Fridge--Freezer / Réfrigérateur--Congélateur / Kühl--Gefrierkombination / Frigorifero--Congelatore /
Koel--Vriescombinatie / Køle--Fryseskab / Frigorifico--Congélador
GEBRAUCHSANWEISUNG
818 16 24--01/9
INSTRUCTION BOOK
ISTRUZIONI D'USO
NOTICE D'UTILISATION
GEBRUIKSAANWIJZING
BRUGSANVISNING
INSTRUÇÕNES DE USO
ER8197B, ER8492B, ER8497BX, ER8997B, ER9009B
GB
FR
DE
IT
NL
DK
DK
PO
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Electrolux ER8197B
Summary of Contents for Electrolux ER8197B
- Page 1 Fridge--Freezer / Réfrigérateur--Congélateur / Kühl--Gefrierkombination / Frigorifero--Congelatore / Koel--Vriescombinatie / Køle--Fryseskab / Frigorifico--Congélador INSTRUCTION BOOK GEBRAUCHSANWEISUNG ISTRUZIONI D’USO NOTICE D’UTILISATION GEBRUIKSAANWIJZING BRUGSANVISNING INSTRUÇÕNES DE USO ER8197B, ER8492B, ER8497BX, ER8997B, ER9009B 818 16 24--01/9...
-
Page 2: Table Of Contents
Safety instructions Your new fridge/freezer may have other functions compared to your previous one. Carefully read these instructions to learn how the appliance works and how to care for it. Keep the instruction booklet. It will come in handy if you later sell the cabinet or give it to somebody else. These warnings are provided in the interests of your safety. -
Page 3: Description Of The Appliance
Description of the Appliance Model ER8197B 1. Glass shelf 2. Bottle shelf 3. Vegetable drawer 4. Butter compartement 5. Door shelf 6. Egg holder 7. Bottle shelf 8. Freezing tray + accumulator 9. Freezer basket 10. Ventilation grille 11. Freezer calender Model 8497BX, ER8492B 1. - Page 4 Model ER8997B glass shelf cooling rack vegetable drawer diary compartment door shelf egg tray bottle shelf freezing tray + accumulator freezer basket ventilation grille freezer calender removeable shelf quick store Model ER9009B Glass shelf Bottle shelf Vegetable drawer Butter compartment Bottle shelf Freezer drawer Ventilation grille...
-
Page 5: Control Panel
Control Panel -- 18 ACTION FREEZE ACTION COOL A. Refrigerator power switch G. Temperature display Switches the refrigerator on and off. Shows the highest temperature inside the freezer. B. Temperature display H. Temperature adjustment buttons/thermostat Shows the average temperature inside the Used to set the temperature in the freezer. -
Page 6: Temperature Inside The Fridge
Setting the temperature Press the buttons until the desired temperature flashes in the temperature display (The temperature can be set between +1°C and +9°C.) - 18 "+" raises the temperature. "-" lowers the temperature. A setting of 5°C is usually suitable for normal operation. -
Page 7: Switching Off
Switching off Switch off the cabinet by pressing the power switch. - 18 Keep the button pressed for approx. 1 second. Power to the cabinet is completely interrupted only when the power plug is disconnected or the fuse is removed. Alarms and other features Door open alarm If the fridgedoor remains open for more than 5... -
Page 8: Using The Freezer
Using the freezer To start the freezer and set the correct temperature - 18 Switching on: Switch on the freezer by pressing the power switch. The alarm sounds if the temperature inside the freezer reaches room temperature. Turn off the alarm by pressing the switch-off button. -
Page 9: Switching Off
Temperature alarm If the temperature rises above -12°C, the red warning lamp flashes and an audible alarm sounds. The temperature display will then start to flash. To switch off the alarm: - 11 Press the alarm shut-off button to switch off the audible alarm. -
Page 10: Suitable Storage Periods
Practical advice on freezing · When freezing products, use the top shelf, and if necessary the shelf beneth that. · Place the foods directly on the freezer shelves. · Spread out the products as much as possible to allow air to circulate between them. ·... -
Page 11: Hints And Tips
Model ER8197B, ER8497BX, ER8997B Cold accumulator The cold accumulator will keep the food cold for longer after a power failure. The cold accumulator will be most effective when placed at the front of the fast-freezing tray. When freezing large amounts of food/provisions, the accumulator moves to the tray/space nearest to the lower freezing shelf. -
Page 12: Protect The Environment
· When cleaning the cabinet, use a mild Protect the environment washing-up detergent. · Follow the advice in the section "Saving energy" · Hand over the cabinet packaging and discarded · The door gasket and coolant used in this fridges and freezers to a recycling station. cabinet will not harm the ozone layer. -
Page 13: Defrosting The Freezer
Defrosting the freezer A certain amount of frost will always form on the freezer shelves and around the top compartment. Defrost the freezer when the frost layer reaches a thickness of about 3-5 mm. Remove the freezer drawers and place them on top of each other by turning every other drawer one half turn. -
Page 14: Something Not Working
Something Not Working Before contacting your local Service Force Center check the following point: Problem Possible cause / Remedy " " is displayed in the temperature An error has occurred in measuring the temperature. Call your display. service representative. (The cooling system will continue to keep food products cold, but temperature adjustment will not be possible.) The yellow Action Freeze and red... -
Page 15: Guarantee Conditions
Too much frost and ice are produced. Make sure that the door is completely closed and that the insulating strip is complete and clean. Set a higher temperature. The compressor operates continuously. Set a higher temperature. Make sure that the door is completely closed and that the insulating strip is complete and clean. -
Page 16: Technical Specification
Technical specification ER8197B ER8497BX ER8997B ER8492B ER9009B Model 193 l 240 l 240 l 240 l 292 l Volume fridge 97 l 85 l 127 l 85 l 85 l Volume freezer 595 mm 595 mm 595 mm 595 mm... -
Page 17: Cleaning
Cleaning Wash the inside of the cabinet using lukewarm water, a mild washing-up detergent and a soft cloth. Installing the cabinet To otain the best performance from the cabinet, ensure · the cabinet is placed in a dry, cool place and is not exposed to direct sunlight. -
Page 18: Electrical Connection
Connect the Green and Yellow (earth) wire to the Electrical connection terminal in the plug which is marked with the letter This appliance must be earthed. "E" or the earth symbol or coloured greeen and If the plug that is fitted to your appliance is not yellow. - Page 19 6. On the doors: Change the positions of the door fittings. Put a new plug in the hole on the lower door. 7. Replace the upper door and secure the upper hinge pin. Replace the lower door. Change the position of the hinge pin of the lower hinge.
- Page 20 MARIESTAD DD--AV...
