting. Action, select All. Attached File, select all.
Page 177: Mail Backup Example
It is easy to create remote backup server. Just to share a folder of internal PC with read/write access right, and define a specific user name and password for the access right. If the folder can be found in My Network Places, it can also be the remote backup server to store ES-6000 mails record.
Page 178 Check up the backup path and available disk capacity. (Figure 9-3) Step2. Figure 9-3 Check up the available disk capacity for backup The archived E-mails of a specific duration can be exported. (Figure 9-4)
Page 179 Figure 9-4 The setting of backup immediately...
Page 180 In Remote Backup Browse Setting, set as below. (Figure 9-5) Step3. Figure 9-5 The browse setting Check up the connection status. (Figure 9-6) Step4. Figure 9-6 Check up the connection status When the mails are archived, they will be transferred to a NAS or file server according the Step5.
Page 181 Figure 9-7 Browsing the remote backup e-mails Figure 9-8 The retrieve window Figure 9-9 Confirm to delete backup E-mails...
Page 182: Chapter 10 Ha
ES-6000 features High Availability function. While there are two ES-6000 devices available onsite, High Availability enables them not only to synchronize to each other but also to substitute for the malfunction one in just no time. It ensures the enterprise an always connecting Internet access.
Page 183 Change Management IP of Master ES-6000 to differ with default IP 192.168.2.1, ex. 192.168.2.2. Step5 (Figure 10-3) Make sure the Master ES-6000 and Backup ES-6000 port 1 and port 2 are connected properly. Step6 Power on the Backup ES-6000, then both ES-6000 will synchronize data and setting.
Page 184 Figure 10-2 Change interface IP of Master ES-6000 Figure 10-3 Change Management IP of Master ES-6000 Figure 10-4 Under the process to synchronize both ES-6000’s data...
Page 185 Figure 10-5 Under the process to synchronize both ES-6000’s data Figure 10-6 Complete High Availability function After the completion of deployment, the two devices will immediately start synchronizing the system settings. If the process is interrupted by certain reason, then the Backup device has to be removed from the deployment.
Page 186 Notes: 1. After the deployment finished, the Backup device will substitute for Master device once it breaks down. (The two devices detect each other for status through Port1 and Port 2 connection.) 2. When there is any data or firmware version variation between the two devices, the synchronization will immediately function through the Port 2.
Page 187: Chapter 11 Dns Setting
Generally speaking, DNS server is either set up by an IT company or set up by oneself. ES-6000 has the function of resolving domain name which enables user to set up a DNS server on user’s own without any expanded cost. While setting up DNS, please direct the registered domain name to the ES-6000’s IP address beforehand.
Page 188: A (Address)
Host Name: dns1.airlive.com IP Address: 61 .11 .11 .11 Set up secondary host name server as: Host Name: dns2.airlive.com IP Address: 211 .22 .2 2 .22 Select Type It is divided into three types, namely Address (A), Canonical NAME (CNAME) and Mail eXchanger (MX).
Page 189: Cname (Canonical Name)
Table 11-2 Mapping table of domain name and CNAME Figure 11-3 Mapping table of Domain name and CNAME The table above indicates that host5.airlive.com (Alias) is mapping to host23.airlive.com (domain name). Thus, pinging host5.airlive.com under DOS mode will have the result of 61.11.11.14.
Page 190: Mx (Exchanger)
3. “mail.airlive.com” is the inquired DNS name. For example, the customer service department of Test company wants to email to mary@mail.airlive.com, a mail server (test.com.tw) served as a SMTP server decides where and how to send the mail by inquiring the target DNS server.
Page 191 Therefore, mail will go to host3.airlive.com according to SMTP Protocol. Name: Customize a DNS host name. Reverse: reverse a domain name lookup of its IP address. Domain mapping distinguish into forward mapping and reverse mapping. Forward mapping served as a translator, a translator transforms a letter-pattern address into a figure-pattern address.
Page 192: Spf (Sender Policy Framework)
When this spam e-mail is sent to an account with SPF enabled, the account will ask AirLive mail server for the SPF record based on the e-mail’s IP address to check if the IP really came from AirLive.
Page 193: Example
Internet users. 11.6.1 Setup a host name server Procedure: 1. Register airlive.com as domain name. 2. Set primary host name server as 61.11.11.11 and domain name as dns1.airlive.com Set secondary host name server as 211 .22 .2 2 .22 and domain name as dns2.airlive.com...
Page 194 Address: 61.11.11.11, 211.22.22.22------->examine IP for correctness (forward mapping) C: \>nslookup 61.11.11.11 Server: dns.hinet.net Address: 168.95.1.1 Name: airlive.com ----------------->examine domain name for correctness (reverse mapping) Address: 61.11.11.11 Secondary DNS can act as substitute while primary DNS is down, it keeps domain name available for use.
Page 195 Address: 168.95.1.1 > server 61.11.11.11 ---------------------------------------------->switch to your DNS server Default Server: web.airlive.com Address: 61.11.11.11 > www.airlive.com ---------->lookup for real domain name (forward mapping) Server: web.airlive.com Address: 61.11.11.11 Name: web.airlive.com -----------------------------------> domain name of www.airlive.com Address: 61.11.11.11, 211.22.22.22 ------------------------>mapping IP of web.airlive.com...
