Page 1: Instrucciones De Uso
Fridge--Freezer / Frigorifero--Congelatore / Frigorifico--Congélador INSTRUCTION BOOKLET INSTRUCCIONES DE USO INSTRUÇÕNES DE USO ERB3800 ERB4000 818 19 40--01/9... -
Page 2: Table Of Contents
Safety instructions Carefully read these instructions to learn how the appliance works and how to care for it. Keep the instruction booklet. It will come in handy if you later sell the cabinet or give it to somebody else. These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using the appliance. -
Page 3: Description Of The Appliance
Description of the Appliance Model ERB3800 Glass shelf Bottle shelf Vegetable drawer Butter compartment Door shelf Egg holder Freezer calendar Freezer plate Freezer drawer Ventilation grille Model ERB4000 Glass shelf Bottle shelf Vegetable drawer Butter compartment Freezer plate Freezer drawer... -
Page 4: Control Panel
Control Panel -- 18 ACTION FREEZE ACTION COOL A. Refrigerator power switch G. Temperature display Switches the refrigerator on and off. Shows the highest temperature inside the freezer. B. Temperature display H. Temperature adjustment button/thermostat Shows the average temperature inside the Used to set the temperature in the freezer. -
Page 5: Temperature Inside The Fridge
Allow the cabinet to run for a period of 24 hours whenever the temperature setting is changed. This will allow the temperature to stabilise inside the cabinet. It is not necessary to reset the temperature when the cabinet is switched on after it has been out of use. The thermostat recalls the previously set temperature. -
Page 6: Alarms And Other Features
Alarms and other features Door open alarm If the fridgedoor remains open for more than 5 minutes, the red warning lamp starts flashing and an - 18 audible alarm sounds. To switch off the alarm: Press the "alarm shut-off button". The red warning lamp goes out when the door is closed. -
Page 7: Using The Freezer
Using the freezer To start the freezer and set the correct temperature - 18 Switching on: Switch on the freezer by pressing the power switch. The alarm sounds if the temperature inside the freezer reaches room temperature. Turn off the alarm by pressing the switch-off button. -
Page 8: Alarms And Other Features
Alarms and other features Door open alarm If the door remains open for more than about 1 minute, the red indicator lamp starts flashing and an audible alarm sounds. - 18 To switch off the alarm: Press the alarm shut-off button. As long as the door remains open, the audible alarm will sound anew at 1-minute intervals. -
Page 9: Suitable Storage Periods
Fast-freezing can be discontinued by pressing the fast-freezing button once again. The yellow fast-freezing lamp remains lit as long as the fast-freezing button is engaged. A" (ACTION FREEZE) is displayed in the temperature display. Practical advice on freezing · When freezing products, use the top shelf, and if necessary the shelf beneth that. -
Page 10: Hints And Tips
Freezer tray Use the freezer tray to freeze berries and vegetables. After about 4 hours the food will be thoroughly frozen and can then be packaged normally. Food that is frozen in this way will not stick together, enabling you to use only the amount required. Ice cubes Fill the ice tray to max. -
Page 11: Maintenance And Cleaning
Maintenance and Cleaning Removing the ventilation grille The ventilation grille can be removed, e.g. to wash the grille. Make sure the door is open when removing the ventilation grille. Unsnap the upper edge of the grille by pulling outward/downward. Then pull the grille straight out to completely remove it. -
Page 12: Defrosting The Freezer
Defrosting the freezer A certain amount of frost will always form on the freezer shelves and around the top compartment. Defrost the freezer when the frost layer reaches a thickness of about 3-5 mm. Remove the freezer drawers and place them on top of each other by turning every other drawer one half turn. -
Page 13: Something Not Working
Something Not Working Before contacting your local Service Force Centre check the following point: Problem Possible cause / Remedy " " is displayed in the temperature An error has occurred in measuring the temperature. Call your display. service representative. (The cooling system will continue to keep food products cold, but temperature adjustment will not be possible.) The yellow Action Freeze and red... -
Page 14: Guarantee Conditions
Too much frost and ice are produced. Make sure that the door is completely closed and that the insulating strip is complete and clean. Set a warmer temperature. The compressor operates continuously. Set a warmer temperature. Make sure that the door is completely closed and that the insulating strip is complete and clean. -
Page 15: Customer Care Department
Electrolux 55-77 High Street Slough Berkshire SL1 1DZ Phone: 08705 950950 * * calls to this number may be recorded for training purposes Technical specification ERB3800 ERB4000 Model 240 l 292 l Volume fridge 127 l 82 l Volume freezer... -
Page 16: Before Installing The Cabinet
Remove the transport supports Remove the tape and the transport supports from · the door sides · inside the door hinges · the shelves Remove the transport support on the glass shelf by pushing the support forward along the edge of the shelf until it stops. -
Page 17: Door Reversal
If the cabinet is placed in a corner and the side with the hinges facing the wall, the distance between the wall and the cabinet must be at least 10 mm to allow the door to open enough so that the shelves can be removed. - Page 18 qÜÉ=bäÉÅíêçäìñ=dêçìé=áë=íÜÉ=ïçêäÇDë=ä~êÖÉëí=éêçÇìÅÉê=çÑ=éçïÉêÉÇ=~ééäá~åÅÉë=Ñçê=âáíÅÜÉåI=ÅäÉ~åáåÖ=~åÇ=çìíÇççê=ìëÉK jçêÉ=íÜ~å=RR=ãáääáçå=bäÉÅíêçäìñ=dêçìé=éêçÇìÅíë=EëìÅÜ=~ë=êÉÑêáÖÉê~íçêëI=ÅççâÉêëI=ï~ëÜáåÖ=ã~ÅÜáåÉëI=î~Åììã=ÅäÉ~åÉêëI ÅÜ~áå=ë~ïë=~åÇ=ä~ïå=ãçïÉêëF=~êÉ=ëçäÇ=É~ÅÜ=óÉ~ê=íç=~=î~äìÉ=çÑ=~ééêçñK=rpa=NQ=Äáääáçå=áå=ãçêÉ=íÜ~å=NRM=ÅçìåíêáÉë ~êçìåÇ=íÜÉ=ïçêäÇK bä=dêìéç=bäÉÅíêçäìñ=Éë=Éä=ã~óçê=Ñ~ÄêáÅ~åíÉ=ÇÉä=ãìåÇç=ÇÉ=~é~ê~íçë=é~ê~=ä~=ÅçÅáå~I=äáãéáÉò~=ó=ìëç=ÉñíÉêáçêK=j•ë=ÇÉ=RR ãáääçåÉë=ÇÉ=éêçÇìÅíçë=ÇÉä=dêìéç=bäÉÅíêçäìñ=EÑêáÖçêáÑáÅçëI=ÅçåÖÉä~ÇçêÉëI=ÅçÅáå~ëI=ä~î~Ççê~ëI=~ëéáê~ÇçêÉëI=ãçíçëáÉêê~ë=ó Åçêí~ŨëéÉÇÉëF=ëÉ=îÉåÇÉå=Å~Ç~=~¥ç=éçê=ìå=î~äçê=~éêçñáã~Çç=ÇÉ=NQ=ÄáääçåÉë=ÇÉ=rpA=Éå=ã•ë=ÇÉ=NRM=é~áëÉë=ÇÉä=ãìåÇçK MARIESTAD DT--AV...
