Giant GLORY DH Specifications

58 giantbicycle.com
Mountain
Competition
Specifications
SIZES XS,S,M,L
Team Blue/Black
COLORS
ALUXX SL-Grade Aluminum, 8.8"
FRAME
Maestro Suspension
FORK Fox 40 RC2, 203mm travel
SHOCK Fox DHX 5.0, coil
Race Face Diabolus DH, 31.8
HANDLEBAR
STEM Race Face Diabolus D2 DH
SEATPOST Race Face Evolve DH 300x30.9mm
WTB Devo Team
SADDLE
Not Included
PEDALS
SHIFTERS Shimano Saint Rapidfire, rear only
MRP G2 guide, Custom for Giant
FRONT DERAILLEUR
Shimano Saint, top normal
REAR DERAILLEUR
BRAKES Shimano Saint 203F/180R
BRAKE LEVERS Shimano Saint
Shimano Saint 11/28, 9-speed
CASSETTE
CHAIN Shimano HG-93
CRANKSET Shimano Saint, 38T
Shimano Saint, External
BOTTOM BRACKET
RIMS Mavic EX729
HUBS Shimano Saint, 32H
DT Competition, 14/15g
SPOKES
TIRES Michelin Hot S, 26x2.5
EXTRAS
Specifications and availability subject to change without notice.
Glory DH
Glory DH is one hundred-percent focused on the finish line. This is the best purebred gravity
racer available, designed to conquer everything and put you where you belong: on the podium.
It's victory on two wheels.
Frame Technology
The Glory DH's 8.8-inch Maestro Suspension is fully active over everything from stutters to less-than-
perfect landings, whether you're speed-checking or pedaling for all you're worth. It's the backup you
need when you're throwing everything you've got into beating the clock.
features
— Fox 40 RC2 203mm suspension fork, Fox DHX 5.0 coil rear shock
— New Shimano Saint group
— Race Face Diabolus DH handlebar and stem
— Mavic EX729 rim/new Shimano Saint hubs, wheelset
frame geometry
Actual
Part Number Head Angle Seat Angle*
Frame Size
degrees degrees
XS 348542 65.5 69.0
S 348543 65.5 69.0
M 348544 65.5 69.0
L 348545 65.5 69.0
*Seat angle is effective
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Toptube** Headtube Chainstay Wheelbase
inches inches inches inches
19.7 4.5 17.5 44.0
21.9 4.5 17.5 44.6
22.3 4.5 17.5 45.1
25.4 5.1 17.5 46.7
Standover
Height***
inches
34.4
34.0
33.7
33.2
