OpenVox A2410P User Manual

Cost effective asterisk cards on trixbox2.8.0.3 modular analog telephony interface
Hide thumbs Also See for A2410P:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
深圳开源通信有限公司
OpenVox-Best Cost Effective Asterisk Cards
OpenVox A2410P/AE2410P on Trixbox2.8.0.3
User Manual
AE2410P
A2410P
Date:30/09/2010
Version: 1.1
1
OpenVox Communication Co. Limited.
URL:
www.openvox.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A2410P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for OpenVox A2410P

Summary of Contents for OpenVox A2410P

  • Page 1 User Manual 深圳开源通信有限公司 OpenVox-Best Cost Effective Asterisk Cards OpenVox A2410P/AE2410P on Trixbox2.8.0.3 User Manual AE2410P A2410P Date:30/09/2010 Version: 1.1 OpenVox Communication Co. Limited. URL: www.openvox.cn...
  • Page 2 Address: F/3, Block No.127, Jindi Industrial Zone, Shazui Road, Futian district, ShenZhen, Guangdong 518048, China Tel:+86-755-82535095,82535461,Fax:+86-755-82535174 E-Mail：sales@openvox.cn support@openvox.cn IM for Technical Support: support@openvox.cn James.zhu@openvox.cn Business Hours: 9:00AM-18:00PM from Monday-Friday URL：www.openvox.cn Thank You for Choosing OpenVox Products! OpenVox Communication Co. Limited. URL: www.openvox.cn...

  • Page 3: Table Of Contents

    User Manual Table of Contents 1. Overview ..............4 1.1 What is A2410P/AE2410P ..........4 1.2 What is Asterisk: ........... 5 2. Hardware Setting ............6 3. Software Installation and Configuration ........8 3.1 Download dahdi and driver ........8 3.2 Edit the configure file .........

  • Page 4: Overview

    1. Overview 1.1 What is A2410P/AE2410P A2410P is a modular analog telephony interface product. AE2410P is A2410P with EC module. It is designed to build IP PBX. A2410P/AE2410P must be used with FXO-400 or FXS-400 together to build a workable system.

  • Page 5: What Is Asterisk

    Asterisk provides Voicemail services with Directory, Call Conferencing, Interactive Voice Response, Call Queuing. It has support for three-way calling, caller ID services, ADSI, IAX, SIP, H.323 (as both client and gateway), MGCP (call manager only) and SCCP/Skinny(voip-info.org). OpenVox Communication Co. Limited. URL: www.openvox.cn...

  • Page 6: Hardware Setting

    2. Checking cabling/pin assignment: There are six modules on A2410P/AE2410P, each module (FXS400/FXO400) corresponds one RJ45 interface (refer figure 2). There are eight pins on each RJ45 interface. A2410P/AE2410P uses the two pins of it as a pair, connecting to two-wire telephone line, so each RJ45 interface can split into four telephone lines.
  • Page 7 3. Splitting the RJ45 to RJ11: User has to use a splitter (refer figure 4) to split RJ45 interface to four RJ11 normal telephone line. And please connect PSTN line into FXO port and telephone into FXS port. Figure 4: A2410P/AE2410P Splitter OpenVox Communication Co. Limited. URL: www.openvox.cn...

  • Page 8: Software Installation And Configuration

    3. Software Installation and Configuration 3.1 Download dahdi and driver #lspci –vvvvv 1) Checking the A2410P/AE2410P hardware by command: From the following, user can see that there is a device called communication controller interface be found. 01:02.0 Communication controller: Unknown device 1b74:2410 (rev 01)

  • Page 9: Edit The Configure File

    To compile this driver as a module, choose M here: the module will be called wct4xxp. If unsure, say Y. config DAHDI_OPVXA24XX tristate "OpenVox 24 ports analog card Support" depends on DAHDI && PCI default DAHDI ---help--- OpenVox Communication Co. Limited.
  • Page 10 4. Add opvxa24xx in /usr/src/dahdi-xx/tools/xpp/perl_modules/Dahdi/Hardware/PC I.pm # vi /usr/src/dahdi-xx/tools/xpp/perl_modules/Dahdi/Hardware/PCI.pm # from opvxa24xx '1b74:2410' => { DRIVER => 'opvxa24xx', DESCRIPTION => 'OpenVox A2410P' }, # from wctdm24xxp 'd161:2400' => { DRIVER => 'wctdm24xxp', DESCRIPTION => 'Wildcard TDM2400P' }, 'd161:0800' => { DRIVER => 'wctdm24xxp', DESCRIPTION => 'Wildcard TDM800P' }, 5.