Page 196 Table 11-7 MX record of mail.airlive.com For figure 1 has the highest priority, server will try to deliver the mail to smtp1.airlive.com due to its first priority. If delivery failed, then the mail goes to smtp2.airlive.com the secondary priority.
Page 197: Mapping Between Servers (Web / Ftp / Mail) And Domain Name
Go to DNS Setting Setting, click New Entry. Step2. Fill in the blank field with registered domain name airlive.com, then click OK and check Enable Step3. DNS Zone, finally click New Entry. (Figure 11-8) Figure 11-8 Add a domain name...
Page 198 In DNS Zone Configuration, add the second entry : Step5. Select type : A Address Name : airlive.com. (Be aware there is a dot sign “.” behind the domain name.) Address : 211.22.22.22 Click OK. (Figure 11-10) Secondary DNS mapping setup completed.
Page 199 In DNS Zone Configuration, add the third entry : Step6. Select type : A Address Name : www Address : 61.11.11.12 Click OK. (Figure 11-11) Mapping record between web server and IP setup completed. Figure 11-11 apping record between web server and IP setup In DNS Zone Configuration, add the forth entry : Step7.
Page 200 In DNS Zone Configuration, add the fifth entry : Step8. Select type : MX mail eXchanger Name : mail Mail server : airlive.com Click OK. (Figure 11-13) Mapping record between mail server and IP setup completed. Figure 11-13 Mapping record between mail server and IP setup Setup completed.
Page 201: Chapter 12 Web Server Setting
The key to a thriving business is to provide your potential customers with a stable, reliable access to your company website. Accordingly, ES-6000 makes website building cost effective and expeditious for you by integrating the web server. It meets your demand on building up a company website.
Page 202: Example
12.2 Example Using ES-6000 to Provide Web Service Setting: Create DNS entry to define web server address. (Figure 12-2) Step1. DNS Setting Figure 12-2 The DNS configuration for Web Server Select Web Server Setting Setting and then set as below: Step2.
Page 203 Select the ZIP file and then click Extract on the right. (Figure 12-8) Select the ZIP file and then click Remove on the right. (Figure 12-9) Click OK (Figure 12-10) Click OK in the dialogue box to confirm restarting the Web server. (Figure 12-11, 12-12) visit your website “http://www.airlive.com.tw:8889” “https://www.airlive.com.tw:3334”. (Figure 12-13)
Page 204 Figure 12-6 Opening the root directory Figure 12-7 Uploading Your Website onto the Web Server...
Page 205 Figure 12-8 Selecting the ZIP File to Extract Figure 12-9 Selecting the ZIP File to Remove...
Page 206 Figure 12-10 Website Uploaded Figure 12-11 Confirming to Restart the Web Server Figure 12-12 Web Server Restarted...
Page 207 Click OK in the dialogue box to confirm restarting the Web server. (Figure 12-19, 12-20) Now you may access the files stored on the Web server through the folder index at “http://www.airlive.com:8889/download/” or “https://www.airlive.com.tw:3334/download/” upon authentication. (Figure 12-21, 12-22, 12-23)
Page 208 Figure 12-14 Adding a New Folder Figure 12-15 The Related Settings of a Folder...
Page 209 Figure 12-16 Opening a Folder Figure 12-17 Uploading a File...
Page 210 Figure 12-18 File Uploaded Figure 12-19 Confirming to Restart the Web Server Figure 12-20 Web Server Restarted...
Page 211 Figure 12-21 The Authentication Dialogue Window Figure 12-22 Browsing for the Desirable File...
Page 212 Figure 12-23 Downloading the Desirable File...
Page 213: Chapter 13 Proxy Server Settings
The ES-6000 offers a new function to perform web proxy server, so the LAN client users can define ES-6000’s IP address and the port number in browser; the ES-6000 will receive webpage from Internet website and store the pages in ES-6000 hard disc.
Page 214: Chapter 14 Monitor
MIS engineer could view the system information and every event log in Monitor. 1. System Info indicates the utilization of CPU, Hard Disk, Memory, and Ram Disk. 2. Event Log records every activity in ES-6000, such as modify and remove setting. 14.1 System Info...
Page 215 Figure 14-1 Display system info...
Page 216: Event Log
14.2 Event Log In the path of Monitor Event Log, it shows records of every activity in ES-6000, such as Step1. modify and remove setting. (Figure 14-2) Click to search event log. (Figure 14-3) Click to view log detail. (Figure 14-4)
Page 217 Figure 14-3 Search results...
Page 218 Figure 14-4 Event log details...
Page 219: Chapter 15 Introduction Of Mail System
A mail server acts as an intermediate between the Internet and users when sending or receiving mails. The format of email address looks like account@server.name. Info on the left side of at sign (@) indicates an account name, the other side stands for the host name. For instance, you are sending a mail to josh@yahoo.com.tw, your email software will go to your DNS server for the IP address and mail exchanger record that corresponding to mail server.
Page 220 Take sending and receiving mail for example to illustrate the process of mail transmission. When user wants to send a mail: Send mails to MTA via MUA. While composing email with MUA, make sure to follow steps below : 1. Enter the sender email address and outgoing mail server (namely the sender MTA ) 2.
Page 221 Relay, a function that MTA transfers mails to another MTA, functions when MTA has learned that mail recipient does not exist on itself will transfer mails to another MTA. A mail server which could be used to transfer mails by anyone is called Open Relay. To avoid this, presently most of mail servers set Relay as disabled.
