2 electrolux Electrolux. Thinking of you. Share more of our thinking at www.electrolux.com Contents Safety information Care and cleaning Control panel What to do if… First use Technical data Daily use Installation Helpful hints and tips Environmental concerns Subject to change without notice Safety information In the interest of your safety and to ensure ing a spring lock (latch) on the door or lid,...
Page 3
electrolux 3 • It is dangerous to alter the specifications or cause it to explode, resulting in damage to modify this product in any way. Any dam- the appliance. age to the cord may cause a short-circuit, • Ice lollies can cause frost burns if con- fire and/or electric shock.
4 electrolux Service either its refrigerant circuit or insulation materials. The appliance shall not be dis- • Any electrical work required to do the serv- carded together with the urban refuse icing of the appliance should be carried out and rubbish. The insulation foam con- by a qualified electrician or competent per- tains flammable gases: the appliance son.
electrolux 5 Switching on Child Lock function Insert the plug into the power outlet. If the Shopping function display is not illuminated, press button (A), to start the appliance. Eco Mode function As soon as the appliance is turned on, the Action Freeze function temperature flashes and you will hear a buz- zer.
6 electrolux Ambient Temperature Function In this condition the chosen temperatures are automatically set (+ 5°C and - 18°C), in the The ambient temperature function is activa- best conditions for storing food. ted by pressing key (D) (several times if nec- It is possible to de-activate the function at essary) until the corresponding icon appears any time by changing the selected tempera-...
electrolux 7 Temperature alarm During the alarm phase, the buzzer can be switched off by pressing button (E). Temperature increase in the freezer com- partment (for example due to an power fail- Door open alarm ure or door is open) is indicated by: An acoustic alarm will sound if some of the •...
8 electrolux Important! If the ambient temperature is Small pieces may even be cooked still frozen, high or the appliance is fully loaded, and the directly from the freezer: in this case, cooking appliance is set to the lowest temperatures, will take longer.
Page 9
electrolux 9 Removal of freezing baskets from the freezer The freezing baskets have a limit stop to pre- vent their accidental removal or falling out. At the time of its removal from the freezer, pull the basket towards yourself and, upon reaching the end point, remove the basket by tilting its front upwards.
10 electrolux Helpful hints and tips Hints for energy saving If the temperature regulator is set to a cold temperature, the ambient temperature is • Do not open the door frequently or leave it high or if the fridge is fully loaded the com- open longer than absolutely necessary.
electrolux 11 • prepare food in small portions to enable it Hints for storage of frozen food to be rapidly and completely frozen and to To obtain the best performance from this ap- make it possible subsequently to thaw only pliance, you should: the quantity required;...
12 electrolux • remove any stored food, wrap it in several layers of newspaper and put it in a cool place • remove the freezer drawers • put insulating material around the drawers, e.g. blankets or newspapers. Defrosting can be accelerated by placing bowls with hot water (not boiling) inside the freezer.
electrolux 13 • leave the door/doors ajar to prevent un- If the cabinet will be kept on, ask somebody pleasant smells. to check it once in a while to prevent the food inside from spoiling in case of a power failure. What to do if…...
14 electrolux Problem Possible cause Solution The door is not closed correctly. Refer to "Closing the door". The door gasket is deformed or Refer to "Closing the door". dirty. The Temperature regulator may Set a higher temperature. be set incorrectly. The temperature in the The Temperature regulator may Set a higher temperature.
electrolux 15 Closing the door 1. Clean the door gaskets. 2. If necessary, adjust the door. Refer to "In- stallation". 3. If necessary, replace the defective door gaskets. Contact the Service Center. Technical data Dimension Height 2000 mm Width 595 mm Depth 623 mm Rising Time...
Page 16
16 electrolux Removing the shelf holders Electrical connection Your appliance is equipped with shelf retain- Before plugging in, ensure that the voltage ers that make it possible to secure the and frequency shown on the rating plate cor- shelves during transportation. respond to your domestic power supply.
electrolux 17 Levelling When placing the appliance ensure that it stands level. If necessary adjust the feet us- ing the adjustment spanner supplied. 6. Remove the cover on the front (d). Unscrew and move the door stopper (e) to the opposite side. Unscrew and move the hinge (f) to the opposite side.
18 electrolux 8. Disassemble the door closing devices (c1, c2) by unscrewing the screw (c3). Reverse the door closing device (c1, c2), 14. Raise the appliance and install the ven- move to the other side of the other door tilation grille. and fix by screwing in the screw (c3).
Page 19
electrolux 19 collection point for the recycling of electrical waste handling of this product. For more and electronic equipment. By ensuring this detailed information about recycling of this product is disposed of correctly, you will help product, please contact your local council, prevent potential negative consequences for your household waste disposal service or the the environment and human health, which...