  • Page 11: Installation

    Then run If user uses AE2410P, from the following, user can find EC module has been detected. OpenVox A2410P version: 1.0 Module 0: Installed -- AUTO FXO (FCC mode) Module 1: Installed -- AUTO FXO (FCC mode) Module 2: Installed -- AUTO FXO (FCC mode)
  • Page 12 OpenVox VPM: echo cancellation supports 32 channels OpenVox VPM: echo cancellation for 32 channels OpenVox VPM: hardware DTMF disabled. OpenVox VPM: Present and operational servicing 1 span(s) Found an OpenVox A2410P: Version 1.0 (24 modules) 2. Checking the configure files dahdi_genconf The command will automatically generate the system.conf under...
  • Page 13 ; This is not intended to be a complete chan_dahdi.conf. Rather, it is intended ; to be #include-d by /etc/chan_dahdi.conf that will include the global settings ; Span 1: DAHDI_DUMMY/1 "DAHDI_DUMMY/1 (source: Linux26) 1" (MASTER) ; Span 2: OPVXA24XX/24 "OpenVox A2410 Board 25" ;;; line="1 OPVXA24XX/24/0" signalling=fxs_ks...
  • Page 14 *CLI> dahdi show channels Chan Extension Context Language MOH Interpret Blocked State pseudo default default In Service from-pstn default In Service from-pstn default In Service from-pstn default In Service OpenVox Communication Co. Limited. URL: www.openvox.cn...
  • Page 15 Dialing: noI> Context: from-internal Caller ID: 111 Calling TON: 0 Caller ID name: device Mailbox: 111@device Destroy: 0LI> InAlarm: 0LI> Signalling Type: FXO Kewlstart Radio: 0*CLI> Owner: DAHDI/13-1 Real: DAHDI/13-1 Callwait: <None> Threeway: <None> OpenVox Communication Co. Limited. URL: www.openvox.cn...
  • Page 16 Relax DTMF: no Dialing/CallwaitCAS: 0/0 Default law: ulaw Fax Handled: no Pulse phone: no DND: no1*CLI> Echo Cancellation: trixbox1128 taps trixbox1(unless TDM bridged) currently ON Actual Confinfo: Num/0, Mode/0x0000 Actual Confmute: No Hookstate (FXS only): Offhook OpenVox Communication Co. Limited. URL: www.openvox.cn...

  • Page 17: Configure On Trixbox Webpage

    Add two extensions, then user can plug two phones to FXS, after that the two phones can call each other. 1) Click PBXPBX Settings button in the following illustration: 2) Click on Extensions bar in the following illustration: OpenVox Communication Co. Limited. URL: www.openvox.cn...
  • Page 18 Please refer to the following illustration: 3) Set up User Extension: 111 (that’s the extension number I gave for reception); Display Name: 111 in the following illustration: OpenVox Communication Co. Limited. URL: www.openvox.cn...
  • Page 19 And click the “Continue with reload” in the popup dialog box. 7) If you use AE2410P,please refer to the following steps,otherwise jump to 8). a. Click on 111<111> button on the up right corner of the page, please refer to the following illustration: OpenVox Communication Co. Limited. URL: www.openvox.cn...

  • Page 20: Add Incoming Route

    8) Please repeat the above steps to add another extension 222 on channel 6. After these, we can dial each other between 111 and 222. 4.3 Add Incoming Route Add an incoming route, it will help you get incoming calls. 1) Click on “Inbound Routes” bar. OpenVox Communication Co. Limited. URL: www.openvox.cn...
  • Page 21 Then click submit. Please refer to the following illustration: 4) Click the “Apply Configuration Changes ” bar in the top of the screen. And click the “Continue with reload” in the popup dialog box. OpenVox Communication Co. Limited. URL: www.openvox.cn...

  • Page 22: Create Trunk

    2) Click on Trunk ZAP/g0 button on the up right corner of the page, please refer to the following illustration: 3) Input trunk1 in the textbox of Outbound Caller ID, please refer to the following illustration: OpenVox Communication Co. Limited. URL: www.openvox.cn...

  • Page 23: Set Up Outbound Route

    Through outbound routes, user can dial out. 1) Please click on the Outbound Routes as the following illustration: 2) Please click “09_outside button”，keep the default parameters in the following screen. Please refer to the following illustration: OpenVox Communication Co. Limited. URL: www.openvox.cn...
  • Page 24 For example, if you want to call 123456, then you have to press 9123456 on your phone. 3) Click the “Apply Configuration Changes” bar in the top of the screen. And click the “Continue with reload” in the popup dialog box. OpenVox Communication Co. Limited. URL: www.openvox.cn...

  • Page 25: References

    User Manual Notes: Test environments are: Trixbox：2.8.0.3 Kernel version: 2.6.18-128.1.10.el5 Dahdi: dahdi-linux-complete-2.2.0.2+2.2.0 Asterisk: 1.6.0.10 Hardware: OpenVox A2410P/AE2410P 5．References www.openvox.cn www.digium.com www.asterisk.org www.voip-info.org www.asteriskguru.com OpenVox Communication Co. Limited. URL: www.openvox.cn...
