Summary of Contents for Electrolux ERB3502
- Page 1 F r i d g e -- F r e e z e r / K ü h l -- G e f r i e r k o m b i n a t i o n INSTRUCTION BOOK GEBRAUCHSANWEISUNG ERB3502 818 38 28--01/4...
-
Page 2: Table Of Contents
Safety instructions Your new fridge/freezer may have other functions compared to your previous one. Carefully read these instructions to learn how the appliance works and how to care for it. Keep the instruction booklet. It will come in handy if you later sell the cabinet or give it to somebody else. These warnings are provided in the interests of your safety. -
Page 3: Description Of The Appliance
Description of the Appliance Model ERB3502 Glass shelf Bottle shelf Vegetable drawer Butter compartment Door shelf Egg tray Bottle shelf Freezing tray Freezer drawer Ventilation grille Control Panel -- 18 ACTION FREEZE ACTION COOL A. Refrigerator power switch G. Temperature display Switches the refrigerator on and off. -
Page 4: Before Use
Before use Position and clean the cabinet as explained in the section "Installation". Check that the drain hose at the rear of the cabinet discharges into the drip tray. Before inserting the power plug into the outlet and switching on the cabinet for the first time, leave it standing upright for about 4 hours. -
Page 5: Switching Off
Hints: · Distribute foodstuffs to allow cold air to circulate freely between the products. · Do not place food products directly against the cooling plate on the rear wall since they may freeze in this case. · Also never put warm products into the cabinet. Wait until they have cooled down. -
Page 6: Using The Freezer
The vegetable drawer has a removable ventilation edging to increase the circulation of air and reduce the risk of condensation. Using the freezer To start the freezer and set the correct temperature - 18 Switching on: Switch on the freezer by pressing the power switch. The alarm sounds if the temperature inside the freezer reaches room temperature. -
Page 7: Freezing
Temperature alarm If the temperature rises above -12°C, the red warning lamp flashes and an audible alarm sounds. The temperature display will then start to flash. To switch off the alarm: - 11 Press the alarm shut-off button to switch off the audible alarm. -
Page 8: Suitable Storage Periods
Practical advice on freezing · When freezing products, use the top shelf, and if necessary the shelf beneath as this is the coldest part. . - Place the foods directly on the freezer shelves. · Spread out the products as much as possible to allow air to circulate between them. -
Page 9: Hints And Tips
Hints and Tips Saving energy Make sure the door gasket is complete and · always clean. Pay careful attention to where the cabinet is · Food Storage placed. See the section "Installation". When installed correctly, the cabinet will consume less To obtain the best results from your appliance, ·... -
Page 10: Defrosting The Freezer
Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0,5 litre water) Rinse and dry thoroughly. Regularly check the door seals and wipe clean to ensure they are clean and free from debris. Vegetable drawer. Pull out drawer. -
Page 11: Defrosting The Fridge
Defrosting the fridge The fridge is defrosted automatically every time the compressor stops. Frost formation can be prevented · not putting warm foodstuff inside the cabinet. · avoiding frequently opening the door or keeping it open too long. · do not place foodstuffs directly against the cold cooling plate. - Page 12 There is water on the cooling plate inside This is normal. During automatic defrosting, frost thaws on the the refrigerator. cooling plate. Water is running inside the refrigerator. Clean the water drain and drain hole inside the refrigerator using e.g. cotton swabs or a bottle cleaner brush. Some food products could have been placed near the rear of the appliance prevetung the water from running into the drain.
-
Page 13: Customer Care Department
Service and Spare Parts SER:NO (serial number):........In the event of your appliance requiring service, or if you wish to purchase spare parts please contact Purchase date............Technical specification Model ERB3502 Volume Refrigerator 216 l 87 l Freezer Width 595 mm... -
Page 14: Unpacking
Unpacking Unpack the cabinet and check that it is in good condition and free of any transport damage. Notify the dealer immediately of any damage. Hand the packaging over for recycling. For more information, contact your local city office or the dealer. Do not allow children to play with the packaging. - Page 15 Make sure that the power plug is not squashed or damaged by back of the product. A damaged power plug may overheat and cause a · fire. Do not place heavy articles or the product itself on the power cord. there is a risk of a short circuit and fire.
-
Page 16: Door Reversal
Door Reversal 1. Close the cabinet and remove the plug from the electrical socket. 2. Remove the ventilation grille. There is a part on the grille that can be removed. Remove and reposition it on the other side. 3. Put the cabinet on a wooden board when it is laid down. - Page 17 www.electrolux.com MARIESTAD DT-AV...
